- Page 1 Signamax™ Connectivity Systems 10BaseT to 10BaseFL Converter Model 065-1140 Multimode Model 065-1150 Singlemode ’ S E R U I D E...
- Page 2 ™ Signamax Connectivity Systems 10BaseT to 10BaseFL Converter Model 065-1140 Multimode Model 065-1150 Singlemode User’ s Guide...
-
Page 3: Fcc Warning
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter FCC Warning This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Trademarks Product names mentioned in this manual may be trademarks or registered trademarks of those products and are hereby acknowledged. • Ethernet is a trademark of Xerox Corporation. • Microsoft Windows is a trademark of Microsoft Corporation.
-
Page 5: Table Of Contents
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter ABLE OF ONTENTS CHAPTER 1:INTRODUCTION … … … … … … … … … … 1 PRODUCT OVERVIEW.… … … … … … … … … … .… … .…... -
Page 6: Chapter 1:Introduction
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter NTRODUCTION Product Overview: The 10BaseT to 10BaseFL Converter is primarily designed for network or data installations that require the migration of cable media between conventional coppers based wiring to Fiber based installations. - Page 7 Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Outlook for model 065-1140 10BaseT to 10BaseFL Converter with ST multimode connector Outlook for model 065-1150 10BaseT to 10BaseFL Converter with SC singlemode connector Introduction...
-
Page 8: Features
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Features • Complies with 802.3 10BaseT/FL standard • MDI/MDIX push button selection for RJ-45 port connection • Supports ST multimode (model 065-1140) or SC singlemode (model 065-1150) fiber connector •... -
Page 9: Specification
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Specifications Standard: IEEE 802.3u Connector: 1 RJ-45, 1 ST for multimode or SC for singlemode Max. Distance: Twisted Pair: 100 m (330 ft) Multimode fiber: 2 km (6,600 feet) Singlemode fiber: 12 km (39,600 feet) -
Page 10: Package Contents
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Package Contents • One Converter • One AC adapter • Four Self-Adhesive feet • This Operation Manual Introduction... -
Page 11: Chapter 2: Installation
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter NSTALLATION To successfully install your converter, please refer to the following procedures: • MDI/MDI-X Connection • Positioning of Converter • Install Your Converter MDI/MDI-X Connection The MDI/MDI-X function alleviates the worry of type of cable to use to connect the converter with a 10BaseT device. -
Page 12: Positioning Of Converter
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Crossover Selection Table Location of Crossover Switch Positioning of Converter In order to achieve the aim of effectively expanding an Ethernet network, one solution is to position two converters back to back between the following end devices: Example 1 •... - Page 13 Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Example 2 • A LAN Switch and a network’s server Switch --- Converter --- Converter --- Server 10Base Switch Fiber Cable 100M Multimode 2 km Singlemode 12 km Server 100M Example 3 •...
- Page 14 Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Example 4 • A 10BaseT Network and a FL device FL --- Converter --- Switch --- Hub --- WS Workgroup Printer with Fiber Print Server Fiber Cable Multimode 2 km...
-
Page 15: Install Your Converter
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Install Your Converter Converter to 10BaseT Device Connection 1. Make sure that the length for the straight through twisted pair cable (Category 3 or better) between the 10BaseT device (hub or switch) and the converter is no longer than 100 meters. -
Page 16: Chapter 3: Led Indicators
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter LED I NDICATORS This converter has several LED to enable you to determine the status of the converter and to also see what is happening across your network. Their functions are as follows. -
Page 17: Chapter 4: Mounting
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter OUNTING This converter can be placed in any location that will make its installation convenient. If you place the converter on a work surface or on top of existing networking equipment you may add the four rubber feet included in the packaging. - Page 18 Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter Connector End Bottom of Converter Mounting...
-
Page 19: Chapter 5: Cables
Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter ABLES The following are some recommendations as to what you should and should not do when installing cables. Remember - cables are the deciding factor in deciding if a network performs to the maximum throughput. - Page 20 Signamax™ 065-1140 series and 065-1150 series 10BaseT to 10BaseFL Converter ONTACT NFORMATION SIGNAMAX™ CONNECTIVITY SYSTEMS An AESP Company 1810 N.E. 144th Street. North Miami, Florida 33181, U.S.A. Phone: 305-944-7710 Fax: 305-652-8489 Sales: 800-446-2377 Tech. Support: 800-446-2377, ext. 201 Http://www.signamax.com E-mail: info@signamax.com...
