Kingsman Marquis SOLACE Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model Numbers: MQHBZDV3636, MQHBZDV4236, MQRB4236, MQRB4236T, HBZDV4736
Stock #'s: MQHBZDV3636N, MQHBZDV3636LP, MQHBZDV4236N, MQRB4236N, MQHBZDV4236LP,
MQHBZDV3636NE, MQHBZDV3636LPE, MQHBZDV4236NE, MQRB4236NE, MQHBZDV4236LPE
Certified to: ANSI Z21.88-2014 • CSA 2.33-2014ZERO CLEARANCE VENTED GAS FIREPLACE HEATER
Stock #'s: MQRB4236NT, MQRB4236LPT, MQRB4236NTE, MQRB4236LPTE
HBZDV4736N, HBZDV4736LP,HBZDV4736NE, HBZDV4736LPE
Certified to: ANSI Z21.50-2014 • CSA 2.22-2014 ZERO CLEARANCE VENTED GAS FIREPLACE
SOLACE/SKYLINE
Installation Instructions
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
For Propane Horizontal installations the venting
must be a minimum of one foot vertical off the
flue before going horizontal.
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada July 20, 2018
Part # 36MQ-MAN14
