- Page 1 Signamax™ Connectivity Systems 100BaseTX to 100BaseFX Media Converter Model 065-1100NS Mode 065-1110NS Mode 065-1120NS Series ’ S E R U I D E...
- Page 2 Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter ™ Signamax Connectivity Systems 100BaseTX to 100BaseFX Media Converter Series 065-1100NS 065-1110NS 065-1120NS User’ s Guide...
-
Page 3: Fcc Warning
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter FCC Warning This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Trademarks Product names mentioned in this manual may be trademarks or registered trademarks of those products and are hereby acknowledged. • Ethernet is a trademark of Xerox Corporation. • Microsoft Windows is a trademark of Microsoft Corporation.
-
Page 5: Table Of Contents
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter ABLE OF ONTENTS CHAPTER 1: INTRODUCTION… … … … … … … … ....… … … … … … … … ABOUT THIS GUIDE ....… … … … … … … … … … … …... -
Page 6: Contact Information
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter APPENDIX C: APPLICATION DIAGRAM… … … … … … … … … … … … APPLICATION DIAGRAM I… … … … … … … … … … … . APPLICATION DIAGRAM II… … … … … … … … … … …... -
Page 7: Chapter 1: Introduction
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter NTRODUCTION About This Guide Welcome Thank you for choosing the 100BaseTX to 100BaseFX Media Converter. This device integrates Fast Ethernet copper and fiber segments in a highly flexible package. Purpose This guide discusses how to install and configure your 100BaseTX to 100BaseFX Media Converter. -
Page 8: Features
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Features • Complies with EIA/TIA and IEEE standards • Complies with IEEE 802.3u 100BaseTX & FX standards • MDI/MDI-X push button selection for RJ-45 port • Supports Half/Full Duplex Auto-Negotiation • Slide switch to enable/disable auto-negotiation operations •... -
Page 9: Specification
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Specifications Standard: IEEE 802.3u Connector: 1 x ST or SC fiber optic 1 x RJ-45 Max. Distance: Twisted Pair: 100 m (330 ft) Full Duplex- MM Fiber: 2,000 m (6,600 ft) SM Fiber: 20 km (66,000 ft) -
Page 10: Package Contents
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Package Contents The 100BaseTX to 100Base-FX Converter packaged should include: • One converter • One AC adapter (for external power supply) • Four pieces self-adhesive pads • One user’s manual Introduction... -
Page 11: Chapter 2: Hardware Description
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter ARDWARE DESCRIPTION Product Overview The Converter is primarily designed for larger workgroups, demanding more speed and bandwidth, and requiring expansion of the Fast Ethernet network. It features a MDI/MDI-X crossover “push button” switch for direct connection to the workstation, switch or hub. - Page 12 Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Front Panel View with SC and RJ-45 Connectors Front Panel View with ST and RJ-45 Connectors Hardware Description...
-
Page 13: Chapter 3: Installation
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter NSTALLATION Installing Your Converter In this chapter, we will take a look at how to install converters within its operating environment. First, it is important to unpack the Converter and ensure that all the components listed in Package Contents are present. -
Page 14: Mdi/Mdi-X Connection
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter 2. Install the Converter in a location free from strong electromagnetic field generators (such as motors), vibration, dust, and direct exposure to sunlight. 3. Leave at least 10 cm of space at the front and rear of the unit for ventilation. -
Page 15: Nway Push Button Switch Setting
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter NWay Push Button Switch Setting Use the NWay push button switch to activate NWay operations. Note: Factory NWay switch default is set to the ON position. Activates the NWay auto-negotiation operation mode. Set the NWay switch to ON when connecting to an auto-negotiation device. -
Page 16: Install The Converter
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Install the converter This Converter utilizes ports with fiber and copper port connectors, functioning under the Fast Ethernet protocol. 100BaseTX Port The 100BaseTX port supports a network speed of 100Mbps, and can operate in half and full duplex transfer modes. This port also offers MDI/MDI-X crossover detection that gives true "plug and play"... -
Page 17: Desktop Installation
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Desktop Installation Follow the instructions listed below to install the Converter onto a desktop location. 1. Locate the Converter in a clean, flat and safe position that has easy access to AC power. 2. Affix the four (4) self-adhesive rubber pads to the underside of the Converter 3. -
Page 18: Connecting Fiber Cable
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Check the front-panel LEDs as the device is powered on to verify that the Power LED is lit. If not, check that the power cable is correctly and securely plugged in. Note: For International use, you may need to change the AC power adapter cord. -
Page 19: Connecting Copper Cable
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Warning Because invisible laser radiation may be emitted from the aperture of the fiber port when no cable is connected, avoid exposure to laser radiation and do not stare into the open apertures. Connecting Copper Cable The 100BaseTX RJ-45 Ethernet port fully supports auto-sensing and auto-negotiation. -
Page 20: Chapter 4: Led Indicators
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter LED I NDICATORS This Converter has LED indicators located at the front of the device. The LEDs have been designed to give easy at-a-glance network status, and provides ‘real-time’ connectivity information. Please below interpretation of their functions:... -
Page 21: Cables
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter PPENDIX A Cables The following are some recommendations as to what you should and should not do when installing cables. Remember - cables are the deciding factor in network performance. Try to Try not to... -
Page 22: About Rj-45 Cables
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter PPENDIX B About RJ-45 Cables When connecting your network devices, use standard Category 3 eight-way cables for 10Base-T configurations and Category 5 cable for 100BaseTX. The pin assignments are as follows: Pair White/Orange Pair... -
Page 23: Appendix C: Application Diagram
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter PPENDIX C Application Diagram I In the figure below, the Converter is functioning as a high-speed bridge between switches creating increased capacity for each user (node) on the local area network. It is providing a 100Mbps full duplex link to a variety of Fast Ethernet network devices within a LAN. -
Page 24: Application Diagram Iii
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter Application Diagram III In the figure below, the Converter is functioning as a high-speed dedicated link within a campus network configuration. It is providing a 100Mbps full duplex link to a remote network node. -
Page 25: Contact Information
Signamax 065-1100NS/1110NS/1120NS Series 100BaseTX/FX Media Converter ONTACT NFORMATION SIGNAMAX™ CONNECTIVITY SYSTEMS An AESP Company 1810 N.E. 144th Street. North Miami, Florida 33181, U.S.A. Phone: 305-944-7710 Fax: 305-652-8489 Sales: 800-446-2377 Tech. Support: 800-446-2377, ext. 201 Http://www.signamax.com E-mail: info@signamax.com EUROPE AESP Ukraine. (UKRAINE) AESP Russia.
