1.2 Typical System Installation

The Singlewire-enabled Voice-over-IP (VoIP) VoIP Indoor Intercom is a SIP endpoint designed to
provide VoIP phone connectivity in a tamper proof and secure package.
Figure 1-2
Door Strike
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
illustrates how the VoIP Indoor Intercom can be installed as part of a VoIP phone system.
Figure 1-2. Typical Installation—Door Entry/Access Control
Generic PoE Switch
1 2 3
VoIP Intercom
VoIP Intercom
930943A
4 5 6
IP Phone
Product Overview 2
Typical System Installation
Informacast Server
CyberData Corporation
