To Install a Module:
Installing a module is a bit more complex because you first have to be sure the locking
screws are aligned correctly. The following procedure is suggested.
1. Verify that the Controller has been turned OFF.
2. Remove the replacement module from its antistatic packaging. This packaging is
3. Rotate the two locking screws counterclockwise until the threads on the screws
4. Insert the module so that the top and bottom edges of the board are riding in the
5. Gently but firmly push the module in until the 64-pin DIN connector at the back
6. Rotate the two locking screws clockwise. As the screws are rotated, they will
WARNING!
Tighten the screws to where they are just snug. Do not tighten them any further because
you could easily bend the mating bracket.

Shutter Malfunctions

MicroMAX System User Manual
designed to protect the module components from electrostatic discharge.
engage those of the module panel. See Figure 60. By doing this, the screws will
be perfectly perpendicular to the module panel and will align perfectly when the
module is inserted.
proper guides.
of the module mates with the corresponding connector on the backplane, leaving
the module panel resting against the controller back panel.
first disengage from the module panel threads, and then begin to engage those of
the bracket behind the controller panel.
•
Verify that the correct shutter setting has been selected on the rear of the
Controller. Refer to Table 13 on page 97.
•
If you are using a 25 mm remote-mounted shutter and it suddenly stops
running, its built-in thermal interlock may have been triggered. Stop the
experiment and wait. The shutter should resume functioning when it has
cooled down sufficiently, typically within an hour. Avoid repeating the
conditions (such as high repetition rate) that lead to the shutter overheating,
or take breaks between data collections.
•
If the shutter no longer operates at all, sticks open or closed causing
overexposed or smeared images, or a shutter leaf has broken and no longer
actuates, contact the factory to arrange for a shutter-replacement repair.
