Note:
The IP parameters should have been provided by your ISP.
IP Address - This is the WAN IP address as seen by external users on the Internet (including
your ISP). Enter the IP address into the field.
Subnet Mask - The Subnet Mask is used for the WAN IP address, it is usually
255.255.255.0.
Default Gateway - Enter the gateway IP address into the box if required.
Primary DNS - Enter the DNS Server IP address into the boxes if required.
Secondary DNS - If your ISP provides another DNS server, enter it into this field.
3. After you have completed the above, click Next, the Wireless settings page will appear as
below.
SSID - The SSID of the AP your Router is going to connect to as a client. You can also use the
TL-WR743ND 150Mbps Wireless AP/Client Router
Figure 3-9 Static IP
Figure 3-10 Wireless
