IEI Technology NANO-PV-D4252 User Manual

Epic motherboard with intel atom processor, vga, dual lvds, gbe lan, eight usb 2.0, two sata 3gb/s, four rs-232, rs-232/422/485, pcie mini, pci-104, rohs
Hide thumbs Also See for NANO-PV-D4252:
Table of Contents

Advertisement

Quick Links

Download this manual
NANO-PV-D4252/N4552/D5252 EPIC SBC
IEI Technology Corp.
MODEL:
NANO-PV-D4252/N4552/D5252
EPIC Motherboard with Intel® Atom™ processor
D425/N455/D525, VGA, Dual LVDS, GbE LAN, Eight USB 2.0,
Two SATA 3Gb/s, Four RS-232, RS-232/422/485, PCIe mini,
PCI-104, RoHS

User Manual

Page i
Rev. 1.04 – 24 August, 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO-PV-D4252 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology NANO-PV-D4252

Summary of Contents for IEI Technology NANO-PV-D4252

  • Page 1: User Manual

    NANO-PV-D4252/N4552/D5252 EPIC SBC IEI Technology Corp. MODEL: NANO-PV-D4252/N4552/D5252 EPIC Motherboard with Intel® Atom™ processor D425/N455/D525, VGA, Dual LVDS, GbE LAN, Eight USB 2.0, Two SATA 3Gb/s, Four RS-232, RS-232/422/485, PCIe mini, PCI-104, RoHS User Manual Page i Rev. 1.04 – 24 August, 2011...
  • Page 2 NANO-PV-D4252/N4552/D5252 EPIC SBC Revision Date Version Changes 24 August, 2011 1.04 Minor revision to pin definitions in the following sections: 4.5.9 LVDS1 Screen Resolution Selection 4.5.10 LVDS2 Screen Resolution Selection 17 June, 2011 1.03 Minor revision to pin definitions in section 3.2.16 Power...
  • Page 3 NANO-PV-D4252/N4552/D5252 EPIC SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    ACKING 2.3.1 Optional Items....................11 3 CONNECTORS ......................12 3.1 P ..............13 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-PV-D4252/N4552/D5252 Layout............13 3.1.2 Peripheral Interface Connectors ..............14 3.1.3 External Interface Panel Connectors............... 15 3.2 I ..............15 NTERNAL ERIPHERAL ONNECTORS 3.2.1 Audio Connector ....................15 3.2.2 Battery Connector....................
  • Page 5 NANO-PV-D4252/N4552/D5252 EPIC SBC 3.2.13 Parallel Port Connector ................25 3.2.14 PCI-104 Connector..................26 3.2.15 PCIe Mini Card Slot ..................28 3.2.16 Power Connector (+12 V, power supply)............29 3.2.17 SATA Drive Connectors ................. 30 3.2.18 SATA Power Connector.................. 31 3.2.19 Serial Port Connectors (RS-232) ..............31 3.2.20 Serial Port Connector (RS-232/422/485) ............
  • Page 6 NANO-PV-D4252/N4552/D5252 EPIC SBC 4.5.11 LVDS Voltage Selection.................. 54 4.5.12 PCI-104 Voltage Setup ................... 55 4.6 C .................... 56 HASSIS NSTALLATION 4.6.1 Airflow......................56 4.6.2 Motherboard Installation................. 56 4.7 I ............56 NTERNAL ERIPHERAL EVICE ONNECTIONS 4.7.1 AT/ATX Power Connection ................56 4.7.2 Audio Kit Installation..................
  • Page 7 NANO-PV-D4252/N4552/D5252 EPIC SBC 5.3.7 H/W Monitor ....................84 5.3.8 Serial Port Console Redirection ..............86 5.4 C ........................87 HIPSET 5.4.1 Host Bridge Configuration ................88 5.4.1.1 OnChip VGA Configuration ..............89 5.4.2 South Bridge Configuration................90 5.4.3 Intel IGD SWSCI OpRegion................91 5.5 B...
  • Page 8 Figure 3-21: Serial Port Connector Location ................33 Figure 3-22: SMBus Connector Locations .................34 Figure 3-23: SPI Flash Connector ....................34 Figure 3-24: USB Connector Pinout Locations .................35 Figure 3-25: NANO-PV-D4252/N4552/D5252 External Peripheral Interface Connector ..36 Figure 3-26: RJ-45 Ethernet Connector..................37 Page viii...
  • Page 9 NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 3-27: PS/2 Pinout and Configuration ................37 Figure 3-28: VGA Connector .......................39 Figure 4-1: SO-DIMM Installation ....................44 Figure 4-2: AT Auto Button Select Jumper Settings..............46 Figure 4-3: AT/ATX Power Select Jumper Location..............47 Figure 4-4: Clear CMOS Jumper ....................48 Figure 4-5: COM 3 Function Select Jumper Location...............49...
  • Page 10 NANO-PV-D4252/N4552/D5252 EPIC SBC Figure B-10: Symantec Ghost Path ..................111 Figure B-11: Select a Local Source Drive ................111 Figure B-12: Select a Source Partition from Basic Drive ............111 Figure B-13: File Name to Copy Image to ................112 Figure B-14: Compress Image....................
  • Page 11 NANO-PV-D4252/N4552/D5252 EPIC SBC List of Tables Table 1-1: Technical Specifications....................7 Table 3-1: Peripheral Interface Connectors ................15 Table 3-2: Rear Panel Connectors ....................15 Table 3-3: Audio Connector Pinouts ..................16 Table 3-4: Battery Connector Pinouts ..................17 Table 3-5: CompactFlash® Slot Pinouts ..................18 Table 3-6: Digital I/O Connector Pinouts..................19...
  • Page 12 NANO-PV-D4252/N4552/D5252 EPIC SBC Table 3-30: VGA Connector Pinouts...................39 Table 4-1: Jumpers ........................45 Table 4-2: AT Auto Button Power Select Jumper Settings ............46 Table 4-3: AT/ATX Power Select Jumper Settings ..............46 Table 4-4: Clear CMOS Jumper Settings..................48 Table 4-5: COM 3 Function Select Jumper Settings ..............48 Table 4-6: COM 3 RS-422/485 Function Select Jumper Settings..........49...
  • Page 13 NANO-PV-D4252/N4552/D5252 EPIC SBC BIOS Menus BIOS Menu 1: Main ........................71 BIOS Menu 2: Advanced ......................72 BIOS Menu 3: ACPI Settings .......................73 BIOS Menu 4: TPM Configuration ....................74 BIOS Menu 5: CPU Configuration ....................75 BIOS Menu 6: IDE Configuration....................76 BIOS Menu 7: USB Configuration ....................77 BIOS Menu 8: Super IO Configuration..................78...
  • Page 14 NANO-PV-D4252/N4552/D5252 EPIC SBC Page xiv...

  • Page 15: Introduction

    NANO-PV-D4252/N4552/D5252 EPIC SBC Chapter Introduction Page 1...

  • Page 16: Introduction

    (with support). NANO-PV-D4252/N4552/D5252 also supports two SATA 3Gb/s drives and provides 5 V SATA power. The NANO-PV-D4252/N4552/D5252 supports dual display via VGA and two internal LVDS LCD connectors. Eight USB 2.0 channels, one PCIe mini socket, one PCI-104 slot and internal one parallel port connector provide flexible expansion options.

  • Page 17: Connectors

    NANO-PV-D4252/N4552/D5252 EPIC SBC 1.2 Connectors The connectors on the NANO-PV-D4252/N4552/D5252 are shown in the figure below. Figure 1-2: Connectors Page 3...

  • Page 18: Dimensions

    NANO-PV-D4252/N4552/D5252 EPIC SBC 1.3 Dimensions The dimensions of the board are listed below:  Length: 165 mm  Width: 115 mm Figure 1-3: NANO-PV-D4252/N4552/D5252 Dimensions (mm) Page 4...

  • Page 19: Data Flow

    NANO-PV-D4252/N4552/D5252 EPIC SBC 1.4 Data Flow F igure 1-4 shows the data flow between the two on-board chipsets and other components installed on the motherboard and described in the following sections of this chapter. Figure 1-4: Data Flow Block Diagram...

  • Page 20: Technical Specifications

    NANO-PV-D4252/N4552/D5252 EPIC SBC 1.5 Technical Specifications NANO-PV-D4252/N4552/D5252 technical specifications are listed in table below. Specification NANO-PV-D4252/N4552/D5252 EPIC Form Factor Intel® Atom™ processor D525, 1.8 GHz/1 MB L2 cache CPU options Intel® Atom™ processor D425, 1.8 GHz/512 KB L2 cache Intel® Atom™ processor N455, 1.66 GHz/512 KB L2 cache Intel®...

  • Page 21: Table 1-1: Technical Specifications

    NANO-PV-D4252/N4552/D5252 EPIC SBC Specification NANO-PV-D4252/N4552/D5252 One RS-232 serial port Serial Ports Three RS-232 via four 10-pin headers One RS-232/422/485 via 14–pin header Two external USB ports USB 2.0/1.1 Ports Six internal USB ports via three 8-pin headers One LPT connector via 26-pin header...

  • Page 22: Unpacking

    NANO-PV-D4252/N4552/D5252 EPIC SBC Chapter Unpacking Page 8...

  • Page 23: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the NANO-PV-D4252/N4552/D5252 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 24: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-PV-D4252/N4552/D5252 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.

  • Page 25: Optional Items

    NANO-PV-D4252/N4552/D5252 EPIC SBC Dual USB cable (w bracket) (P/N:CB-USB02A-RS) Mini jumper pack (2.0mm) (P/N: 33100-000033-RS) Utility CD Quick Installation Guide 2.3.1 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image LPT cable (wo bracket)

  • Page 26: Connectors

    NANO-PV-D4252/N4552/D5252 EPIC SBC Chapter Connectors Page 12...

  • Page 27: Peripheral Interface Connectors

    NANO-PV-D4252/N4552/D5252 EPIC SBC 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 NANO-PV-D4252/N4552/D5252 Layout The figures below show all the connectors and jumpers. Figure 3-1: Connector and Jumper Locations Page 13...

  • Page 28: Peripheral Interface Connectors

    NANO-PV-D4252/N4552/D5252 EPIC SBC 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label Audio connector 10-pin header AUDIO1 Battery connector 2-pin wafer BAT1 BIOS update connector 6-pin wafer SPI1 CompactFlash® slot 50-pin header...

  • Page 29: External Interface Panel Connectors

    9-pin male COM1 USB ports (dual) USB port USB6_7 Table 3-2: Rear Panel Connectors 3.2 Internal Peripheral Connectors The section describes all of the connectors on the NANO-PV-D4252/N4552/D5252. 3.2.1 Audio Connector CN Label: AUDIO1 10-pin header (2x5) CN Type: CN Location:...

  • Page 30: Battery Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC The audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system. Figure 3-2: Audio Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION...

  • Page 31: Compactflash® Slot

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description Battery+ Ground Table 3-4: Battery Connector Pinouts 3.2.3 CompactFlash® Slot CN Label: CN Type: CompactFlash® card slot CN Location: See Figure 3-4 CN Pinouts: See Table 3-5 A CompactFlash® Type I/II card can be used in this slot.

  • Page 32: Digital I/O Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description Description GROUND VCC_CF GROUND IRQ14 VCC_CF VCC_CF GROUND CSEL GROUND GROUND HDD_RESET GROUND IORDY SDREQ SDACK# HDD_ACTIVE# DATA 0 66DET DATA 1 DATA 8 DATA 2 DATA 9 DATA 10 VCC-IN CHECK2 GROUND Table 3-5: CompactFlash® Slot Pinouts 3.2.4 Digital I/O Connector...

  • Page 33: Fan Connector (Cpu)

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description Description Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 3-6: Digital I/O Connector Pinouts 3.2.5 Fan Connector (CPU) CN Label: CPU_FAN1 CN Type: 3-pin wafer (1x3) CN Location:...

  • Page 34: Fan Connector (System)

    NANO-PV-D4252/N4552/D5252 EPIC SBC 3.2.6 Fan Connector (System) CN Label: SYS_FAN1 3-pin wafer (1x3) CN Type: CN Location: F igure 3-7 CN Pinouts: T able 3-8 The cooling fan connector provides a 12V, 500mA current to the cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed.

  • Page 35: Keyboard/Mouse Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Power button  Reset  Power LED  HDD LED Figure 3-8: Front Panel Connector Location FUNCTION DESCRIPTION FUNCTION DESCRIPTION Power Button PWR_BTN+ Power LED PWR LED SATA LED SATA LED PWT Reset RESET SATA_LED# Table 3-9: Front Panel Connector Pinouts 3.2.8 Keyboard/Mouse Connector...

  • Page 36: Backlight Inverter Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description +5 VCC MS DATA MS CLK KB DATA KB CLK GROUND Table 3-10: Keyboard/Mouse Connector Pinouts 3.2.9 Backlight Inverter Connector CN Label: INV1, INV2 5-pin wafer (1x5) CN Type: CN Location: See Figure 3-10 CN Pinouts: See Table 3-11 The backlight inverter connector provides power to an LCD panel.

  • Page 37: Lvds Backlight Adjustment (Lvds2)

    NANO-PV-D4252/N4552/D5252 EPIC SBC 3.2.10 LVDS Backlight Adjustment (LVDS2) CN Label: KEY1 9-pin header CN Type: CN Location: See Figure 3-11 CN Pinouts: See Table 3-12 Interfaces to the LPC interface on the Southbridge. Figure 3-11: LPC Connector Location Description Description...

  • Page 38: Lvds2 Lcd Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 3-12: LVDS1 Connector Locations Description Description GROUND GROUND LVDSA_DATA0+ LVDSA_DATA0- LVDSA_DATA1+ LVDSA_DATA1- LVDSA_DATA2+ LVDSA_DATA2- LVDSA_CLK+ LVDSA_CLK- GROUND GROUND LDDC_DATA LDDC_CLK VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 3-13: LVDS1 Connector Pinouts 3.2.12 LVDS2 LCD Connector CN Label: LVDS2...

  • Page 39: Parallel Port Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 3-13: LVDS2 Connector Location Description Description GROUND GROUND LVDSA_Y0+ LVDSA_Y0- LVDSA_Y1+ LVDSA_Y1- LVDSA_Y2+ LVDSA_Y2- LVDSA_CLK+ LVDSA_CLK- LVDSA_Y3+ LVDSA_Y3- GROUND GROUND LVDSB_Y0+ LVDSB_Y0- LVDSB_Y1+ LVDSB_Y1- LVDSB_Y2+ LVDSB_Y2- LVDSB_CLK+ LVDSB_CLK- LVDSB_Y3+ LVDSB_Y3- GROUND GROUND VCC_LVDS VCC_LVDS VCC_LVDS VCC_LVDS Table 3-14: LVDS2 Connector Pinouts 3.2.13 Parallel Port Connector...

  • Page 40: Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC The parallel port connector connects to a parallel port connector interface or some other parallel port device such as a printer. Figure 3-14: Parallel Port Connector Location Description Description STROBE# PTD0 ERROR# PTD1 INITIALIZE PTD 2 SLIN...

  • Page 41: Figure 3-15: Pci-104 Connector Location

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 3-15: PCI-104 Connector Location Row A Row B Row C Row D GND/5 V TBD1 AD00 VI/O1 AD02 AD01 +5 V AD05 AD04 AD03 C/BE0# AD07 AD06 AD09 AD08 AD11 VI/O2 AD10 M66EN AD14 AD13 AD12 +3.3 V...

  • Page 42: Pcie Mini Card Slot

    NANO-PV-D4252/N4552/D5252 EPIC SBC Row A Row B Row C Row D +5 V CLK0 CLK1 CLK2 +5 V CLK3 INTD# +5 V RST# +12 V INTA# INTB# INTC# -12 V TBD2 GND/3.3 V Table 3-16: PCI-104 Connector Pinouts 3.2.15 PCIe Mini Card Slot...

  • Page 43: Power Connector (+12 V, Power Supply)

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description Description VCC3 PCIRST# PERN2 3VDual PERP2 1.5 V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ VCC3 VCC3 RF_LINK# SATATXP1 BLUELED# SATATXN1 1.5 V SATARXN1 SATARXP1 VCC3 Table 3-17: PCIe Mini Card Slot Pinouts 3.2.16 Power Connector (+12 V, power supply)

  • Page 44: Sata Drive Connectors

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 3-17: CPU 12V Power Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V Table 3-18: CPU 12V Power Connector Pinouts 3.2.17 SATA Drive Connectors CN Label: SATA1, SATA2 7-pin SATA drive connectors CN Type: CN Location:...

  • Page 45: Sata Power Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Table 3-19: SATA Drive Connector Pinouts 3.2.18 SATA Power Connector CN Label: PWR1 CN Type: 2-pin wafer (1x2) See Figure 3-19 CN Location: CN Pinouts: See Table 3-20 The SATA Power Connector provides +5V power output to the SATA connectors.

  • Page 46: Figure 3-20: Com Connector Pinout Locations

    NANO-PV-D4252/N4552/D5252 EPIC SBC These connectors provide RS-232 communications. Figure 3-20: COM Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data Carrier Direct (DCD) Data Set Ready (DSR) Receive Data (RXD) Request To Send (RTS) Transmit Data (TXD) Clear To Send (CTS)

  • Page 47: Serial Port Connector (Rs-232/422/485)

    NANO-PV-D4252/N4552/D5252 EPIC SBC 3.2.20 Serial Port Connector (RS-232/422/485) CN Label: COM3 14-pin header (2x7) CN Type: CN Location: See Figure 3-21 CN Pinouts: See Table 3-22 Used for RS-232/422/485 communications. Figure 3-21: Serial Port Connector Location PIN NO. DESCRIPTION PIN NO.

  • Page 48: Spi Flash Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 3-22: SMBus Connector Locations PIN NO. DESCRIPTION SMBDATA SMBCLK VCC5S Table 3-23: SMBus Connector Pinouts 3.2.22 SPI Flash Connector CN Label: SPI1 8-pin header (2x4) CN Type: CN Location: See Figure 3-23 CN Pinouts: See Table 3-24 The 8-pin SPI Flash connector is used to flash the BIOS.

  • Page 49: Usb Connectors

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description Description Table 3-24: SPI Flash Connector Pinouts 3.2.23 USB Connectors CN Label: USB0_1, USB2_3, USB4_5 CN Type: 8-pin header (2x4) CN Location: See Figure 3-24 CN Pinouts: See Table 3-25 The USB connectors connect to USB devices. Each pin header provides two USB ports.

  • Page 50: External Peripheral Interface Connector Panel

    NANO-PV-D4252/N4552/D5252 EPIC SBC 3.3 External Peripheral Interface Connector Panel F igure 3-25 shows the NANO-PV-D4252/N4552/D5252 external peripheral interface connector (EPIC) panel. The NANO-PV-D4252/N4552/D5252 EPIC panel consists of the following:  1 x Ethernet connector  1 x Keyboard/Mouse  1 x Serial port (RS-232) ...

  • Page 51: Keyboard/Mouse Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Table 3-26: LAN Pinouts The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the speed. See T able 3-27. Speed LED...

  • Page 52: Usb Connectors

    CN Type: USB port CN Location: F igure 3-25 CN Pinouts: T able 3-29 The NANO-PV-D4252/N4552/D5252 has four external USB 2.0 ports. The ports connect to both USB 2.0 and USB 1.1 devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA-...

  • Page 53: Figure 3-28: Vga Connector

    NANO-PV-D4252/N4552/D5252 EPIC SBC Connects to a monitor that accepts a standard VGA input. Figure 3-28: VGA Connector DESCRIPTION DESCRIPTION GREEN BLUE VCC / NC DDC DAT HSYNC VSYNC DDCCLK Table 3-30: VGA Connector Pinouts Page 39...

  • Page 54: Installation

    NANO-PV-D4252/N4552/D5252 EPIC SBC Chapter Installation Page 40...

  • Page 55: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-PV-D4252/N4552/D5252. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the NANO-PV-D4252/N4552/D5252 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 56: Installation Considerations

    4.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before the NANO-PV-D4252/N4552/D5252 is installed. All installation notices pertaining to the installation of the NANO-PV-D4252/N4552/D5252 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the NANO-PV-D4252/N4552/D5252 and injury to the person installing the motherboard.

  • Page 57: Unpacking

    NANO-PV-D4252/N4552/D5252 vendor reseller/vendor where the NANO-PV-D4252/N4552/D5252 was purchased or contact an IEI sales representative. 4.4 SO-DIMM Installation SO-DIMM is a critical component of the NANO-PV-D4252/N4552/D5252. If it is not installed the NANO-PV-D4252/N4552/D5252 cannot run. Page 43...

  • Page 58: So-Dimm Installation

    NANO-PV-D4252/N4552/D5252 EPIC SBC 4.4.1 SO-DIMM Installation To install an SO-DIMM, please follow the steps below and refer to Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket. Place the board on an anti-static mat. Step 2: Align the SO-DIMM with the socket. Align the notch on the memory with the notch on the memory socket.

  • Page 59: At Auto Button Power Select Jumper Settings

    NANO-PV-D4252/N4552/D5252 EPIC SBC Before the NANO-PV-D4252/N4552/D5252 is installed in the system, the jumpers must be accordance with desired configuration. jumpers NANO-PV-D4252/N4552/D5252 are listed in T able 4-1. Description Type Label AT Auto Button 2-pin header J_AUTOPWR1 Clear CMOS 3-pin header J_CMOS1 CompactFlash®...

  • Page 60: At/Atx Power Select Jumper Settings

    NANO-PV-D4252/N4552/D5252 EPIC SBC Setting Description Open Use ATX power Table 4-2: AT Auto Button Power Select Jumper Settings Figure 4-2: AT Auto Button Select Jumper Settings 4.5.2 AT/ATX Power Select Jumper Settings Jumper Label: J_ATXCTL1 3-pin header (1x3) Jumper Type:...

  • Page 61: Clear Cmos Jumper

    Jumper Location: F igure 4-4 If the NANO-PV-D4252/N4552/D5252 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 62: Com 3 Function Select Jumper

    NANO-PV-D4252/N4552/D5252 EPIC SBC Clear CMOS Description Short 1 - 2 Keep CMOS Setup Default Short 2 - 3 Clear CMOS Setup Table 4-4: Clear CMOS Jumper Settings The location of the clear CMOS jumper is shown in F igure 4-4 below.

  • Page 63: Com 3 Rs-422/485 Function Select Jumper

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 4-5: COM 3 Function Select Jumper Location 4.5.5 COM 3 RS-422/485 Function Select Jumper Jumper Label: Jumper Type: 6-pin header Jumper Settings: See Table 4-5 Jumper Location: See Figure 4-5 The COM 3 Function Select jumper sets the communication protocol used by the second serial communications port (COM 3) as RS-422 or RS-485.

  • Page 64: Com 3 Rs-422/485 Termination Select Jumpers

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 4-6: COM 3 RS-422/485 Function Select Jumper Location 4.5.6 COM 3 RS-422/485 Termination Select Jumpers Jumper Label: J9 and J10 Jumper Type: 2-pin header Jumper Settings: See Table 4-5 and Table 4-7 Jumper Location: See Figure 4-7 The COM 3 RS-422 and RS-485 Termination Select jumpers enable or disable the termination used by the serial COM 3 communications port as 120 ohm.

  • Page 65: Compactflash® Card Setup

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 4-7: COM 3 RS-422 and RS-485 Termination Select Jumper Location 4.5.7 CompactFlash® Card Setup Jumper Label: JCF1 Jumper Type: 2-pin header Jumper Settings: See Table 4-9 Jumper Location: See Figure 4-4 The CompactFlash® slot is connected through an IDE connection. This jumper sets the CompactFlash®...

  • Page 66: Compactflash® Voltage Selection

    NANO-PV-D4252/N4552/D5252 EPIC SBC 4.5.8 CompactFlash® Voltage Selection WARNING: Incorrect voltages can destroy the CF card. Make sure to select a voltage that matches the voltage required by the CF card. Jumper Label: J_VCF1 2-pin header Jumper Type: Jumper Settings: See Table 4-10...

  • Page 67: Lvds2 Screen Resolution Selection

    NANO-PV-D4252/N4552/D5252 EPIC SBC The LVDS1 Screen Resolution Selection jumper allows the LVDS screen voltage to be set. The LVDS1 Screen Resolution Selection jumper settings are shown in Table 4-13. Description Open 640 x 480 800 x 600 1024 x 768...

  • Page 68: Lvds Voltage Selection

    NANO-PV-D4252/N4552/D5252 EPIC SBC Description 1366 x 768 1-2 and 5-6 1920 x 1080 Table 4-12: LVDS2 Screen Resolution Jumper Settings Figure 4-11: LVDS2 Screen Resolution Jumper Location 4.5.11 LVDS Voltage Selection WARNING: Incorrect voltages can destroy the LCD panel. Make sure to select a voltage that matches the voltage required by the LCD panel.

  • Page 69: Voltage Setup

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 4-12: LVDS Voltage Selection Jumper Locations 4.5.12 PCI-104 Voltage Setup Jumper Label: Jumper Type: 3-pin header Jumper Settings: See Table 4-14 See Figure 4-13 Jumper Location: This jumper selects the voltage supplied to the PCI-104 expansion module.

  • Page 70: Chassis Installation

    4.7 Internal Peripheral Device Connections This section outlines the installation of peripheral devices to the onboard connectors 4.7.1 AT/ATX Power Connection Follow the instructions below to connect the NANO-PV-D4252/N4552/D5252 to an AT or ATX power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the NANO-PV-D4252/N4552/D5252.

  • Page 71: Figure 4-14: Power Cable To Motherboard Connection

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 1: Locate the power cable. The power cable is shown in the packing list in Chapter 3. Step 2: Connect the Power Cable to the Motherboard. Connect the 4-pin (2x2) Molex type power cable connector to the AT/ATX power connector on the motherboard.

  • Page 72: Audio Kit Installation

    Figure 4-15: Connect Power Cable to Power Supply 4.7.2 Audio Kit Installation The Audio Kit that came with the NANO-PV-D4252/N4552/D5252 connects to the audio connector on the NANO-PV-D4252/N4552/D5252. The audio kit consists of three audio jacks. Mic-in connects to a microphone. Line-in provides a stereo line-level input to connect to the output of an audio device.

  • Page 73: Single Rs-232 Cable (W/O Bracket)

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 4-16: Audio Kit Cable Connection Step 3: Connect the audio devices. Connect speakers to the line-out audio jack. Connect the output of an audio device to the line-in audio jack. Connect a microphone to the mic-in audio jack.Step 0:...

  • Page 74: External Peripheral Interface Connection

    RJ-45 Ethernet cable connector  Serial devices  USB devices  VGA monitor To install these devices, connect the corresponding cable connector from the actual device to the corresponding NANO-PV-D4252/N4552/D5252 external peripheral interface connector making sure the pins are properly aligned. Page 60...

  • Page 75: Lan Connection (Single Connector)

    The dual PS/2 connector is connected to the PS/2 Y-cable that came with the NANO-PV-D4252/N4552/D5252. One of the PS/2 cables is connected to a keyboard and the other to a mouse to the system. Follow the steps below to connect a keyboard and mouse to the NANO-PV-D4252/N4552/D5252.

  • Page 76: Serial Device Connection

    Step 0: 4.8.3 Serial Device Connection The NANO-PV-D4252/N4552/D5252 has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the NANO-PV-D4252/N4552/D5252. Page 62...

  • Page 77: Usb Connection (Dual Connector)

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 1: Locate the DB-9 connector. The location of the DB-9 connector is shown in Chapter 3. Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into the DB-9 connector on the external peripheral interface. See Figure 4-20.

  • Page 78: Vga Monitor Connection

    Figure 4-21: USB Connector 4.8.5 VGA Monitor Connection The NANO-PV-D4252/N4552/D5252 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the NANO-PV-D4252/N4552/D5252, please follow the instructions below.

  • Page 79: Software Installation

    Step 0: 4.9 Software Installation All the drivers for the NANO-PV-D4252/N4552/D5252 are on the CD that came with the system. To install the drivers, please follow the steps below. Step 1: Insert the CD into a CD drive connected to the system.

  • Page 80: Figure 4-23: Introduction Screen

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 2: The driver main menu appears (Figure 4-23). Figure 4-23: Introduction Screen Step 3: Click NANO-PV-D4252/N4552/D5252. Step 4: A new screen with a list of available drivers appears (Figure 4-24). Page 66...

  • Page 81: Figure 4-24: Available Drivers

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure 4-24: Available Drivers Step 5: Install all of the necessary drivers in this menu. S t e p 0 : Page 67...

  • Page 82: Bios Screens

    NANO-PV-D4252/N4552/D5252 EPIC SBC Chapter BIOS Screens Page 68...

  • Page 83: Introduction

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 84: Getting Help

    NANO-PV-D4252/N4552/D5252 EPIC SBC Function F4 key Save all the CMOS changes Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help...

  • Page 85: Main

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 86: Advanced

    NANO-PV-D4252/N4552/D5252 EPIC SBC  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices...

  • Page 87: Trusted Computing

    NANO-PV-D4252/N4552/D5252 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced ACPI Sleep State [S3 (Suspend to R…)] Set the ACPI state used for System suspend ---------------------- : Select Screen  : Select Item Enter Select General Help...

  • Page 88: Cpu Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced TPM Configuration Enables or Disables TPM TPM SUPPORT [Disable] support. O.S. will not show TPM. Reset of Current TPM Status Information platform is required. NO TPM Hardware ---------------------- : Select Screen...

  • Page 89: Bios Menu 5: Cpu Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced CPU Configuration Processor Type Intel(R) Atom(TM) CPU CPU N475 @ 1.83GHz ---------------------- EMT64 Supported : Select Screen Processor Speed 1834 MHz  : Select Item System Bus Speed...

  • Page 90: Sata Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.3.4 SATA Configuration Use the SATA Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PATA Master...

  • Page 91: Usb Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Configure SATA as [IDE] Use the Configure SATA as option to configure SATA devices as normal IDE devices.  Configures SATA devices as normal IDE device. EFAULT  AHCI Configures SATA devices as AHCI device. 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings.

  • Page 92: Super Io Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard does not become available until a USB compatible operating system is fully booted with all USB drivers loaded.

  • Page 93: Serial Port N Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.3.6.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Serial Port 0 Configuration Enable or Disable Serial...
  • Page 94 NANO-PV-D4252/N4552/D5252 EPIC SBC  IO=3F8h; Serial Port I/O port address is 3F8h and the interrupt IRQ=3, 4 address is IRQ3 and IRQ4  Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3 and IRQ4 IRQ=3, 4 5.3.6.1.2 Serial Port 1 Configuration...
  • Page 95 NANO-PV-D4252/N4552/D5252 EPIC SBC  Enabled Enable the serial port EFAULT  Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.  The serial port IO port address and interrupt address...

  • Page 96: Irda Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC  IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt IRQ=10 address is IRQ10  Serial Port I/O port address is 3E8h and the interrupt IO=3E8h; address is IRQ10, 11 IRQ=10, 11  IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt...

  • Page 97: Parallel Port Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.3.6.3 Parallel Port Configuration Use the Parallel Port Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Parallel Port Configuration Change the Printer Port...

  • Page 98: H/W Monitor

    NANO-PV-D4252/N4552/D5252 EPIC SBC  IO=3BCh; Parallel Port I/O port address is 3BCh and the IRQ=7 interrupt address is IRQ7  Parallel Port I/O port address is 378h IO=378h  IO=278h Parallel Port I/O port address is 278h  IO=3BCh Parallel Port I/O port address is 3BCh ...

  • Page 99: Bios Menu 12: Hardware Health Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PC Health Status CPU Temperature :+39 C SYS Temperature :+40 C CPU FAN Speed :4950 RPM VCC3V :+3.344 V V_core :+1.136 V :+5.087 V --------------------- : Select Screen Vcc12 :+11.352 V...

  • Page 100: Serial Port Console Redirection

    NANO-PV-D4252/N4552/D5252 EPIC SBC  CPU Smart Fan control [Auto Mode] Use the CPU Smart Fan control option to configure the CPU fan.  The fan adjusts its speed using these settings: Auto Mode Temperature Bound 1 Temperature Bound 2 Temperature Bound 3 Temperature Bound 4 ...

  • Page 101: Chipset

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Disabled Disabled the console redirection function EFAULT  Enabled the console redirection function Enabled 5.4 Chipset Use the Chipset menu (BIOS Menu 14) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 102: Host Bridge Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.4.1 Host Bridge Configuration Use the Host Bridge Configuration menu (BIOS Menu 15) to configure the Northbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset > OnChip VGA Configuration Select which graphics Initate Graphic Adapter...

  • Page 103: Onchip Vga Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.4.1.1 OnChip VGA Configuration Use the OnChip VGA Configuration menu (BIOS Menu 15) to configure the OnChip VGA. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset OnChip VGA Configuration Select Share Memory Size. Share Memory Size...

  • Page 104: South Bridge Configuration

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Disabled Disabled the multi-monitor function  Enabled the multi-monitor function Enabled EFAULT 5.4.2 South Bridge Configuration Use the South Bridge Configuration menu (BIOS Menu 17) to configure the Southbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 105: Intel Igd Swsci Opregion

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Enabled USB function support enabled EFAULT  USB 2.0 (EHCI) Support [Enabled] Use the USB 2.0 (EHCI) Support BIOS option to enable or disable USB 2.0 support.  USB 2.0 (EHCI) support enabled Enabled EFAULT ...
  • Page 106 NANO-PV-D4252/N4552/D5252 EPIC SBC  DVMT Mode Select [DVMT Mode] Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology (DVMT) operating mode.  Fixed A fixed portion of graphics memory is reserved as Mode graphics memory.

  • Page 107: Boot

    NANO-PV-D4252/N4552/D5252 EPIC SBC  1024x768 18bit  1280x1024 18bit  1366x768 18bit  1280x800 18bit  1280x600 18bit 5.5 Boot Use the Boot menu (BIOS Menu 19) to configure system boot options. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 108: Security

    NANO-PV-D4252/N4552/D5252 EPIC SBC  Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The Number Lock LED on the keyboard lights up when the Number Lock is engaged.

  • Page 109: Bios Menu 20: Security

    NANO-PV-D4252/N4552/D5252 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is...

  • Page 110: Exit

    NANO-PV-D4252/N4552/D5252 EPIC SBC 5.7 Exit Use the Exit menu (BIOS Menu 21) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
  • Page 111 NANO-PV-D4252/N4552/D5252 EPIC SBC  Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults.  Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 112: Abios Menu Options

    NANO-PV-D4252/N4552/D5252 EPIC SBC Appendix BIOS Menu Options 　 BIOS Information .........................71 　 System Date [xx/xx/xx] ......................71 　 System Time [xx:xx:xx] .......................72 　 ACPI Sleep State [S3 (Suspend to RAM)]................73 　 TPM Support [Disable] ......................74 　 ATA/IDE Configurations [Enhanced] .................76 　...
  • Page 113 NANO-PV-D4252/N4552/D5252 EPIC SBC 　 Device Mode [Printer Mode]....................84 　 PC Health Status ........................85 　 CPU Smart Fan control [Auto Mode] .................86 　 Console Redirection [Disabled] ..................86 　 Share Memory Size [8 MB] ....................89 　 Multi-Monitor Support [Enabled] ..................89 　 HD Audio Controller [Enabled] ...................90 　...

  • Page 114: B One Key Recovery

    NANO-PV-D4252/N4552/D5252 EPIC SBC Appendix One Key Recovery Page 100...

  • Page 115: One Key Recovery Introduction

    NANO-PV-D4252/N4552/D5252 EPIC SBC B.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. The one key recovery provides quick and easy shortcuts for creating a backup and reverting to that backup or for reverting to the factory default settings.
  • Page 116 NANO-PV-D4252/N4552/D5252 EPIC SBC Windows 7 Windows CE 5.0 Windows CE 6.0 Windows XP Embedded  Linux Fedora Core 12 (Constantine) Fedora Core 11 (Leonidas) Fedora Core 10 (Cambridge) Fedora Core 8 (Werewolf) Fedora Core 7 (Moonshine) RedHat RHEL-5.4 RedHat 9 (Ghirke) Ubuntu 8.10 (Intrepid)

  • Page 117: Setup Procedure For Windows

    NANO-PV-D4252/N4552/D5252 EPIC SBC NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware. B.2 Setup Procedure for Windows Prior to using the recovery tool to backup or restore system, a few setup procedures are required.

  • Page 118: Hardware And Bios Setup

    Step 1: Make sure the system is powered off and unplugged. Step 2: Install a hard driver or SSD in the NANO-PV-D4252/N4552/D5252. An unformatted and unpartitioned disk is recommended. Step 3: Connect an optical disk drive to the NANO-PV-D4252/N4552/D5252 and insert the recovery CD.

  • Page 119: Figure B-1: Recovery Tool Setup Menu

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure B-1: Recovery Tool Setup Menu Step 5: Press <5> then <Enter>. Figure B-2: Command Mode Step 6: The command prompt window appears. Type the following commands (marked in red) to create two partitions. One is for the OS installation; the other is for saving recovery files and images which will be an invisible partition.

  • Page 120: Figure B-3: Partition Creation Commands

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure B-3: Partition Creation Commands Page 106...

  • Page 121: Install Operating System, Drivers And Applications

    NANO-PV-D4252/N4552/D5252 EPIC SBC NOTE: Use the following commands to check if the partitions were created successfully. Step 7: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build-up Recovery Partition.S t e p 0 : B.2.3 Install Operating System, Drivers and Applications...

  • Page 122: Figure B-4: System Configuration For Windows

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 2: Start the system. Step 3: Press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient. Step 4: When the recovery tool setup menu appears, press <2> then <Enter>.

  • Page 123: Create Factory Default Image

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 6: After completing the system configuration, press any key in the following window to reboot the system. Figure B-6: Press any key to continue Step 7: Eject the recovery CD. S t e p 0 : B.2.5 Create Factory Default Image...

  • Page 124: Figure B-8: Recovery Tool Menu

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure B-8: Recovery Tool Menu Step 3: The About Symantec Ghost window appears. Click OK button to continue. Figure B-9: About Symantec Ghost Window Step 4: Use mouse to navigate to the option shown below (Figure B-10).

  • Page 125: Figure B-10: Symantec Ghost Path

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure B-10: Symantec Ghost Path Step 5: Select the local source drive as shown in Figure B-11. Then click OK. Figure B-11: Select a Local Source Drive Step 6: Select a source partition from basic drive as shown in Figure B-12. Then click...

  • Page 126: Figure B-13: File Name To Copy Image To

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 7: Select 1.2: [Recovery] NTFS drive and enter a file name called (Figure B-13). Click Save. The factory default image will then be saved in the selected recovery drive and named IEI.GHO. WARNING: The file name of the factory default image must be iei.GHO.

  • Page 127: Figure B-14: Compress Image

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 8: When the Compress Image screen in Figure B-14 prompts, click High to make the image file smaller. Figure B-14: Compress Image Step 9: The Proceed with partition image creation window appears, click Yes to continue.

  • Page 128: Setup Procedure For Linux

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 11: When the image creation completes, a screen prompts as shown in Figure B-17. Click Continue and close the Ghost window to exit the program. Figure B-17: Image Creation Complete Step 12: The recovery tool main menu window is shown as below. Press any key to reboot the system.

  • Page 129: Figure B-19: Partitions For Linux

    NANO-PV-D4252/N4552/D5252 EPIC SBC NOTE: If the Linux OS is not installed with GRUB (v0.97 or earlier) and Ext3, the Symantec Ghost may not function properly. While installing Linux OS, please create two partitions:  Partition 1: /  Partition 2: SWAP...

  • Page 130: Figure B-20: System Configuration For Linux

    NANO-PV-D4252/N4552/D5252 EPIC SBC system32>format N: /fs:ntfs /q /v:Recovery /y system32>exit Step 4: Build-up recovery partition. Press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient. When the recovery tool setup menu appears, type <3>...

  • Page 131: Recovery Tool Functions

    NANO-PV-D4252/N4552/D5252 EPIC SBC Step 7: The recovery tool menu appears. (Figure B-22) Figure B-22: Recovery Tool Menu Step 8: Create a factory default image. Follow Step 2 Step 12 described in Section B.2.5 to create a factory default image. B.4 Recovery Tool Functions After completing the initial setup procedures as described above, users can access the recovery tool by pressing <F3>...

  • Page 132: Figure B-23: Recovery Tool Main Menu

    NANO-PV-D4252/N4552/D5252 EPIC SBC Figure B-23: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section B.2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 133: Factory Restore

    NANO-PV-D4252/N4552/D5252 EPIC SBC B.4.1 Factory Restore To restore the factory default image, please follow the steps below. Step 1: Type <1> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 134: Backup System

    NANO-PV-D4252/N4552/D5252 EPIC SBC B.4.2 Backup System To backup the system, please follow the steps below. Step 1: Type <2> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 135: Restore Your Last Backup

    NANO-PV-D4252/N4552/D5252 EPIC SBC B.4.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Step 1: Type <3> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the last backup image (iei_user.GHO).

  • Page 136: Manual

    NANO-PV-D4252/N4552/D5252 EPIC SBC B.4.4 Manual To restore the last system backup, please follow the steps below. Step 1: Type <4> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.

  • Page 137: C Terminology

    NANO-PV-D4252/N4552/D5252 EPIC SBC Appendix Terminology Page 123...
  • Page 138 NANO-PV-D4252/N4552/D5252 EPIC SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 139 NANO-PV-D4252/N4552/D5252 EPIC SBC memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module. EHCI The Enhanced Host Controller Interface (EHCI) specification is a register-level interface description for USB 2.0 Host Controllers.
  • Page 140 NANO-PV-D4252/N4552/D5252 EPIC SBC SATA Serial ATA (SATA) is a serial communications bus designed for data transfers between storage devices and the computer chipsets. The SATA bus has transfer speeds up to 1.5 Gbps and the SATA 3Gb/s bus has data transfer speeds of up to 3.0 Gbps.

  • Page 141: D Watchdog Timer

    NANO-PV-D4252/N4552/D5252 EPIC SBC Appendix Watchdog Timer Page 127...
  • Page 142 NANO-PV-D4252/N4552/D5252 EPIC SBC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 143 NANO-PV-D4252/N4552/D5252 EPIC SBC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30H ;time-out value is 48 seconds ;...

  • Page 144: E Hazardous Materials Disclosure

    NANO-PV-D4252/N4552/D5252 EPIC SBC Appendix Hazardous Materials Disclosure Page 130...

  • Page 145: Hazardous Material Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    NANO-PV-D4252/N4552/D5252 EPIC SBC E.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 146 NANO-PV-D4252/N4552/D5252 EPIC SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly X Fan Assembly Power Supply...
  • Page 147 NANO-PV-D4252/N4552/D5252 EPIC SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限 量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规...

This manual is also suitable for:

Nano-pv-n4552Nano-pv-d5252Nano-n4552Nano-pv-n4552-r10Nano-pv-d5252-r10Nano-pv-d4252-r10

Table of Contents
