Chapter 3
4. Select the Hardware tab and click on Device Manager button.
5. Expand Universal Serial Bus Controllers.
6. Right-mouse click on OrangeUSB USB 2.0 Host Controller and select
7. On the Driver tab, click on the Update Driver... button. You may have to wait
8. When the Upgrade Device Driver Wizard appears, click on Next. Select the
9. On the next screen select the Specify a location checkbox.
10. Browse and select the location. Click on OK.
11. In the Driver Files Search Results window, check the Install one of the other
12. Select the NEC PCI to USB Enhanced Host Controller B1 driver. Click on
To Install the Princeton Instruments USB2 Interface:
Properties.
a minute or so before you will be allowed to click on the button.
Search for a suitable driver ... radio button.
drivers check box.
Next and the installation will take place. When the Completing the Upgrade
Device Driver Wizard window appears, click on Finish. You will then be given
the choice of restarting the computer now or later. According to the window text,
the hardware associated with the driver will not work until you restart the
computer.
The following information assumes that:
•
You have verified that the host computer meets the required specifications
for USB 2.0 communication with the MicroMAX system (see page 20).
•
A USB 2.0 board and its driver are installed in the host computer.
•
The ST-133 has an installed USB 2.0 Interface Control module.
•
You have already installed the WinView/32 or WinSpec/32 software
(versions 2.5.15 and higher). Versions 2.5.15 and higher automatically
install the driver and INF files required to support the USB 2.0 Interface
Control module.
1. Before installing the Princeton Instruments USB2 Interface, we recommend
that you defragment the host computer's hard disk. This operation reduces the
time the computer spends locating files. Typically, the "defrag" utility "Disk
Defragmenter" can be accessed from the Windows
usually accessed from the Programs/Accessories/System Tools subdirectory.
2. After defragmenting the hard disk, turn off the computer and make the USB
cable connections between the host computer and the ST-133. Then, turn the
ST-133 on before turning on the host computer.
3. At bootup, Windows will detect the Princeton Instruments USB2 Interface
hardware (i.e., the USB 2.0 Interface Control module). You may be prompted
to enter the directory path(s) for the apausbprop.dll and/or the apausb.sys
file(s), either by keyboard entry or by using the browse function.
If you selected AUTO PCI during the application software installation,
WinView/32 automatically put the required INF, DLL, and USB driver file in
System Setup
®
Start menu and can
