- Page 1 Signamax™ Connectivity Systems Gigabit Ethernet Media Converter ’ S E R U I D E...
- Page 2 Signamax™ Connectivity Systems Gigabit Ethernet Media Converter User’s Guide...
-
Page 3: Fcc Statement
All trademarks or brand names mentioned are properties of their respective companies. P r e f a c e This manual describes how to install and use the Signamax™ Gigabit Ethernet Media Converter. The Converter introduced here provides one channel media conversion solution:... -
Page 4: Table Of Contents
Signamax™ Gigabit Ethernet Media Converter T a b l e o f C o n t e n t s FCC S ....................1 TATEMENT ......................1 RADEMARKS ........................1 REFACE ....................2 ABLE OF ONTENTS ......................3 NTRODUCTION ..................3... -
Page 5: Introduction
Signamax™ Gigabit Ethernet Media Converter I n t r o d u c t i o n The Signamax™ Gigabit Ethernet Media Converter, provides one channel for media conversion between 1000BaseSX/LX to 1000BaseLX. It can be used as a stand-alone device or with a standard 19”... -
Page 6: Packing List
Signamax™ Gigabit Ethernet Media Converter Packing List When you unpack this product package, you will find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. — The Media Converter —... - Page 7 Signamax™ Gigabit Ethernet Media Converter 1000T to 1000SX/LX: LEDs State Indication Power Steady Power feed is OK No power LNKC Steady TX port: A valid network connection has been established LNKC stands for LINK/Copper No connection LNKF Steady FX port: A valid network connection has been established...
-
Page 8: Installation
Step 2: Attach the plug into a standard AC outlet with the appropriate AC voltage. Installing in a Chassis The Converter is designed to fit into any of the expansion slots on a Signamax™ FO-065-1185 rackmount chassis. Step 1: Unscrew the carrier from the desired expansion slot on the chassis. -
Page 9: Specifications
Signamax™ Gigabit Ethernet Media Converter S p e c i f i c a t i o n s IEEE 802.3ab 1000BaseT, IEEE 802.3z 1000BaseSX/LX Applicable Standards Fixed Ports 1000T to 1000SX/LX: One twisted-pair port meeting IEEE 802.3ab standard specification; Category 5e or better cable, 100 meters maximum distance One fiber optic port meeting IEEE 802.3z standard... -
Page 10: Appendix A: Ordering Information
Signamax™ Gigabit Ethernet Media Converter A p p e n d i x A : O r d e r i n g I n f o r m a t i o n Please include the following information when ordering: 1. -
Page 11: Appendix B: Contact Information
Signamax™ Gigabit Ethernet Media Converter A p p e n d i x B : C o n t a c t I n f o r m a t i o n SIGNAMAX™ CONNECTIVITY SYSTEMS An AESP Company 1810 N.E. 144th Street.
