COMMAND 54 - Read Transmitter Variable Information

Description
This command gets information about any selected transmitter variable sensor.
Write Parameters
Word High Byte
0 Transmitter Variable Code
Floating Point Data Returned
Word High Byte
0 Transmitter Variable Upper Limit
1
2 Transmitter Variable Lower Limit
3
4 Transmitter Variable Damping Value (Sec)
5
Integer Data Returned
Word High Byte
0 STATUS WORD
1 Transmitter Variable Code
1 Sensor Serial Number 1
2 Unit Code for Limits
Page 76 of 104
ProLinx-HART ♦ ProLinx Gateway
Low Byte
Transmitter Variable Code
Low Byte
Low Byte
Sensor Serial Number 0
Sensor Serial Number 2
0
HART Master with Analog I/O
