Summary of Contents for Cumberland G50CBF16GA
- Page 1 50" Butterfly Fan Model: G50CBF16GA Installation and Operation Manual PNEG-1425 Date: 10-28-09 PNEG-1425...
- Page 2 Before beginning installation, check the condition of the fan. Remove the overwrap and packing materials and examine all parts and components for shipping damage. Any damage incurred must be reported immediately to the freight carrier. Model : G50CBF16GA Size : 50" Galvanized Housing and Cone Voltage...
-
Page 3: Table Of Contents
Table of Contents Contents Chapter 1 Safety..............................4 Safety Guidelines ..........................4 Safety Instructions ..........................5 General Safety Information ........................ 7 Chapter 2 Decals..............................9 Warning Decals and Locations ......................9 Chapter 3 Installation ............................10 Framing and Positioning ........................10 Installation of the Fan on a Vertical Plane .................. -
Page 4: Chapter 1 Safety
1. Safety Safety Guidelines This manual contains information that is important for you, the owner/operator, to know and understand. This information relates to protecting personal safety and preventing equipment problems. It is the responsibility of the owner/operator to inform anyone operating or working in the area of this equipment of these safety guidelines. -
Page 5: Safety Instructions
1. Safety Safety Instructions Our foremost concern is your safety and the safety of others associated with this equipment. We want to keep you as a customer. This manual is to help you understand safe operating procedures and some problems which may be encountered by the operator and other personnel. As owner and/or operator, it is your responsibility to know what requirements, hazards and precautions exist, and to inform all personnel associated with the equipment or in the area. - Page 6 1. Safety Prepare for Emergencies Be prepared if fire starts. Keep a first aid kit and fire extinguisher handy. Keep emergency numbers for doctors, ambulance service, hospital and fire department near your telephone. Keep Emergency Equipment Quickly Accessible Wear Protective Clothing Wear close fitting clothing and safety equipment appropriate Eye Protection to the job.
-
Page 7: General Safety Information
In the installation and use of the Butterfly Fan only genuine Cumberland parts are to be used. Use of other non-genuine parts is a misuse and may lead to dangerous situations. - Page 8 Provisions for an adequate and safe power supply to the fan unit are essential to your safety. Cumberland recommends that a competent and qualified electrician undertake all electrical wiring. All wiring is to be installed in accordance with National, State, and Local electrical codes. Fans used to ventilate livestock buildings and other rooms where continuous air movement is essential should be connected to individual electrical circuits with a minimum of two circuits per room.
-
Page 9: Chapter 2 Decals
2. Decals Warning Decals and Locations WARNING WARNING STAY CLEAR OF SHEAR POINT ROTATING BLADE Keep hands clear of moving Blade may start automatically. parts. Do not operate with May cause serious injury. Disconnect and guard removed. Disconnect lockout power sources before servicing. -
Page 10: Chapter 3 Installation
3. Installation Framing and Positioning 1. Construct the opening frame to the correct size (55-1/4" H x 55-1/4" W) as shown below in Figure 3A. Remember, framing must be able to support the weight of the fan assembly. Ensure the load bearing portion of the bottom sill is rigid and properly supported. IMPORTANT: When installing more than one fan, maintain a minimum of 10"... -
Page 11: Installation Of The Fan On A Vertical Plane
3. Installation Installation of the Fan on a Vertical Plane Lifting Hazard. Single person lift could cause injury. Use two (2) or more people or a mechanical lifting device to lift/move heavy equipment. 1. Position the fan in front of the opening from the inside of the building. Using a minimum of two (2) people, lift fan housing into the opening. -
Page 12: Tabbed Cone Panel Assembly
3. Installation Tabbed Cone Panel Assembly Figure 3D Assembly Steps 1. Lay cone panels on the ground as shown in Figure 2. Slip four (4) cone panels together using tab and slot connections on edges of each panel. (Please note that all tabs must be on the inside of the cone assembly.) 3. - Page 13 3. Installation Nuts on outside of cone assembly Figure 3E Cone strut angles Figure 3F PNEG-1425 50" Galvanized Butterfly Fan...
-
Page 14: Butterfly Assembly
3. Installation Butterfly Assembly 1. Install the spring clip 16-0108 onto the butterfly frame bar using one (1) 1/4" x 20" x 1" bolt (S-6998) and one (1) 1/4" x 20" whiz nut (S-7215) as shown in Figure 2. The center bar of the butterfly frame weldment should be positioned vertically, with the bottom lining up with the slots farthest out on the cone and the top lined up with the slots farthest in on the cone. -
Page 15: Grill Guard Assembly
3. Installation Grill Guard Assembly Position grill guard lining up attachment hoops with the holes in the cone panels at 3, 6, 9, 12 o’clock positions. Attach and tighten using the 5/16" x 1" bolts and 5/16" whiz nuts. (See Figure 3I.) Figure 3I Inlet Grill Assembly 1. - Page 16 3. Installation Figure 3L Inlet Grill Hanging Hook - Top Figure 3M Inlet Grill Hanging Hook - Bottom PNEG-1425 50" Galvanized Butterfly Fan...
-
Page 17: Chapter 4 Wiring
4. Wiring Electrical Hookup As previously mentioned, All wiring should be installed in accordance with National, State and Local electrical codes. A certified electrician should complete this portion of the installation to ensure safety and that the wiring is correct for the application. 1. -
Page 18: Chapter 5 Operation
5. Operation Start-up and Operation of the Butterfly Fan Disconnect and lock out all power sources before servicing equipment. 1. With the fan de-energized, rotate the prop by turning the fan pulley, look for clearance between the prop tip and the housing. Replace all guards and check all fasteners to ensure they are tight. When satisfied, energize the fan and make note of direction of rotation. -
Page 19: Chapter 6 Troubleshooting
Do they all three appear even? (NOTE: They can be a little different without any problems.) If they are significantly different contact your Cumberland distributor for more information. 2. Is the noise coming from the bearings? Lubricate per instructions and energize the fan. Did the noise subside? If not, the bearings are probably damaged and in need of replacement. -
Page 20: Parts List
7. Parts List Part # Description 10-0200 Galvanized Cone Mounting Hardware 12-0312 50" Galvanized Butterfly Cone Bracket S-3611 Nut Flanged Whiz 5/16"-18 ZN YDP S-6606 Bolt Flanges 5/16"-18 x 3/4" ZN Grade 5 10-0103 Cord/Terminal Bag - Galvanized Fans 10-0102 Terminal Bag - Galvanized Fans S-7145 Cord, 96"-16/3 SJT w/ Male... - Page 21 7. Parts List Part # Description S-9351 Clip 7/8" x 43/64" HRCLP 34G 11-0342-WH Guard, 59" 50" Short Fan Paint 12-0274 Venturi, 50" Butterfly Metal (50-1/2" I.D.) 12-0196 Top Panel 50" Galvanized Short Fan 12-0197 Bottom Panel 50" Galvanized Short Fan 12-0198 Left Panel 50"...
-
Page 22: Chapter 8 Exploded Diagram
8. Exploded Diagram PNEG-1425 50" Galvanized Butterfly Fan... - Page 23 8. Exploded Diagram Exploded Diagram Ref # Part # Description 11-0333 Inlet Grill 12-0197 Bottom Panel 12-0199 Right Panel 12-0401-6Y Butterfly Frame 12-0198 Left Panel 12-0196 Top Panel 12-0306 50" Galvanized Butterfly Cone Panel 12-0311 50" Galvanized Butterfly Bottom Cone Panel 12-0406 Butterfly Flap 50"...
- Page 24 NOTES PNEG-1425 50" Galvanized Butterfly Fan...
-
Page 25: Chapter 9 Warranty
Lifetime 5 to 7 years - end-user pays 50% Feeder System Pan Assemblies 5 Years ** 7 to 10 years - end-user pays 75% Cumberland Feed Tubes (1-3/4" and 2.00") 10 Years * ** Warranty prorated from list price: Feeding/Watering... - Page 26 This equipment shall be installed in accordance with the current installation codes and applicable regulations which should be carefully followed in all cases. Authorities having jurisdiction should be consulted before installations are made. 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com...
