- Page 1 Signamax FO-065-1200 series 12-Port Media Converter ™ ™ ™ ™ Signamax Connectivity Systems ™ FO-065-1200 Series 12-Port Media Converter ’ S E R U I D E User’s Manual...
- Page 2 Signamax Connectivity Systems ™ 12-Port Media Converter F0-065-1200 Series User’s Guide...
-
Page 3: P Reface
™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Preface This manual describes how to install and use the Signamax™ FO- 065-1200 series 12-Port Media Converter. The system introduced here is capable of housing up to twelve media converters, each of which offers a single channel media conversion solution: 10/100BaseTX ↔... -
Page 4: Table Of Contents
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Table of Contents REFACE ABLE OF ONTENTS RODUCT VERVIEW ™ FO-065-1200 12-P IGNAMAX SERIES EDIA ONVERTER ACKAGE ONTENTS RODUCT EATURES RONT ANEL ISPLAY Front Panel Understanding LEDs NSTALLATION ELECTING A... -
Page 5: Product Overview
The Signamax™ FO-065-1200 series 12-Port Media Converter can house up to twelve media converters in a 1U standard 19” rackmountable size. The front panel of the Signamax™ FO-065- 1200 12-Port Media Converter provides status LEDs and an uplink push button for each 10/100BaseTX to 100BaseFX media converter or status LEDs and a dip switch array for each 1000BaseT to 1000BaseSX/LX media converter. -
Page 6: Product Features
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Product Features ♦ Houses twelve channels of media conversion ♦ Front panel status LEDs ♦ Standard 19” rackmountable size, 1U high ♦ 2 Redundant Power Supplies ♦ 10/100BaseTX to 100BaseFX converters:... -
Page 7: Front Panel Display
Converter shows the layout of the twelve media converter channels. There are 12 sets of LED indicators, which provide you with instant feedback on the status of each media converter channel. Figure 2: Front Panel of the Signamax™ FO-065-1200 series 12-Port Media Converter User’s Manual... -
Page 8: Understanding Leds
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter NDERSTANDING 10/100TX to 100FX Media Converter LEDs State Indication Steady Power on Power off LNK/ACT Steady A valid network connection established LNK stands for LINK Flashing Transmitting & receiving ACT stands for activity... - Page 9 Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter 1000T to 1000SX/LX Media Converter LEDs State Indication Power Steady Power feeding in No power LNKC Steady TX port: A valid network connection established. LNKC stands for LINK/Copper No connection...
-
Page 10: Installation
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Installation Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select... -
Page 11: Connecting To Power
Ports from the Signamax 065-1200 series 12-channel media converters can be routed to network switch ports located on different network switches. There is no requirement for the Signamax 1200 series’ converter channels to be routed to a single switch. When used in multiple switch configurations,... -
Page 12: Specifications
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Specifications Applicable Standards IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX/FX, IEEE 802.3ab 1000BaseT, IEEE 802.3z 1000BaseSX/LX Fixed Ports 12-Bay of 1 TX port and 1 FX port Speed – 10BaseT 10/20Mbps for half/full-duplex... -
Page 13: Ordering Information
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Ordering Information FO-065-1200ST00 10/100BaseT/TX to 100BaseFX 12-Port Media Converter – ST Multimode Connectors FO-065-1200SC10 10/100BaseT/TX to 100BaseFX 12-Port Media Converter – SC Multimode Connectors FO-065-1200SC20 10/100BaseT/TX to 100BaseFX 12-Port Media Converter – SC Singlemode... -
Page 14: Contact Information
Signamax ™ ™ ™ ™ FO-065-1200 series 12-Port Media Converter Contact Information SIGNAMAX™ ™ ™ ™ CONNECTIVITY SYSTEMS An AESP Company 16295 N.W. 13th Avenue Suite A Miami, Florida 33169, U.S.A. Phone: 305-944-7710 Fax: 305-949-4483 Sales: 800-446-2377 Tech. Support: 800-446-2377, ext. 201 Http://www.signamax.com...
