Specification :
Technical Specification
Connectors
TV SCART
VCR SCART
Audio Output
Composite Video Output
S/PDIF
USB
RF Modulator
RS232C
General Characteristics
Supply Voltage
Power Consumption
LED Display
Weight
Dimensions
Channel Storage
Please Note : The specification of the STB may be changed without notice in advance.
41
CVBS, RGB,S-VIDEO, Audio L/R
CVBS, S-VIDEO,Audio L/R
2 x RCA/Cinch
1 x RCA/Cinch
1 x optic con. (Dolby Bitstream Out Available)
USB 2.0 Compatible (Device/B-type)
UHF I/O IEC male/female
CH21~CH69(PAL B/G/I/D/K)
9 Pin D-Sub RS232C serial port
100-250VAC, 50/60Hz
Max. 60W
4Digits (Yellow-Green)
2.44 Kg (without HDD : 0.4~0.6Kg)
350(W) x 270 (D) x 60 (H) mm
Each other Max. 4000 TV & Radio Channels
