Package Contents - ProSoft Technology ProLinx-HART Driver Manual

ProLinx-HART ♦ ProLinx Gateway
HART Master with Analog I/O
1.2

Package Contents

The following components are included with your ProLinx-HART module, and are all
required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following
items are present.
Qty. Part Name
1 ProLinx-HART
module
1 Cable
Varies
Cable
Varies Adapter
1 ProSoft Solutions CD
If any of these components are missing, please contact ProSoft Technology Support for
replacements.
ProSoft Technology, Inc.
October 13, 2011
Part Number Part Description
PLX-#### ProLinx communication gateway
Cable #15, RS232 For RS232 Connection from a PC to the
Null Modem CFG Port of the module
Cable #9, Mini- For DB9 Connection to module's Port. One
DIN8 to DB9 Male DIN to DB-9M cable included per
Adapter configurable serial port, plus one for module
configuration
1454-9F Adapters, DB9 Female to Screw Terminal.
For RS422 or RS485 Connections to each
serial application port of the module
Contains sample programs, utilities and
documentation for the ProLinx-HART
module.
Start Here
Driver Manual
