NANO-PV-D4252/N4552/D5252 EPIC SBC
MODEL:
NANO-PV-D4252/N4552/D5252
EPIC Motherboard with Intel® Atom™ Processor
D425/N455/D525, VGA, Dual LVDS, GbE LAN, Eight USB 2.0,
Two SATA 3Gb/s, Four RS-232, RS-232/422/485, PCIe Mini,
PCI-104, RoHS

User Manual

Page i
Rev. 1.12 – November 10, 2015

Advertisement

Table of Contents
