COMMAND 15 - Read Output Information

Description
This command gets information about the Primary Variable Output Information.
Write Parameters
NONE
Floating Point Data Returned
Word High Byte
0 Upper Range Value
1
2 Lower Range Value
3
4 Damping Value (Sec)
5
Integer Data Returned
Word High Byte
0 STATUS WORD
1 Alarm Select Code
2 Primary Variable Range Units Code
2 Private-Label Distributor Code
Page 50 of 104
ProLinx-HART ♦ ProLinx Gateway
Low Byte
Low Byte
Transfer Function Code
Write-Protect Code
0
