  • Page 1 Flat Stainless Panel PC Intel® Atom ™ N2600 1.6 GHz Full IP65 R15ID3S-65A1FTE R15ID3S-65A1FTP User Manual Version 1.0...

  • Page 2: Preface

    Warranty Winmate Inc. warranty guarantees that each of its products will be free from material and workmanship defects for a period of one year from the invoice date. If the customer discovers a defect, we will, at his/her option, repair or replace the defective product at no charge to the customer, provide it is returned during the warranty period of one year, with transportation charges prepaid.
  • Page 3 USER MANUAL PREFACE Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
  • Page 4 USER MANUAL PREFACE Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.

  • Page 5: Safety Information

    USER MANUAL PREFACE Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
  • Page 6 USER MANUAL PREFACE Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference.  Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. ...
  • Page 7 USER MANUAL PREFACE CAUTION/ATTENTION Use the recommended mounting apparatus to avoid risk of injury. Utiliser l’appareil de fixation recommandé pour éliminer le risque de blessure. WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer.

  • Page 8: Important Information

    USER MANUAL PREFACE Important Information Countries/ Area Symbol This equipment complies with essential requirements of: Electromagnetic Compatibility Directive(2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous European Union substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules.
  • Page 9 USER MANUAL PREFACE European Union This equipment is in conformity with the requirement of the following EU legislations and harmonized standards. Product also complies with the Council directions. Electromagnetic Compatibility Directive (2014/30/EU) 1. EN55024: 2010/ A1: 2015 a. IEC61000-4-2: 2009 b.

  • Page 11: About This User Manual

    ABOUT THIS USER MANUAL ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® IP65 Flat Stainless Panel PC with Intel® Atom ™ N2600 1.6 GHz processor. This User Manual applies to the IP65 Flat Stainless Panel PC – R15ID3S-65A1FTE, R15ID3S-65A1FTP.

  • Page 12: Table Of Contents

    USER MANUAL CONTENTS CONTENTS PREFACE ......................... ii ABOUT THIS USER MANUAL ..................... i CHAPTER 1: INTRODUCTION .................... 2 1.1 Product Features ....................2 1.2 Package Content ....................3 1.3 Description of Parts....................4 1.3.1 Front View ....................4 1.3.2 Side and Rear Views ..................4 1.3.3 Dimensions ....................
  • Page 13 6.3.2 Rear Mounting ................... 70 CHAPTER 7: TECHNICAL SUPPORT .................. 73 7.1 Software Developer Support ................73 7.1.1 Winmate Download Center ............... 73 7.1.2 Winmate File Share ................... 73 7.2 Problem Report Form ..................74 APPENDIX A: PRODUCT SPECIFICATIONS ............... 76 APPENDIX B: ORDERING INFORMATION ................
  • Page 15 USER MANUAL CHAPTER 1 INTRODUCTION INTRODUCTION This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the device in the packing list. Mechanical dimensions and drawings included in this chapter. IP65 FLAT STAINLESS PANEL PC...

  • Page 16: Chapter 1: Introduction

    INTRODUCTION CHAPTER 1: INTRODUCTION Winmate® IP65 Flat Stainless Panel PC is rugged, industrial-grade panel PC series built to withstand challenging environments, undergoing rigorous testing to ensure safety and top performance. All of the models in the series are sealed to IP65 standard. Stainless housing features anti-corrosion properties making it suitable for food, chemical and pharmaceutical industries.

  • Page 17: Package Content

    User Manual Chapter 1 Introduction 1.2 Package Content Carefully remove the box and unpack your Panel PC. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately.

  • Page 18: Description Of Parts

    USER MANUAL CHAPTER 1 INTRODUCTION 1.3 Description of Parts This section contains mechanical drawing of the Panel PC. Notice that this is a simplified drawing and some components are not marked in detail. 1.3.1 Front View 1.3.2 Side and Rear Views IP65 FLAT STAINLESS PANEL PC...

  • Page 19: Dimensions

    User Manual Chapter 1 Introduction 1.3.3 Dimensions Unit: mm Dimensions: 396 x 310 x 49 mm 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators located on the rear side of the Panel PC. Physical Buttons Icon Button Description Reset Press to reset the system...

  • Page 20: Led Indicators

    USER MANUAL CHAPTER 1 INTRODUCTION LED Indicators LED Type Status Description Power is on Power is off Blinking Storage activity (Data is being read or written) System is idle IP65 FLAT STAINLESS PANEL PC...

  • Page 21: Getting Started

    USER MANUAL CHAPTER 2 GETTING STARTED GETTING STARTED This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. IP65 FLAT STAINLESS PANEL PC...

  • Page 22: Chapter 2: Getting Started

    USER MANUAL CHAPTER 2 GETTING STARTED CHAPTER 2: GETTING STARTED This chapter provides information on how to connect the Panel PC to the source of power, connector pinouts and the guideline to turn on/off the Panel PC. 2.1 Turning On Remove the protective cap of the DC IN jack.

  • Page 23: Installation

    User Manual Chapter 2 Getting Started 2.2 Installation 2.2.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 24: Connecting The Interface

    USER MANUAL CHAPTER 2 GETTING STARTED 2.2.2 Connecting the Interface This Panel PC comes with various interfaces located on the bottom panel. All of these connectors have been shipped with protective caps. To ensure the waterproof function can work properly, make sure that the protective caps have been securely fastened whenever the connectors are not used.

  • Page 25: Connecting To Other Devices

    User Manual Chapter 2 Getting Started 2.2.3 Connecting to Other Devices Perform the connections as shown below. IP65 Flat Stainless Panel PC...

  • Page 26: Connector Pin Assignments

    USER MANUAL CHAPTER 2 GETTING STARTED 2.2.4 Connector Pin Assignments This Panel PC is equipped with four connectors which are IP65 level and fool-proofing design. Use only the cables that are included in the package. The pin assignments of the cables are as follows.
  • Page 27 User Manual Chapter 2 Getting Started 2.2.4.2 Serial Cable The Flat Stainless Panel PC has IP65 serial port connector. Use serial cable to connect serial interfaces. IP65 Flat Stainless Panel PC...
  • Page 28 USER MANUAL CHAPTER 2 GETTING STARTED 2.2.4.3 Ethernet Cable The Flat Stainless Panel PC has IP65 Ethernet connector. Use Ethernet cable to connect the Panel PC to the Internet. IP65 FLAT STAINLESS PANEL PC...
  • Page 29 User Manual Chapter 2 Getting Started 2.2.4.4 USB 2.0 Cable Flat Stainless Panel PC has one Full IP65 USB2.0 connector. Use USB2.0 cable to connect external devices such as mouse or keyboard to the Panel PC. IP65 Flat Stainless Panel PC...
  • Page 30 USER MANUAL CHAPTER 3 OPERATING THE DEVICE OPERATING THE DEVICE This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. IP65 FLAT STAINLESS PANEL PC...

  • Page 31: Chapter 3: Operating The Device

    USER MANUAL CHAPTER 3 OPERATING THE DEVICE CHAPTER 3: OPERATING THE DEVICE In this chapter you will find instructions on how to operate the Panel PC with Hot Tab. 3.1 Operating System Flat Stainless Panel PC support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 7 Pro for Embedded Systems, and Windows Embedded Standard 7 –...

  • Page 32: Multi-Touch

    User Manual Chapter 3 Operating the Device 3.2 Multi-Touch The P-CAP touchpad supports the core gestures for Windows. Gesture Windows Gesture Action Action Usage Tap/ Click / Click or double-click Double-tap Double-click Panning Scrolling Drag one or two with Inertia fingers up and down Selection/D...

  • Page 33: How To Enable Watchdog

    USER MANUAL CHAPTER 3 OPERATING THE DEVICE 3.3 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center File Share.
  • Page 34 User Manual Chapter 3 Operating the Device Settings Description The system automaticity restarts when this countdown time reaches zero. Watchdog Countdown Time Default: 10 min To set a cycle time to automatically reset watchdog timer. Periodically Feed Time Default: 9 min IP65 FLAT STAINLESS PANEL PC...

  • Page 35: Ami Bios Setup

    USER MANUAL CHAPTER 4 AMI BIOS SETUP AMI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.

  • Page 36: Chapter 4: Ami Bios Setup

    USER MANUAL CHAPTER 4 AMI BIOS SETUP CHAPTER 4: AMI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.
  • Page 37 USER MANUAL CHAPTER 4 AMI BIOS SETUP The following Keys can be used after entering the BIOS Setup. Function General Help Previous Values Optimized Defaults Save & Exit Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓...

  • Page 38: Bios Functions

    USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2 BIOS Functions This computer has AMI BIOS built-in and a CMOS SETUP utility that allow users to configure required settings or to activate certain system features. The follwoing sections describe the configuration options found in the menu items. 4.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.
  • Page 39 USER MANUAL CHAPTER 4 AMI BIOS SETUP BIOS Setting Description Setting Option Effect System Displays the system Adjustment of the Set the language in Language language. [English] is language other language. The set up by default. language in this device is English. System This is current date Date and time...

  • Page 40: Advanced Menu

    USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. CAUTION Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer.
  • Page 41 USER MANUAL CHAPTER 4 AMI BIOS SETUP BIOS Setting Description Setting Option Effect Launch PXE Control Launch PXE Enabled Load PXE Option OpROM OpROM ROMs. parameters. *Disabled Ignore all PXE Option ROMs. To limit the PXE support to particular devices, the function Use device for PXE.
  • Page 42 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.1 PCI Subsystem Settings IP65 FLAT STAINLESS PANEL PC...
  • Page 43 USER MANUAL CHAPTER 4 AMI BIOS SETUP BIOS Setting Description Setting Option Effect PCI ROM Priority Selects the PCI Legacy ROM Launches Legacy Option ROM to launch in case EFI Compatible Launches EFI Multiple Option Compatible ROM ROMs PCI Latency Timer Use this function to *32/64/96/128/16 Program the PCI...
  • Page 44 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.2 ACPI Settings *Default BIOS Setting Description Setting Option Effect Enable ACPI Auto BIOS ACPI Auto Enable/ *Disable Enables or Disables Configuration Configuration this function Enable Hibernation Control Enable/ Disable Enables or Disables hibernation.
  • Page 45 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.3 S5 RTC Wake Settings You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
  • Page 46 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.4 CPU Configuration BIOS Setting Description Setting Option Effect Hyper-Threading Enables for Enable/ Enables or disables Windows XP and Disable Hyper-Threading Linux (optimized Technology for Hyper- Threading Technology) and Disabled for other OS (not optimized for Hyper- Threading Technology)
  • Page 47 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.5 SATA Configuration BIOS Setting Description Setting Effect Option SATA Controller SATA Ports (0-3) Device Enable/ Enables or Names if Present and Disable Disables SATA Enabled Ports (0-3) Configure SATA Allows users to select mode ACHI Work in AHCI of SATA controller(s).
  • Page 48 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.6 iFFS Support BIOS Setting Description Setting Option Effect iFFS Support Control iFFS Enable/ Enables or Support Disable Disables this parameters function IP65 FLAT STAINLESS PANEL PC...
  • Page 49 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.7 USB Configuration IP65 FLAT STAINLESS PANEL PC...
  • Page 50 USER MANUAL CHAPTER 4 AMI BIOS SETUP BIOS Setting Description Setting Option Effect Legacy USB Support User can enable or Disable Will keep USB disable USB port. devices available only for EFI applications. Enable Enable all the USB devices EMCI Hand‐off This is a Disable Disables this...
  • Page 51 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.8 F81865 Super IO Configuration BIOS Setting Description Setting Option Effect Serial Port Set Parameters of Serial Ports. Enabled/ Enable or 1,2,3 ,4,5 User can Enable/Disable the Disabled disable Serial Configuratio serial port and select optimal Port (COM) settings for the super IO Device.
  • Page 52 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.9 PC Health Status You can see System temperature, fan speed and other PC Health Status parameters. BIOS Setting Description Setting Option Effect Set parameters of Enable or disable Fan 1 Smart Fan Enabled/ Disabled Cooling smart fan Fan 1 Smart Fan...
  • Page 53 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.2.2.10 PPM Configuration BIOS Setting Description Setting Option Effect Configure Intel Enable or disable Enabled/ Disabled EIST Speed Step (EIST) Intel Speed Step parameters (EIST) IP65 FLAT STAINLESS PANEL PC...

  • Page 54: Chipset

    USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.3 Chipset BIOS Setting Description Setting Option Effect Configures Memory Enter Opens submenu Memory Frequency Frequency and Timing Timing Settings Enter Opens submenu Intel IGD Configures Intel Configuratgion IGO Settings IP65 FLAT STAINLESS PANEL PC...
  • Page 55 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.3.1 Memory Frequency Timing BIOS Setting Description Setting Option Effect Enable/ Enable or Disable Configures MRC MRC Fast Boot Disable MRC fast boot Fast Boot Settings IP65 FLAT STAINLESS PANEL PC...
  • Page 56 USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.3.2 Intel IGD Configuratgion IP65 FLAT STAINLESS PANEL PC...
  • Page 57 USER MANUAL CHAPTER 4 AMI BIOS SETUP BIOS Setting Description Setting Option Effect Auto disable IGD Enable/ Enable or disable Auto Disable IGD upon external GFX Disable this function detected VBIOS Default Select IGFX – Boot Set IGFX – Boot IGFX –...

  • Page 58: Boot

    USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.4 Boot BIOS Setting Description Setting Option Effect Number of seconds Set the number of Setup Prompt to wait for setup seconds Timeout activation key Set the keyboard Bootup Numlock Select the keyboard NumLock state State NumLock state...
  • Page 59 USER MANUAL CHAPTER 4 AMI BIOS SETUP Auto Only install Legacy OpRom with Legacy OS and logo would a. VGA Configures VGA NOT be shown EFI Driver Support Support settings during post. Efi driver will still be installed with EFi Disabled All USB devices will NOT be available...
  • Page 60 USER MANUAL CHAPTER 4 AMI BIOS SETUP UEFI: ADATA USB Set the parameter Flash Drive 1.00 for each Boot Option 1~3 Disabled Disable this function Enter Opens sub-menu Hard Drive BBS Hard Drive BBS Priorities Parameters IP65 FLAT STAINLESS PANEL PC...

  • Page 61: Security

    USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.5 Security This section allows you to configure and improve your system and allows you to set up some system features according to your preference. BIOS Setting Description Setting Effect Option Displays Enter If only Administrator’s password is whether or not password.

  • Page 62: Save & Exit

    USER MANUAL CHAPTER 4 AMI BIOS SETUP 4.6 Save & Exit IP65 FLAT STAINLESS PANEL PC...
  • Page 63 USER MANUAL CHAPTER 4 AMI BIOS SETUP BIOS Setting Description Setting Effect Option Save Changes and This saves the <YES> Save changes Exit changes to the CMOS and exits the BIOS Setup program. Discard Changes This exits the BIOS <YES> Saves the changes and Exit Setup without...

  • Page 64: Driver Installation

    USER MANUAL CHAPTER 6 DRIVER INSTALLATION DRIVER INSTALLATION This chapter describes how to install all necessary drivers. IP65 FLAT STAINLESS PANEL PC...

  • Page 65: Chapter 5: Driver Installation

    USER MANUAL CHAPTER 4 AMI BIOS SETUP CHAPTER 5: DRIVER INSTALLATION This chapter describes how to install all necessary drivers. 5.1 Chipset Driver Installation 5.1.1 Standard CMOS Features 1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”.
  • Page 66 USER MANUAL CHAPTER 6 DRIVER INSTALLATION 4. Click on “Next“ to install driver. 5. Click on “Next“ to install driver. IP65 FLAT STAINLESS PANEL PC...
  • Page 67 USER MANUAL CHAPTER 4 AMI BIOS SETUP 6. Click on “Yes, I want to restart this computer now“, and the click “Finish” completing chipset driver installation. IP65 FLAT STAINLESS PANEL PC...

  • Page 68: Graphic Driver Installation

    USER MANUAL CHAPTER 6 DRIVER INSTALLATION 5.2 Graphic Driver Installation 5.2.1 Standard CMOS Feature The computer is equipped with Intel NM10 Companion Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation.
  • Page 69 USER MANUAL CHAPTER 4 AMI BIOS SETUP 3. Click on “Next “to install Driver. 4. Click on “Yes “ to agree with the terms of license. IP65 FLAT STAINLESS PANEL PC...
  • Page 70 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5. Click on “Next “ to install Driver. 6. Click on “Next “to install Driver. IP65 FLAT STAINLESS PANEL PC...

  • Page 71: Panel Resolution Setting

    USER MANUAL CHAPTER 5 DRIVER INSTALLATION 7. Click on “Yes, I want to restart this computer now“ to go on. 5.2.2 Panel Resolution Setting 1. Right-click the desktop, and then click Properties. 2. In the Display Properties dialog box, click the Settings tab. 1.
  • Page 72 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 2. Click on “Hide modes that this monitor cannot display” to remove this option. IP65 FLAT STAINLESS PANEL PC...
  • Page 73 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 1. Click on “Setting”, then could choose 32bit color quality. IP65 FLAT STAINLESS PANEL PC...

  • Page 74: Ethernet Driver Installation

    USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.3 Ethernet Driver Installation You must make sure which operating system you are using before installing the Ethernet drivers. Follow instruction below to complete the installation of the Broadcom BCM57780 Gigabit Ethernet controller LAN drivers. You will quickly complete the installation.
  • Page 75 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 3. Click on “Update Driver” to execute the setup. 4. Click on “Browse my computer for driver software“ to install driver. IP65 FLAT STAINLESS PANEL PC...
  • Page 76 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5. Choose the path to install driver. 6. Click “Close“ to finish driver installation. IP65 FLAT STAINLESS PANEL PC...

  • Page 77: Audio Driver Installation

    USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.4 Audio Driver Installation The ALC888 series are high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs.

  • Page 78: Fintek Com Port Driver Installation

    USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.5 Fintek COM Port Driver Installation 1. If the system is WIN7 please first close UAC(Refer to “Disabling User Account Control (UAC) in Windows 7”). 2. Extract the Patch_0408.zip to a folder. 3. Double-click batch file(patch.bat) will install driver. 4.
  • Page 79 USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5. You will need to restart your computer for driver install success. Type in this command from the Run menu: C:\Windows\System32\UserAccountControlSettings.exe or uac To turn off UAC, move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation.

  • Page 80: Mounting Options

    USER MANUAL CHAPTER 6 MOUNTING MOUNTING This chapter provides step-by-step mounting guide for all available mounting options. IP65 FLAT STAINLESS PANEL PC...

  • Page 81: Chapter 6: Mounting

    USER MANUAL CHAPTER 6 MOUNTING CHAPTER 6: MOUNTING This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. WARNING! / AVERTISSEMENT! Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury.

  • Page 82: Safety Precautions

    USER MANUAL CHAPTER 6 MOUNTING 6.2 Safety Precautions Observe the following common safety precautions before installing any electronic device: • Use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must be crossed make sure the wires are perpendicular at the intersection point.

  • Page 83: Mounting Guide

    This Panel PC comes with different mounting options suitable for most of the industrial and commercial applications. 6.3.1 VESA Mounting This Panel PC has VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). Size VESA Plate Dimensions Screw hole diameter 15”...

  • Page 84: Rear Mounting

    USER MANUAL CHAPTER 6 MOUNTING 6.3.2 Rear Mounting Before you start installing the rear mount, be sure that you have the following components: Panel PC 2 x Bracket M4, 4mm Screw To install the rear mount, perform the following:  Prepare a customized fixture for Panel PC. ...
  • Page 85 USER MANUAL CHAPTER 6 MOUNTING  Make sure your screws are tight and on the right position. IP65 FLAT STAINLESS PANEL PC...
  • Page 86 USER MANUAL CHAPTER 7 TECHNICAL SUPPORT TECHNICAL SUPPORT This chapter includes directory to Winmate technical support. IP65 FLAT STAINLESS PANEL PC...

  • Page 87: Chapter 7: Technical Support

    This chapter includes technical support documents and software developing kit (SDK). If any problem occurs fill in problem report form enclosed and immediately contact us. 7.1 Software Developer Support Winmate provides the following SDK and Utilities for the IP65 Flat Stainless Panel PC Item File Type Description Watchdog SDK...

  • Page 88: Problem Report Form

    USER MANUAL CHAPTER 7 TECHNICAL SUPPORT 7.2 Problem Report Form IP65 Flat Stainless Panel PC Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible.

  • Page 89: Product Specification

    USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS PRODUCT SPECIFICATION This section includes product specifications. Appendix IP65 Flat Stainless Panel PC...

  • Page 90: Appendix A: Product Specifications

    USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS APPENDIX A: PRODUCT SPECIFICATIONS Hardware Specifications Model Name R15ID3S-65A1FTE R15ID3S-65A1FTP Display Size 15” 15” Resolution 1024 x 768 1024 x 768 Brightness (typ.) (typ.) Contrast Ratio 700 : 1 (typ.) 700 : 1 (typ.) Viewing Angle -80~80(H);...
  • Page 91 USER MANUAL APPENDIX B ORDERING INFORMATION ORDERING INFORMATION This section includes product specifications. Appendix IP65 FLAT STAINLESS PANEL PC...

  • Page 92: Appendix B: Ordering Information

    USER MANUAL APPENDIX B ORDERING INFORMATION APPENDIX B: ORDERING INFORMATION IP65 Flat Stainless Panel PC available for ordering in the following configurations. Panel PC SODIMM DDR3L Windows Embedded 7 Standard 1 GB/ 2 GB/ 4 GB Windows XP Embedded ELO 5 Wires Resistive for R15ID3S- 65A1FTE Storage 2.5”...
  • Page 93 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
