Product Installation Guide
nterprise branch and head offices
NANO-PV-D5251
www.enochsystems.com
1-877-722-1116
sales@enochsystems.com
Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries.
Third-party trademarks mentioned are the property of their respective owners. All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology NANO-PV-D4251-R10
Summary of Contents for IEI Technology NANO-PV-D4251-R10
- Page 1 Product Installation Guide nterprise branch and head offices NANO-PV-D5251 www.enochsystems.com 1-877-722-1116 sales@enochsystems.com Copyright © 2013 Enoch Systems, LLC, Enoch Systems and the Enoch Systems logo are trademarks or registered trademarks of Enoch Systems, LLC and/or its affiliates in the U.S. and other countries. Third-party trademarks mentioned are the property of their respective owners.
- Page 2 1 x USB Cable 1 x Power Cable 1 x Audio Cable 1 x Mini Jumper Pack 1 x Driver CD 1 x One Key Recovery Utility CD 1 x QIG (Quick Installation Guide) ©2006 Copyright by IEI Technology corp. All rights reserved.
- Page 3 Specifications CPU: D425: Intel® Atom™ 45nm 1.8GHz Single Core Processor with 512KB L2 Cache D525: Intel® Atom™ 45nm 1.8GHz Dual Core Processor with 1MB L2 Cache N455: Intel® Atom™ 45nm 1.66GHz Single Core Processor with 512KB L2 Cache System Chipset: Intel ICH8M BIOS: UEFI BIOS System memory: One 204-pin 800MHz DDR3 SDRAM SO-DIMM supported (System max.
-
Page 4: Ordering Information
Ordering Information NANO-PV-D5251-R10: EPIC with Intel® Atom™ D525 1.8GHz, DDR3, VGA/LVDS, Dual GbE, USB2.0, CF II, Audio and SATA II, RoHS NANO-PV-D4251-R10: EPIC with Intel® Atom™D425 1.8GHz, DDR3, VGA/LVDS, Dual GbE, USB2.0, CFII, Audio and SATA II,RoHS NANO-PV-D4251-R10: EPIC with Intel® Atom™ N455 1.66GHz, DDR3, VGA/LVDS, Dual GbE, USB2.0, CFII, Audio and SATA II,RoHS... -
Page 5: Jumpers Setting
Jumpers setting LABEL FUNCTION J_AUTOPWR1 AT/ATX mode selection J_ATXCTL1 AT/ATX mode selection J_CMOS1 Clear CMOS J_VLVDS1 LCD Voltage Selection RS232/RS422 or RS485 Type Selection RS422/RS485 type selection RS422 terminal selection RS485 terminal selection JCF1 CF master/slave selection J_VCF1 CF Voltage selection PCI-104 voltage selection J_LCD_TYPE1 LVDS1 panel resolution selection... - Page 6 Compact Flash Master/Slave Function Selection. JCF1 DESCRIPTION Short Master Open (default) Slave (default) PIO_VCC:PCI-104 device voltage selection DESCRIPTION 2-3(default) 3.3V(default) CF voltage selection J_VCF1 DESCRIPTION 2-3(default) 3.3V(default) LCD Voltage Selection J_VLVDS1 DESCRIPTION 1 -2(default) 3.3V( default) 3 -4 5 -6 J_LCD_TYPE1 : LVDS1 panel resolution selection Resolution Open...
- Page 7 Table of Connectors LABEL FUNCTION 6 pin PS/2 KB/MS Connector KB/MS1 Internal KB/MS Connector COM1 COM 9pin Female Connector COM2,4,5 Internal Serial Pin Header (RS-232) COM3 Internal Serial Pin Header (RS-232/422/485) VGA1 VGA 15-pin Female Connector LAN1,2 RJ45 LAN Connectors AUDIO1 Audio Connector CPU12V1...
- Page 8 COM 2,COM4,COM5: Serial port connector.(PIN HEADER 2*5,10PIN,P:2.0mm) PIN NO DESCRIPTION PIN NO DESCRIPTION COM3 : Serial port connector.(PIN HEADER 2*7,14PIN,P:2.0MM) DESCRIPTION DESCRIPTION DCD3 DSR3 RXD3 RTS3 TXD3 CTS3 DTR3 RS422 TX2 +/485 RS422 TX2-/485 RS422 RX2+ RS422 RX2- KB_MS1: 6-pin Mini-DIN Keyboard Connector PIN NO.
- Page 9 VGA1: 15-pin Female Connector PIN NO. DESCRIPTION P IN NO. DESCRIPTION GREEN BLUE Display_ GND DDCDAT HSYNC VSYNC DDCCLK LAN1 ,2: RJ45 LAN Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0+ MDI2+ MDI0- MDI3- MDI1+ MDI3+ MDI1- LED 100M LED MDI2- LAN Active MDI2-...
- Page 10 AUDIO1: AUDIO Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Line out_R Line in_R Line out_L Line in_L MIC_R MIC_L CPU12V1: Power input connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EXT_12VIN EXT_12VIN SYS_FAN1:Fan Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION FANIO2 VCC12 CPU_FAN1:CPU Fan Connector PIN NO.
- Page 11 SMBCLK SMBDATA INT_SERIRQ VCC3S DIO 1 : 10-pin Digital I/O Connector. PIN NO DESCRIPTION PIN NO. DESCRIPTION VCC5S OUTPUT3 OUTPUT2 OUTPUT1 OUTPUT0 INPUT3 INPUT2 INPUT1 INPUT0 CN1：SMBUS CONNECTOR PIN NO. DESCRIPTION PIN NO. DESCRIPTION SDAT SCLK LVDS1 : LVDS LCD Connector. PIN NO.
- Page 12 LPT1: Parallel Port Connector DESCRIPTION DESCRIPTION PTD0 ERROR# PTD1 INITIALIZE PTD 2 SLIN PTD3 PTD 4 PTD 5 PTD 6 PTD7 BUSY SLCT INV1 : Inverter Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Brightness Adjust Backlight Power Backlight Enable SPI1 : SPI flash connector PIN HEADER 2*4,8PIN,180D,P:2.54MM PIN NO.
- Page 13 Board Layout: Dimensions (Unit: MM)
- Page 14 Board Layout: Jumper and Connector Locations...
- Page 15 Bottom Side： ： ： ：...
