■ Specifi cations
D General
• Frequency range
U.S.A.
Europe
• Type of emission
• Frequency stability
• Frequency resolutions
• Antenna connector
• Communication speed
• Power supply requirement
• Current drain
• Usable temperature range
• Dimensions
(proj. not incl.)
• Weight
(approx.)
D Transmitter
• Tx output power
(at 13.8 V DC)
• Modulation system
• Occupied bandwidth
• Spurious emissions
D Receiver
• Receive system
• Intermediate frequencies
• Sensitivity
(BER 1×10
• Adjacent channel selectivity
• Intermodulation rejection ratio
• Receive spurious
• Spurious and image rejection ratio

■ System units

ID-RP2D*
DATA REPEATER
1.2 GH
Z
ID-RP2V*
DIGITAL VOICE REPEATER
1.2 GH
Z
ID-RP2L*
MICROWAVE LINK REPEATER
10 GH
Z
ID-RP4000V
UHF DIGITAL VOICE REPEATER
AH-106*
PARABOLIC ANTENNA
10 GH
Z
AH-107*
PARABOLIC ANTENNA
10 GH
Z
AH-108*
COLLINEAR ANTENNA
1.2 GH
Z

SPECIFICATIONS AND SYSTEM UNITS

:
Tx/Rx
Tx/Rx
: F1D
: ±0.3 kHz
: 5/6.25 kHz
: Type-N
: 4.8 kbps
: 13.8 V DC ±15%
: Tx
Tx
Rx Stand-by Less then 0.7 A
: –10˚C to +50˚C; +14˚F to +122˚F
: 483(W)×88(H)×428(D) mm; 19(W)×3
: 7.5 kg; 16 lb 9 oz
: High
Low
: QPSK
: Less than 5.5 kHz
: Less than –60dB
: Double-conversion superheterodyne
: 1st
2nd
–2 : Less than 0.45 µV
)
: More than 65 dB
: More than 65 dB
: Less than –57 dBm
: More than 70 dB
(800 (d))
(450 (d))
144 to 148 MHz
144 to 146 MHz
(GMSK; F7W for system operation)
(based on +25˚C; +77˚F)
(impedance: 50 Ω)
(negative ground)
Less than 7.0 A
(High)
Less than 3.0 A
(Low)
23–30 W
2–3 W
(244.8 MHz)
46.35 MHz
450 kHz
(20 kHz offset)
(±20 kHz/±40 kHz)
All stated specifi cations are subject to change without notice or obligation.
*Not available in European countries as of May 2008.
32
15 27
⁄ (H)×16 ⁄ (D) in.
32 32
8
