  • Page 1 ® Helios IP Vario Door Entry IP Intercom Installation Manual Version www.2n.cz  ...
  • Page 2 The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All development, production and distribution processes of the company are managed by this standard and guarantee a high quality, technical level and professional aspect of all our products.

  • Page 3: Table Of Contents

    Content 1. Product Overview ........4 1.1 Components and Associated Products  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  6  ...

  • Page 4: Product Overview

    Helios IP Vario can also be provided with RFID card reader modules. ® Helios IP Vario is very easy to install. All you have to do is connect the system into your LAN via a network cable and feed it from a 12 V power supply or your PoE supporting LAN.

  • Page 5: Advantages Of Use

    ® Manager to manage extensive Helios IP Vario systems easily and quickly. Advantages of Use Bidirectional communication – acoustic echo cancelling Integrated colour camera Optional dial buttons including name tags with backlight Optional numerical keypad with backlight Integrated electronic lock switches with wide setting options...

  • Page 6: Components And Associated Products

    9137160(C)KDU 9137111(C)KU 9137131(C)KU 9137161(C)KU Basic unit Basic unit Basic unit Basic unit 3× 2 buttons 1 button 3 buttons 3× 2 buttons + keypad + keypad + keypad + keypad + display (C) = integrated camera ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 7: Extending Modules

    Part No. 9135302E Spare double-button name plate All units can be surface mounted without needing any additional accessories. To make them even more robust and resistant, use a Vandal Resistant mask. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 8 Caution For flush or outdoor mounting you need to use the accessories; see the Mounting Accessories subsection. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 9: Mounting Accessories

    × 46) mm (W × H × D) 240 × 41) mm (W × H × D) × 60) mm (W × H × D) Wall hole: (110 × 220 × Wall hole: (110 × 220 × 50) ±5 mm 50) ±5 mm ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 10: Voip Telephones

    The box with ® frame (without roof) allows for installation of Helios IP Vario in indoor applications so that the unit does not practically stick out (up to 1 mm).

  • Page 11: Power Supply

    91341481E 91378100E Part No. Adapter 12 V / 2 A Part No. 932928E A stabilised power supply has to be used if the 91378100US 12 V transformer Ethernet (PoE) power supply is not available. PoE injector ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 12: Additional Modules

    Internal RFID card External RFID card Additional appliance control, normally ® reader for PC reader for 2N open/closed contact option, connection via USB Helios IP Vario time-unlimited connection, up to 48 V / interface unting 2 A. Part No. 9159010 Part No.

  • Page 13: Terms And Symbols

    Warning Always abide by this information to prevent damage to the device. Caution Important information for system functionality. Useful information for quick and efficient functionality. Note Routines or advice for efficient use of the device. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 14: Description And Installation

    2. Description and Installation Here is what you can find in this section: 2.1 Before You Start 2.2 Mechanical Installation 2.3 Electric Installation 2.4 Completion 2.5 Extending Module Connection ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 15: Before You Start

    2.1 Before You Start Product Completeness Check ® Before you start please check whether the contents of the package of your new 2N Helios IP Vario complies with the following list. ® 1× 2N Helios IP Vario 1× spare seal 1×...

  • Page 16: Mechanical Installation

    2.2 Mechanical Installation Overview of Installation Types An overview of the installation types and the list of the required components are provided in the table below. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 17 Installation Symbol What you need for installation type Indoor, on ® Helios IP Vario only surface Indoor, ® Helios IP Vario flush Box with 1-module frame 9135351E mounting Box with 2-module frame 9135352E ® Helios IP Vario Outdoor, Surface 1-module roof...

  • Page 18: Surface Mounting

    Helios IP Vario supply. Insert the included dowels in the wall holes. ® Use the hexagonal wrench included in the supply and remove the 2N Helios IP Vario metal cover. Remove the screw in the lower part of the metal cover and fold out the cover.
  • Page 19 (Ethernet, lock, power cables) to the basic module box through one of the holes. Warning ® Make sure that the mounting surface for the 2N Helios IP Vario door communicator is perfectly flat. Avoid mechanical overload upon the bottom part of the cover. An incorrect installation on an uneven surface may lead to cover deformation and thus product malfunctions.
  • Page 20 Connect the cables as described in subsection 2.4, Mounting – Electrical Installation. Make sure that the cables are not squeezed while installing the plastic cover. For the correct cable installation. ® Remove the protective foil from the display (for display-equipped 2N Helios IP Vario versions only).

  • Page 21: Flush Mounting

    Name tag material and printing ® Each Helios IP Vario package includes a sheet of transparent foil for laser printing. Cut the printed foil into pieces and insert the labels in the name plates. Do not use paper to avoid water in-leak and paper damage.
  • Page 22 The product is not designed as a burglar protection device except when used in combination with a standard lock, which has the security function. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 23: Electric Installation

    (10/100BASE-T) using a UTP cable. Use a CAT 5e UTP cable at least for connection. ® Helios IP Vario is fed through the PoE (Power over Ethernet) technology. No additional cabling is therefore necessary. If your Ethernet is not equipped with the PoE technology, it is possible to use a PoE injector, Part No.
  • Page 24 Figure: Description of Connectors, PCB Versions 535v1, 535v2 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 25 12 V / 2 A DC power supply if no PoE power supply is available. ® The terminal block is included in the package. To adjust an already installed 2N Helios IP Vario , disconnect it IP from the power supply. Then pull to remove the terminal block from the printed circuit board.

  • Page 26: Electric Lock Connection

    Ethernet Connection For the connections and meanings of the wires see the table below. Join UTP cable ® wires 4 (blue) and 5 (white-blue) and attach them under terminal 6 on 2N Helios IP ® Vario In the same way, join wires 7 and 8 and place them under terminal 5 of...

  • Page 27: Configuration Connector Connection

    External Power Supply Connection If the Ethernet network is not equipped with the PoE technology, you have two ® alternative options how to supply power to Helios IP Vario ® Using a PoE injector, Part No. 91378100. Helios IP Vario is then powered through an Ethernet cable as shown in Tab.
  • Page 28 Figure: Connection of Configuration Connector Jumpers Display Connector The display connector includes the name plate backlighting ON/OFF switching pins and ® Helios IP Vario resetting pins. The remaining pins are intended for display connection. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 29 Resetting procedure ® Switch Helios IP Vario off. Connect the jumper into the resetting (default setting) position (put the display switch into the F_RES position in the display-equipped models with 535v1 and 535v2 board versions). ® Switch Helios IP Vario on and wait for the acoustic start signalling.

  • Page 30: Card Reader Connection

    535v1 and 535v2 only. For 535v5 versions, use a jumper at connector X13. Card Reader Connection ® Helios IP Vario (Part Nos. 91371…U) can be equipped with an internal multifunction module including an RFID card reader (Part No. 9137430E). This module ® enhances the...
  • Page 31 ® Use the enclosed screws to fix the reader module to the 2N Helios IP Vario plastic base. Connect the wires for the reader module interface(s) if necessary.

  • Page 32: Completion

    2.4 Completion ® Remember to seal the Helios IP Vario cable passage hole properly to avoid moisture in-leak and damage to electronics due to condensation. ® Make sure that the wires inside Helios IP Vario are not squeezed and insert the plastic top cover (a transparent plastic mould) carefully making its contacts plug into the electronics board connectors.
  • Page 33 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 34 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 35: Extending Module Connection

    Extending button modules ® Helios IP Vario features an easy installation of extending button modules. Extending modules are connected using a single cable (included in every extender delivery) in a chain pattern (every additional unit is connected with the previous one).

  • Page 36: Maximum Count Of Extenders

    (see subsection 2.3 Mounting – Mechanical Installation). Figure 2.16 Connection of Two-Button-Row Extending Module Caution The extending modules must be connected mutually and with the basic unit by means of a formed piece supplied with the extending module!!! ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 37: Button Numbering

    Button Numbering Button numbering – one-button with a whole-button set Button numbering – whole-button sets ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 38 ) is used to extend the Helios IP ® Vario door communicator with another switch. Helios IP Vario Additional Switch is suitable for e.g. electric door lock or low voltage logical inputs of e.g. gate and barrier control systems. ®...

  • Page 39: Specifications

    Function: ® ® Helios IP Vario Additional Switch adds one additional switch to the Helios IP Vario basic unit. Specifications: Passive switch: NO and NC contacts, up to 30 V / 1 A AC/DC Caution Before installing the module, make sure that the current and voltage limits of the module will not be exceeded in your application (refer to the Technical Parameters chapter).
  • Page 40 Internal RFID Card Reader 125 kHz The Internal RFID Card Reader (Part No. 9137430 E) is used for reading RFID card ® Ids in the 125 kHz band. This module is intended for mounting into the 2N Helios IP Vario model 91371..U.
  • Page 41 ® Compatible with EM4100 / EM4102 / HID Prox RFID cards Working frequency: 125 KHz ® Minimum reading distance: 10 mm above Helios IP Vario cover Relay outputs Switching contact 30V / 1A AC / DC Logical inputs Active mode – requires external voltage (JP2 jumper OFF) = min +2.5 V...
  • Page 42 ® Use the enclosed screws to fix the reader module to the 2N Helios IP Vario plastic base. Connect the wires for the reader module interface(s) if necessary.
  • Page 43 Helios IP Security Relay is a device installed between an intercom (outside ® the secured area) and the electric lock (inside the secured area). The 2N Helios IP Security Relay includes a relay that can only be activated if the valid opening code is...
  • Page 44 ® Helios IP Wiegand Isolator is designed for galvanic isolation of two ® devices with separate power supply and interconnected via the Wiegand bus. The 2N Helios IP Wiegand Isolator protects the interconnected devices against communication errors and/or damage. ®...
  • Page 45 Open LED OUT switched against GND on WIEGAND IN side (up to 24 V / 50 mA) 5 to 16V / 10 mA power supply from Wiegand bus receiver side 500 V DC isolation strength Connection: ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 46 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 47: Function And Use

    3. Function and Use ® This section describes the basic and extending functions of the the 2N Helios IP Vario product. Here is what you can find in this section: 3.1 Configuration 3.2 Intercom Control as Viewed by External User 3.3 Display-Equipped Intercom as Viewed by External User...

  • Page 48: Configuration

    3.1 Configuration ® Use a PC equipped with any web browser to configure Helios IP Vario Launch your web browser (Internet Explorer, Firefox, etc.). Enter the IP address of your intercom (http://192.168.1.100/, e.g.). Log in using the Admin user name and password.
  • Page 49 6-buttons models: Press the fifth quick dial button on the basic unit five times. ® Helios IP Vario will read its IP address. If the address is 0.0.0.0, it means that the intercom has not obtained the IP address from the DHCP server.
  • Page 50 The inter-digit delay may be 2 s at most. The device will have the following network parameters after restart: IP address – 192.168.1.100 Network mask – 255.255.255.0 Default gateway – 192.168.1.1 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 51 The 2, 1, 1, 2, 2, 3 sequence must be entered within 30 seconds after the first sound signal for security reasons. The inter-digit delay may be 2 s at most. ® Helios IP Vario gets the IP address upon restart only if the DHCP server is configured properly. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 52 Mode Switching with 1-Button Models ® In case your Helios IP Vario device is equipped with 1 button, you can switch the modes using one button only. ® Connect Helios IP Vario to the power supply (or, disconnect and reconnect it if already connected).

  • Page 53: Intercom Control As Viewed By External User

    Configuration Manual. Calling to Phone Book Position ® Helios IP Vario telephone directory may contain up to 1999 pre-programmed positions. You can use the quick dialling buttons for positions 1 to 54 only. To retrieve the remaining positions, use the numeric keypad if Dial Users by Phonebook Position is enabled;...

  • Page 54: Incoming Call Answer And Reject

    Code Door Opening (Switch Activation) ® Helios IP Vario is equipped with a door unlocking switch. To activate the switch enter the valid code (refer to the Intercom Configuration / Hardware / Switches subsection of Configuration Manual ) on the numeric keypad.
  • Page 55 An invalid code is announced by acoustic signalling ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 56: Display-Equipped Intercom As Viewed By External User

    ® Until the display program is uploaded to Helios IP Vario , the display shows the following text: 2N Helios IP display is not configured ; refer to the figure below. In ® this state, Helios IP Vario behaves and is controlled like no-display models, see ®...

  • Page 57: Calling To Number

    6 to switch on the phone directory searching mode. To retrieve a text, use the numeric keypad. The text to be searched is displayed in the centre of the status line. To delete the last character push the quick dialling button 3. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 58: Status Information

    To browse through the contacts found and select the required one, push the quick dialling button 6, thus recovering the arrow function of the numeric keypad. Status Information ® In addition to the above described modes, the Helios IP Vario display indicates various device statuses: Call being set up Ringing – outgoing call...

  • Page 59: Intercom Control As Viewed By Internal User

    Calling to Helios IP Vario ® Helios IP Vario allows to answer an incoming call too. To set the required parameters use the Incoming calls item, refer to the Intercom Configuration / Services / Phone / Calls subsection of Configuration Manual Code Door Opening (Switch Activation) ®...

  • Page 60: Profile Activation And Deactivation

    Enter the profile activation or deactivation code using the numeric keypad and push for confirmation. A valid code is announced by acoustic signalling depending on the code type. An invalid code is announced by acoustic signalling ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 61: Maintenance

    The manufacturer reserves the right to modify the product in order to improve its qualities. ® Helios IP Vario contains no environmentally harmful components. When the product's service life is exhausted and you would like to dispose of it please do so in accordance with applicable legal regulations.

  • Page 62: Technical Parameters

    Full duplex: Yes (AEC) Audio stream Protocols: RTP/RTSP Codecs: G.711, G.729 Camera Sensor: 1/4'' colour CMOS Resolution: 640 (H) x 480 (V) Picture frequency: Up to 30 snaps/s Sensitivity: 1.9 V/lux-sec (550 nm) Viewing angle: 55° (H), 39° (V) ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 63: Rfid Card Reader

    Working relative humidity: 10 % – 95 % (non-condensing) Storing temperature: − 40 °C to 70 °C Dimensions: 210 × 100 × 29 mm Weight: 500 g Covering level: IP53 when the roof is used (see Mounting Accessories) ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 64: Supplementary Information

    5. Supplementary Information Here is what you can find in this section: 5.1 Troubleshooting 5.2 Directives, Laws and Regulations 5.3 General Instructions and Cautions ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 65: Troubleshooting

    5.1 Troubleshooting For the most frequently asked questions refer to faq.2n.cz ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 66: Directives, Laws And Regulations

    5.2 Directives, Laws and Regulations Europe ® Helios IP Vario conforms to the following directives and regulations: Directive 1999/5/EC of the European Parliament and of the Council, of 9 March 1999 – on radio equipment and telecommunications terminal equipment and the mutual...
  • Page 67 Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 68: General Instructions And Cautions

    The manufacturer also assumes no responsibility for additional costs incurred by the consumer as a result of making calls using a line with an increased tariff. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 69: Electric Waste And Used Battery Pack Handling

    Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 70 2N TELEKOMUNIKACE a.s. Modřanská 621, 143 01 Prague 4, Czech Republic Phone: +420 261 301 500, Fax: +420 261 301 599 E-mail: sales@2n.cz Web: www.2n.cz EN1777_v2.0.1 ® TELEKOMUNIKACE a.s., www.2n.cz...
