SignaMax 065 Series User Manual

Rs-232/422/485 to 100basefx multimode / singlemode fiber converter
Hide thumbs
Table of Contents

Advertisement

Quick Links

SIGNAMAX Networks 065-1180 FiberPack Media Converter Rack Mount Chassis
Signamax™ Connectivity Systems
RS-232/422/485 to 100BaseFX
Multimode / Singlemode
Fiber Converter
Model 065-1163F series
U
'
G
S E R
S
U I D E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 065 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SignaMax 065 Series

Summary of Contents for SignaMax 065 Series

  • Page 1 SIGNAMAX Networks 065-1180 FiberPack Media Converter Rack Mount Chassis Signamax™ Connectivity Systems RS-232/422/485 to 100BaseFX Multimode / Singlemode Fiber Converter Model 065-1163F series ’ S E R U I D E...
  • Page 2 ™ Signamax Connectivity Systems RS-232/422/485 to 100BaseFX Multimode / Singlemode Fiber Converter Model 065-1163F series User’s Guide...

  • Page 3: Fcc Warning

    Signamax 065 㤠-1163 F series RS-232/422/485 to 100BaseFX Media Converter FCC Warning This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 • Ethernet is a trademark of Xerox Corporation. • Microsoft Windows is a trademark of Microsoft Corporation. • Signamax Connectivity Systems is a trademark of Advanced Electronic Support Products, Inc.

  • Page 5: Table Of Contents

    Signamax 065 „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter ABLE OF ONTENTS CHAPTER 1: INTRODUCTION… … … … … … … … ....… … … … … … … . PRODUCT OVERVIEW ....… … … … … … … … … … … …...

  • Page 6: Chapter 1: Introduction

    Additionally, by deploying the media converter, users can install the device as a standalone solution or in a Signamax™ 065-1180 or 065-1185 chassis for a rack mount system, thereby retaining investments made in the existing serial equipment and software...
  • Page 7 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter (RS-232/422/485 to Multimode Fiber Converter, ST) (RS-232/422/485 to Multimode or Singlemode Fiber Converter, SC) Introduction...

  • Page 8: Features

    Signamax 065 „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Features • Complies with EIA/TIA and IEEE standards • Supports 4-wire full-duplex asynchronous serial data transmission (RS-422/485) • Supports 2-wire half-duplex asynchronous serial data transmission (RS-485) • Supports serial port asynchronous data rates up to 115.2 Kbps...

  • Page 9: Specification

    Signamax 㤠-1163 F series RS-232/422/485 to 100BaseFX Media Converter Specifications Standards: IEEE 802.3u (100BaseFX Fast Ethernet); EIA/TIA RS-232E; EIA/TIA-574 Ports: 1x duplex fiber; ST Multimode (065-1163FST) 1x duplex fiber; SC Multimode (065-1163FSC) 1x duplex fiber; SC Singlemode (065-1163FSM) 1x 9-pin serial connector; D-sub, female Data Rates: Fiber: 100 Mbps Serial: 50 ~ 115.2 kbps (asynchronous).
  • Page 10 Signamax 065 „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Power: AC power adapter; 12V DC @ 0.8A Frequency: 47Hz to 63Hz. Environment: Operating: Temperature: 32°F to 131°F (0°C to 55°C) Relative Humidity: 10% to 80%, non-condensing Non-Operating/Storage: Temperature: -13°F to 158°F (-25°C to 70°C) Relative Humidity: 5% to 90%, non-condensing Emissions: FCC Part 15 of Class A &...

  • Page 11: Package Contents

    -34 dBm 19, 27 30km. Power Budget =TX PWR -RX Sensitivity ¡¯ Package Contents The Signamax™ 065-1163F series RS-232/422/485 to 100BaseFX converter package includes: • One media converter unit • One power adapter (please check connector type and input power specification) •...

  • Page 12: Chapter 2: Installation

    Signamax 065 „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter NSTALLATION To ensure proper installation of the converter, please note the following procedures: • DB9 Female Connector Pin Assignment • Serial Connection • Connection to DTE • Connection to DCE •...

  • Page 13: Serial Connection

    Signamax 㤠-1163 F series RS-232/422/485 to 100BaseFX Media Converter Serial Connection This converter features DIP switches on the rear panel that sets the unit to the correct type of cable configuration to support connection with a RS-232/422/485 device. For setting the control function of the serial port, see the...

  • Page 14: Equipment (Dte)

    Signamax 065 „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Connection to Data Terminal Equipment (DTE) Console Mode 1. Ensure that DIP switch #1 is in the “ON” position. (Enables Console mode) 2. Set DIP switches #2, #3 and #4 according to wire type...
  • Page 15 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Data Communication Mode 1. Ensure that DIP switch #1 is in the “OFF” position. (Disables Console mode) 2. Set DIP switches #2, #3 and #4 according to the wire type, as indicated below:...

  • Page 16: Connection To Data Communication Equipment (Dce)

    Signamax 065 „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Connection to Data Communication Equipment (DCE) Data Communication Mode 1. Ensure that DIP switch #1 is in the “OFF” position. (Disables Console mode) 2. Set DIP switches #2, #3 and #4 according to the wire...

  • Page 17: Led Indicators

    Signamax 㤠-1163 F series RS-232/422/485 to 100BaseFX Media Converter Connection to Fiber Optic Cable When connecting fiber cable to the 100BaseFX port of the media converter, be sure the correct type РSC or ST - connector is used. Follow the steps below to properly connect the fiber cable: 1.

  • Page 18: Chapter 3: Led Indicators

    Signamax 㤠-1163 F series RS-232/422/485 to 100BaseFX Media Converter LED I NDICATORS This converter has several LED indicators that enable quick identification of the status of the converter as well as what is happening across your network. Their functions are as...

  • Page 19: Console Port

    Signamax 㤠-1163 F series RS-232/422/485 to 100BaseFX Media Converter Configuration There are two separate methods for configuring this media converter for use. In the first section of this chapter, the Command line Interface (CLI) or Menu-driven interface via the Console Port to set the device for connection to data terminal equipment in console mode will be defined.
  • Page 20 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter password. After successful login, type the following command line to change the device IP address in CLI mode where xxx’s represent values between 0 and 254, and the user should enter their own IP address in this form.
  • Page 21 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter proceed. 5. Select either the CLI User Interface or the Menu-driven Interface option by using the associated number key or using the TAB key and pressing ENTER. A Main Menu screen appears.
  • Page 22 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter DHCP Configuration Menu DHCP (Dynamic Host Configuration Protocol) allows the converter to obtain an IP address from the DHCP server automatically. NOTE: A DHCP server must exist and be available in your local network prior to enabling the DHCP client.
  • Page 23 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter through a media converter, it is necessary to set up a connection between the local and remote media converter. The connection setup process involves the server waiting for a connection service request sent by the client. During...

  • Page 24: Dip Switches

    Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Under the Serial Port Configuration heading, the field Operation Mode is a “read only” value indicating one of the following modes: Console, RS -232, RS -422, or RS-485. The mode is based on the DIP switches setting found on the rear panel of the media converter.
  • Page 25 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter field and enter the IP address of the TFTP server in the IP address field to perform the upgrade. Load System Default The Load System Default command allows a user to restore factory default settings to the converter.
  • Page 26 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter with other devices with the same defaults. NOTE: Prior to following the instructions listed below for Remote Computer Login, ensure that a serial cable connection between the media converter and remote workstation exists.
  • Page 27 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter 4. Press ENTER and on the following screen, type the default username admin, leave the password field blank since there is no default value, and press ENTER to proceed. 5. Select the CLI User Interface option by using the associated number key or using the TAB key and pressing ENTER.
  • Page 28 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter Command Definitions backup: Use this command to save configuration settings to file. exit: Type exit or logout and press ENTER to quit the program. help: To access help commands list.
  • Page 29 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter communication is idle set xfer – command RS232 configuration data communication setting. command syntax is as shown below: set xfer [arg_1 data_1] [arg_2 data_2] ... [arg_n data_n] [Argument List] idle... Set idle time of serial port type…...
  • Page 30 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter and filename accurately. upgrade firmware: Use this command to load new versions of software for this console. For example: upgrade firmware xxx.xxx.xxx.xxx firmware.bin Configuration...
  • Page 31 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter PPENDIX A RS-232 Wiring Male-to-Female Wire (DTE->DTE): RS-232 (DTE) PC-COM1 (DTE) DB9 Female DB9 Male PIN 1 PIN 1 PIN 2 PIN 3 PIN 3 PIN 2 PIN 4 PIN 6...
  • Page 32 Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter PPENDIX B RS-422/485 4-Wire Definition Converter RS-422/485 DB9 Female Device PIN 1 PIN 2 A (RX+) PIN 3 B (TX+) PIN 4 PIN 5 PIN 6 PIN 7 C (RX-)

  • Page 33: Application Example

    Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter PPENDIX C Application Examples • DTE to DTE 2km 62.5/ 1200m RS-485 125um 1200m RS-232 CABLE FIBER CABLE RS-485 RS-485 Converter Converter Push-button set push-button set to DTE to DTE •...

  • Page 34: Contact Information

    Signamax „§ -1163 F series RS-232/422/485 to 100BaseFX Media Converter ONTACT NFORMATION SIGNAMAX™ CONNECTIVITY SYSTEMS An AESP Company 1810 N.E. 144th Street. North Miami, Florida 33181, U.S.A. Phone: 305-944-7710 Fax: 305-652-8489 Sales: 800-446-2377 Tech. Support: 800-446-2377, ext. 201 Http://www.signamax.com E-mail: info@signamax.com...
