Chapter 4
Focusing
1. If you are using WinView/32 (or WinSpec/32 in Imaging Mode) and the computer
monitor for focusing, select
present, will open and successive images will be sent to the monitor as quickly as
they are acquired. Because the time to acquire and read out an image varies directly
with the size of the CCD, the observed frame rate will vary greatly depending on the
CCD installed. With a short exposure time, it is not uncommon for the frame readout
time to be significantly longer than the exposure time.
will light and there will be a locked indication at the computer monitor,
indicating that temperature lock has been established. Note that some
overshoot may occur. This could cause temperature lock to be briefly lost
and then quickly re-established. If you are reading the actual temperature
reported by the application software, there may be a small difference
between the set and reported temperature when lock is established. This is
normal and does not indicate a system malfunction. Once lock is established,
the temperature will be stable to within ±0.05°C.
Note: If you are using the USB 2.0 interface, the Detector Temperature
dialog box will not display temperature information while you are acquiring
data.
Interface tab page (Setup|Hardware): High Speed PCI (or PCI(Timer))
Note: This tab page is not available if you are using the USB 2.0 interface.
Cleans and Skips tab page (Setup|Hardware): Default
Experiment Setup Main tab page (Acquisition|Experiment Setup...):
•
Exposure Time: 100 ms
•
Accumulations & Number of Images: 1
Experiment Setup ROI tab page (Acquisition|Experiment Setup...):
Use this function to define the region of interest (ROI).
•
Imaging Mode: Selected if you are using WinSpec/32.
•
Clicking on Full loads the full size of the chip into the edit boxes.
•
Clicking on Store will store the Pattern so it can be reused at another
time.
Experiment Setup Timing tab page (Acquisition|Experiment Setup...):
•
Timing Mode: Free Run
•
Shutter Control: Normal
•
Safe Mode vs. Fast Mode: Safe
Acquisition Menu: Select
video monitor to the system and plan to use it for focusing or other operations. There
will be a check next to "
Operation
if you have connected an RS-170 (or a CCIR)
Video
" to indicate that it is selected
Video
from the Acquisition menu. The shutter, if
Focus
43
