Kingsman MQRB5143 Installation Instructions Manual
Infinite series “zero clearance” direct vent gas fireplace
Hide thumbs
Also See for MQRB5143:
- Installation instructions manual (97 pages) ,
- Installation instructions manual (116 pages)
Table of Contents
Advertisement
Quick Links
Installation Instructions
Model Number:
Stock Numbers:
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit is used.
Direct Vent Gas Fireplace
Read this complete manual before beginning installation.
These instructions must be kept with the unit for future reference.
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
Warning: Improper installation, adjustment, alteration, service or maintenance can cause property damage,
personal injury or loss of life. Refer to this manual. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or
mobile home, where not prohibited by local codes. This appliance is only for use with the type(s) of gas indicated
on the rating plate. A conversion kit is supplied with the appliance.
A Division of R-Co. Inc.
MQRB5143
MQRB5143N, MQRB5143NE, MQRB5143LP, MQRB5143LPE
Certified to:
ANSI Z21.50-2007, ANSI Z21.50a-2008
CSA 2.22-2007, CSA 2.22a-2008
"Zero Clearance"
For Your Safety
What To Do If You Smell Gas
Do not try to light any appliance.
Extinguish any open flame.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a neighbour's phone.
If you cannot reach your gas supplier, call the fire department.
* 2340 Logan Ave. * Winnipeg, Manitoba
\Çy|Ç|àx fxÜ|xá
* Canada *
Printed in Canada July 10, 2009, Part# 51MQ-MAN
R2R 2V3
Advertisement
Table of Contents
Related Manuals for Kingsman MQRB5143
Summary of Contents for Kingsman MQRB5143
-
Page 1: Installation Instructions
\Çy|Ç|àx fxÜ|xá Installation Instructions Model Number: MQRB5143 Stock Numbers: MQRB5143N, MQRB5143NE, MQRB5143LP, MQRB5143LPE Certified to: ANSI Z21.50-2007, ANSI Z21.50a-2008 CSA 2.22-2007, CSA 2.22a-2008 This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used. -
Page 2: Table Of Contents
Mobile Home/Manufactured Housing Installation ........................... 6 Installation and Operation..................................7 Installation Regulations ..................................7 Installation Requirements for the Commonwealth of Massachusetts ..................... 8 MQRB5143 Locating Your Appliance ..............................9 Fireplace Dimensions ..................................... 9 Surround Dimensions MQRB5143 ............................... 10 Surround Clearances ................................... 10 MQRB5143 Framing Your Gas Fireplace............................. - Page 3 Venting ......................................... 45 General Vent Installation Information ..............................46 Simpson Dura-vent, AmeriVent, and Selkirk Direct Temp ........................ 46 Eight Inch Hard Pipe Adapter for MQRB5143 Infinite Series (Z57DFA) ................... 46 Flex Pipe Venting ..................................... 46 Termination ...................................... 46 Venting Routes and Components..............................47 Horizontal Vent Table ...................................
- Page 4 Infinite Wall Surround-(Covers 55-3/4"W X 24") ..........................54 Infinite Porcelain Liners ..................................54 Accessories ...................................... 54 Rocks & Logs ....................................54 Electronic Ignition ..................................... 55 Valve System Parts ..................................55 Replacement Burner Assembly ................................ 55 Conversion Kit ....................................55 Miscellaneous Parts ..................................55 Venting Accessories ..................................
-
Page 5: Pre-Installation Questions And Answers
Pre-Installation Questions and Answers Why does my fireplace or stove give off odour? It is normal for your fireplace to give off some odour. This is due to the curing of paint, adhesives, silicones and any undetected oil from the manufacturing process as well as the finishing materials used with the installation (e.g. marble, tile and the adhesives used to adhere these products to the walls can react with heat and cause odours). -
Page 6: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 7: Installation And Operation
Installation and Operation Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CGA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1 when installed in the United States. -
Page 8: Installation Requirements For The Commonwealth Of Massachusetts
13. Do not use this heater if any part has been under water. Immediately call a qualified service technician to inspect the heater and to replace any part of the control system and any gas control which has been under water. 14. -
Page 9: Mqrb5143 Locating Your Appliance
MQRB5143 Locating Your Appliance All units are Factory Set for a Left Hand Burner System. Right Hand Burner System Requires Valve to be relocated to right side of unit. Fireplace Dimensions... -
Page 10: Surround Dimensions Mqrb5143
Surround Dimensions MQRB5143 • The Surround Frames are 1” thick, with a 3/4” space behind the frame. • When using Surrounds, Maximum Thickness for Non-Combustible Facing Materials is 3/4”. • The Fireplace may be covered up to within 1/2” of the Fireplace Opening with non-combustible materials. -
Page 11: Mqrb5143 Framing Your Gas Fireplace
MQRB5143 Framing Your Gas Fireplace This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and clearance requirements (see Venting section) for this appliance. -
Page 12: Mqrb5143 Nailing Tab Guide
[Qty]2 Nailing Tabs are located on each corner of the fireplace. The Nailing Tabs on the MQRB5143 can be used in two ways: 1/2” Drywall Flush with Face of Fireplace –Fireplace and -Fireplace to be covered Framing Flush with Face of Fireplace Combustible Wall to be covered with Non-Combustible with Non-Combustibles (e.g. -
Page 13: Mqrb5143 -See Thru Framing
MQRB5143 -See Thru Framing An MQRB5143SK Kit is required for a See Thru Installation. Before you begin Framing- Determine for both sides whether the Wall Surface will be flush with the face of the fireplace (Fireplace and wall to be covered with Non-Combustibles, such as tile), or the Framing will be flush with the face of the fireplace (Flat Wall appearance). - Page 14 Wall Surface Flush With Face of Fireplace Framing Flush With Face of Fireplace Note: If using Optional Surround, Maximum Thickness for Non-Combustible Material is 3/4”. [Steel Stud Framing Shown.] *See the “Nailing Tab Guide” and “MQRB5143SK” pages before placing unit into the framed opening.*...
-
Page 15: Mqrb5143 Single Sided Framing
MQRB5143 Single Sided Framing An MQRB5143BK Kit is required for a Single Sided Installation. Before you begin Framing- Determine whether the Wall Surface will be flush with the face of the fireplace (Fireplace and wall to be covered with Non-Combustibles, such as tile), or the Framing will be flush with the face of the fireplace (Flat Wall appearance). - Page 16 Wall Surface Flush With Face of Fireplace Framing Flush With Face of Fireplace Note: If using Optional Surround, Maximum Thickness for Non-Combustible Material is 3/4”. [Steel Stud Framing Shown.] *See the “Nailing Tab Guide” and “MQRB5143BK” pages before placing unit into the framed opening.*...
-
Page 17: Mqrb5143 Combustible Enclosure Heights
MQRB5143 Combustible Enclosure Heights Cold Climate Recommendation When installing this fireplace against an exterior wall or chase, it is recommended that the outer walls be insulated to conform to applicable insulation codes. Drywall must be installed over vapor barrier and insulation material to prevent direct contact with the appliance. -
Page 18: Mqrb5143 Facing Material Requirements
MQRB5143 Facing Material Requirements These specifications are the same for all Models (5143N, 5143NE, 5143LP, 5143LPE). Note: If using Optional Surround, See Surround Clearances Section. [Steel Stud Framing Shown.] Note: Do not drive excessively long screws into the face of the unit as internal parts may be damaged. -
Page 19: Mqrb5143 Mantel Clearances
MQRB5143 Mantel Clearances Before installing any mantels it is important to determine the combustibility of its material(s). There are two types of mantels to consider: Combustible and Non-Combustible. A Combustible Mantel is one that consists of material(s) that may discolor, combust, or lose its integrity in the presence of heat. -
Page 20: Mqrb5143 Finishing Options
MQRB5143 Finishing Options Using Side Fillers The Side Fillers are located at each side of the door. They are provided to give a continuous surface up to the opening of the fireplace door. Using other Non-Combustible Materials as Side Fillers (Brick, Tile, Marble, etc.) -
Page 21: Mqrb5143Bk Back Shield Kit -Single View
MQRB5143BK Back Shield Kit –Single View *This Kit must be opened before unit is installed into Framing (See “Single Sided Framing” page of this Manual). Contents of Kit: Firebox Cover Heat Shield Assembly Back Liner False Bottom ... -
Page 22: Back Liner, False Bottom, And End Panel Installation
Back Liner, False Bottom, and End Panel Installation: Remove Liner Clips from the inside of the Firebox. Place the Back Liner into the Firebox with bends facing the Rear Firebox Cover. Next install the False Bottom with larger Dimension to Front Glass Opening (See Right), and secure it with 6 DT screws into the mounting... -
Page 23: Mqrb5143Sk (See Thru Kit) Installation
MQRB5143SK (See Thru Kit) Installation This basic Kit is required for See Thru installations. Note: If you wish to cover the Side Fillers with non-combustible materials, they must be installed before Facing materials are applied. Components: [2ea.] Side Fillers Valve Access Cover Glass Door c/w Glass See Thru False Bottom [4ea.] #6 Black Screws... -
Page 24: Mqrb5143 Surround Installation
MQRB5143 Surround Installation The Surround Kits for the MQRB5143 are available in 3 different finishes: Small [1-1/2”] Large [4”] MQRB5019SBL MQRB5624SBL -Black Surround Kits: MQRB5019SSS MQRB5624SSS -Stainless Steel MQRB5019SPW MQRB5624SPW -Pewter Each kit contains: (Qty-1) Surround Frame (Qty-2) Surround Side Fillers... -
Page 25: Optional Additional Screws: Stainless Steel Surrounds
Optional Additional Screws: Stainless Steel Surrounds Two additional screws may be added to MQRB5019SS and MQRB5624SS to counteract heat distortion. Directions: 1. Install Surround normally as per Instructions. 2. Drill a pilot hole through the unused slot in each corner of the inner top of the surround. 3. -
Page 26: Optional Glass Ember Installation
Optional Glass Ember Installation If you wish to use this media evenly spread the glass embers onto the false bottom and burner. Ensure the glass embers do not excessively overlap as this will affect the flame pattern. (MQG5W) 5 lbs of ½” White Ember Glass is supplied with every unit. Use care when placing glass embers near the pilot area so as not block or have the glass fall over the crossover holes from the pilot to the burner, as delayed ignition can occur. -
Page 27: Door And Glass Information
Do not strike or abuse the glass. Glass Replacement Only Robax ceramic or coated Neoceram glass may be used for replacement for Models MQRB5143 and MQRB6169. Glass must be minimum 5mm thick. To replace glass, clean all materials from the door frame. Scrape off old silicone all the way down to the metal. Using high-temp silicone [rated up to 500°F (260°C)] apply a continuous bead of approximately 1/8”-3/16”... -
Page 28: Valve Access Cover Removal
Remove Valve Access Cover in order to access igniter and valve controls. To remove Valve Access Cover, simply insert fingers into holes in Access Panel and lift out. When replacing Access Panel, engage Tabs into Slots in Bracket. MQRB5143 Removable Lower Face Panel Installers Note: Once the installation is complete attach the Lower Face Panel. -
Page 29: Gas Line Installation
Gas Line Installation This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CGA - B149.1 or .2 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI Z223 in the U.S.A. -
Page 30: Millivolt System, Lighting, And Burner Control
Millivolt System, Lighting, and Burner Control... -
Page 31: Troubleshooting The Millivolt Gas Control System
Troubleshooting the Millivolt Gas Control System WARNING: BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. NOTE: Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not Defective or misaligned Check for spark at electrode and pilot: if no spark... -
Page 32: Mqrb5143 Gas Conversion
MQRB5143 Gas Conversion or Models: MQRB5143N, MQRB5143LP, MQRB5143NE, MQRB5143LPE. Kit Number Description Pilot Orifice Burner Orifice Nipple Air Shutter Hi/Lo Regulator 5143MQ-CKLP LP Conversion 1001-P167SI 1000-253closed 3/8” 1001-P202SI 5143MQ-CKNG 1001-P165SI 1000-253closed 1/32” 1001-P201SI Conversion 5143MQ-CKLPI LP Conversion 1001-P168si 1000-253closed 3/8”... -
Page 33: Gas Conversion For Top Convertible Pilot (Series 019065X)
Gas Conversion for Top Convertible Pilot (Series 019065X) Instructions for converting SIT 190 series pilot burner injection from NG to LPG and from NG to LPG only. This information should be considered as supplemental to the Appliance Manufacturer’s Instructions. WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. -
Page 34: Mqrb5143 Burner Tube Removal
Slide the Burner Tube away from the Plumbing Connection until it disengages from the orifice. Reverse these steps to reinstall. MQRB5143 Burner System Removal/Installation Guide Warning- Turn off Unit and allow to cool before cleaning. Only a Qualified service technician should service and repair this appliance. -
Page 35: Moving Valve To Other Side Of Fireplace
Moving Valve to Other Side of Fireplace The Valve Assembly may be changed to the other side of the fireplace. This must be done Before the unit is inside the enclosure. Remove the Burner Tube (See Burner Tube Removal section in this Manual). Disconnect plumbing from the valve, including connections to Pilot. -
Page 36: Ipi Electronic Ignition System
IPI Electronic Ignition System SYSTEM NOTE In the event of an operational lockup the IPI system must be reset by removing the batteries from both the backup pack and the remote receiver module. Remote Receiver Location -For All IPI Installations & GT Series Remotes Only- The Remote Receiver may be located outside of the unit- up to a maximum of 6 feet from either... -
Page 37: Electronic Ignition Lighting Instructions
Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. -
Page 38: Ipi Electronic Ignition Parts List - Standard System
IPI Electronic Ignition Parts List – Standard System Item No. Part No. Description 1006-P002si Valve IPI Hi/Lo NG 1006-P003si Valve IPI Hi/Lo LP 1002-P047si Pilot Assembly-LP 1002-P033si Pilot Assembly-NG 1002-P017si Spark Electrode (with wire) 1002-P903si Electrode Flame Sensor 1002-P302si IPI Ignition Board 1002-P850si AC Wall Adapter 1002-P12BH... -
Page 40: Lk2 Halogen Lamp Kit
LK2 Halogen Lamp Kit Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. SYSTEM NOTES Each lamp is running on a dedicated circuit (Parallel circuit). This means that if one bulb fails the rest will remain operational. -
Page 41: Photos
Photos Bottom of Unit with IPI Module Light Module &IPI Valve... -
Page 42: Close Up View Of Ipi Module
Close up View of IPI Module Inside of IPI Module... -
Page 43: Ipi Valve
IPI Valve IPI Valve... -
Page 44: Millivolt Valve & Light Module
Millivolt Valve & Light Module Millivolt Valve... -
Page 45: Venting
Venting [1,2] Clearance above grade, veranda, porch, deck, or balcony 12in [30cm] min. Clearance to window or door that may be opened. 12in [30cm] min. for appliances 100,000BTUh [30kW] and lower, in Canada. [23cm] for appliances 50,000 BTUh and lower, in USA. C. -
Page 46: General Vent Installation Information
WARNING: DO NOT mix parts from different systems unless stated in the manual. Eight Inch Hard Pipe Adapter for MQRB5143 Infinite Series (Z57DFA) Contents: 1 ea. 8” Adapter Plate 6ea. -
Page 47: Venting Routes And Components
Figure 2 - Flex pipe spring spacing guide. Horizontal runs require support metal straps every 2ft. In an offset installation support straps should be used to stabilize pipe. Expand 5" and 7" flex pipe to the point that the 7" protrudes approximately 2 to 3 inches past outer wall and the 5" flex protrudes approximately 2 to 3 inches past the 7"... -
Page 48: Horizontal Vent Table
Minimum clearance to combustibles on venting is 1” with the following exceptions: -Top of horizontal is 2”. -Top of 90 degree elbow in an enclosure under 72” is 5” with Wall Thimble Shield [Z57WTS]. -Top of 90 degree elbow in an enclosure over 72” is 4”. -Minimum Enclosure Height is 60”... -
Page 49: Venting Examples
Venting Examples All horizontal runs have a minimum ¼” rise per foot. -
Page 50: Installation Of Side Wall Venting
Installation of Side Wall Venting The minimum distance from the bottom of fireplace to centre of vent is 51-1/2". For combustible walls: Cut a hole through the wall allowing for an 11" x 11" (inside dimension) wall thimble. For a non-combustible wall: Cut an 8" diameter hole (see Figure 4). -
Page 51: Venting Straight Up Through Roof
Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney (see Figure 7a). When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"... -
Page 52: Flue Restrictor Adjustment
Flue Restrictor Adjustment MQRB5143 –All Models The Flue Restrictor is located in the top of the Firebox in front of the Flue Opening. For vertically vented installations it is necessary to use the Flue Restrictor. Restrictor is set fully open from factory for short horizontal and vertical runs. - Page 53 2” Top of Horizontal Vent Figure 6 - Clearances in horizontal venting. Figure 7 - a) Straight-through roof support configuration; b) Flex bend configuration; c) Termination mounting.
-
Page 54: Mqrb5143 -Parts List
MQRB5143 -Parts List Marquis Infinite Zero Clearance Direct Vent Gas Fireplace -51” Wide Listed for USA/Canada as a Decorative Appliance: Linear LH Burner, Two Sides Open, SIT Valve with Hi/Lo Flame and BTU Adjustment, Ceramic Glass, 5/7" Flue, Wall Switches, Junction Box, Accent Lighting... -
Page 55: Electronic Ignition
5143MQ-BLPSIE Burner Assembly- Liquid Propane c/w Valve System (MQRB5143LPE) 5143MQ-BNGSIE Burner Assembly-Natural Gas c/w Valve System (MQRB5143NE) Conversion Kit 5143MQ-CKLP LP Conversion Kit for MQRB5143 5143MQ-CKNG NG Conversion Kit for MQRB5143 5143MQ-CKLPI LP Conversion Kit for IPI MQRB5143LPE 5143MQ-CKNGI NG Conversion Kit for IPI MQRB5143NE... -
Page 56: Venting Accessories
1000-255 Orifice Brass -(State Size) 1000-306 Thermalcord -Adhesive Back for Door Frame 5143ZDV-311 Ceramic Glass –For All MQRB5143 36HB-123 Upper Door Spring Venting Accessories Z57HSK5 Horizontal Round Termination Vent Starter Kit - 5/7" X 5 FT Length, Wall Thimble Shield, Horizontal Vent Termination, Wall Thimble, 60"... -
Page 57: Warranty
Warranty...
