- Page 1 APP Series Fans Installation and Operation Manual PNEG-876 Date: 07-25-13 PNEG-876...
- Page 2 This fan is not designed for use in atmospheres where risk of explosion is foreseen. Such environments may include enclosed areas of high dust concentrations, gas vapors and fumes. Use in such an atmosphere is prohibited. If in doubt contact AP/Cumberland or your dealer. Retain instructions for future reference.
-
Page 3: Table Of Contents
Electrical Wiring ...........................12 Direct Drive Wirings ..........................12 Chapter 7 Dimension Chart ..........................17 Chapter 8 Parts List .............................18 Chapter 9 50" Cone Assembly ..........................20 Cone Assembly Detail ..........................21 Cone Mounting Detail ...........................21 Guard Detail ............................22 Chapter 10 Warranty ............................23 PNEG-876 APP Series Fans... -
Page 4: Chapter 1 Safety
CAUTION, used with the safety alert symbol, indicates a CAUTION hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE is used to address practices not related to NOTICE personal injury. PNEG-876 APP Series Fans... -
Page 5: Safety Instructions
Only genuine AP/Cumberland parts are to be used in the installation and use of the APP Fan. Use of other non-genuine parts is a misuse of the system and may lead to dangerous situations imperilling the safety and health of you and others. -
Page 6: General Safety Information
Before restarting the APP Fan, ensure that all electrical enclosures are locked closed and all guards and other safety measures are correctly fitted. If in any doubt, contact your dealer or AP/Cumberland for assistance. General Safety Information This unit should be assembled and installed by a qualified technician. -
Page 7: Chapter 2 Decals
The following pages show you exactly where the safety signs and warnings (decals) should be placed on your APP Fan. If a decal is missing, damaged or unreadable, please contact your dealer or AP/Cumberland for a free replacement. WARNING SHEAR POINT Keep hands clear of moving parts. - Page 8 May cause serious injury. Disconnect and lockout power sources before servicing. WARNING HIGH VOLTAGE. FLYING OBJECTS Will cause serious HAZARD. injury or death. Danger of eye injury. Lockout power Wear eye protection. before servicing. DC-1540 Motor mount plate PNEG-876 APP Series Fans...
-
Page 9: Chapter 3 Installation
(Motor terminal connection data is provided on motor nameplate and in this manual.) Use adequate size wire for all branch and feeder runs. When speed control is used, follow the installation procedures recommended by the speed control manufacturer. Re-install electrical cover. Unit is now ready for operation. PNEG-876 APP Series Fans... -
Page 10: Chapter 4 Operation
1. Set thermostat setting to a desired temperature. Fan will operate only when ambient temperature is above the thermostat set temperature. 2. Some controllers have idle speed controls. Set idle speed such that the blade RPM is within the RPM range listed in the performance table. PNEG-876 APP Series Fans... -
Page 11: Chapter 5 Maintenance
It is advisable to clean blade and shutter at regular intervals. This will remove any accumulated dirt, which would cause fan blade to become unbalanced and result in excessive vibration and poor performance. Lubrication Motor is pre-lubricated at factory and will not require any further lubrication. PNEG-876 APP Series Fans... -
Page 12: Chapter 6 Wiring
For electrical connection requirements, refer to Figure 6A on motor nameplate and to information enclosed with the “AVS” fan control to be used. Figure 6A Direct Drive Wirings Figure 6B To reverse, interchange Red and Black leads. PNEG-876 APP Series Fans... - Page 13 Back-up thermostats such as the TH-1, should always be used in conjunction with the control system. These should be placed on a separate circuit to give the animals ventilation in the event that the controller fails. PNEG-876 APP Series Fans...
- Page 14 APP-12F* Speed Curve #9 Volts CFM without Cone CFM with Cone 1765 1432 1675 1351 1575 1251 1475 1133 1375 1275 1175 1075 * Add - BLK suffix to end of fan model for black fans. PNEG-876 APP Series Fans...
- Page 15 1575 3251 3898 1475 3012 3664 1375 2786 3480 1275 2508 3168 1175 2202 2788 1075 1990 2431 1710 2102 1396 1722 1401 * Add - BLK suffix to end of fan model for black fans. PNEG-876 APP Series Fans...
- Page 16 APP-36F* Speed Curve #5 Volts CFM without Cone CFM with Cone 9260 11000 7894 9421 6587 7764 5482 6293 3516 2953 1286 1362 * Add - BLK suffix to end of fan model for black fans. PNEG-876 APP Series Fans...
-
Page 17: Chapter 7 Dimension Chart
22" 25-3/8" APP-24F* 22" 26" APP-24FC* 41" 23-3/8" 31-7/8" APP-36F/APPB-36F* 30-1/4" 37-7/8" APP-36FC/APPB-36FC* 54-1/2" 27" 44-3/8" APPB-50* 34-1/4" 50-3/8" APPB-50C* 55" 24" 56-3/8" * Add - BLK suffix to end of fan model for black fans. PNEG-876 APP Series Fans... -
Page 18: Chapter 8 Parts List
11-0194 11-0192 11-0219 Right Motor Mount 11-0195 11-0191 11-0218 Left Motor Mount PS-15SC PS-18C PS-24C PS-32C PVC Shutter * * For black fans add -BLK suffix after the housing, cone, grill and PVC shutter part numbers. PNEG-876 APP Series Fans... - Page 19 (CR) 16-0083 / (SS) 16-0004 Shaft 1016-0100 1016-0100 Bearing PVC Shutter * PS-42C PS-54C HD42 HD54-F Optional Aluminum Shutter * For black fans add -BLK suffix after the housing, cone, grill and PVC shutter part numbers. PNEG-876 APP Series Fans...
-
Page 20: Chapter 9 50" Cone Assembly
Part # Description S-8724 Fender Washer 5/16" x 1-1/2" x 1/16" SS S-8452 Flange Nut 5/16"-18 SS Waxed (Must be Waxed) S-7447 Flange Bolt 5/16"-18 x 1" SS (Full Thread) S-8168 Flange Bolt 5/16"-18 x 1-1/2" SS PNEG-876 APP Series Fans... -
Page 21: Cone Assembly Detail
Place the cone on the fan leaving a 2" overlap. Mark the nine (9) holes around fan orifice. Remove cone and drill 7/16" holes where marked. Mount the cone using the 1-1/2" bolts, fender washers and flange nuts. Tighten all hardware including cone panels. Figure 9C PNEG-876 APP Series Fans... -
Page 22: Guard Detail
Mark and drill three (3) 7/16" holes in the center of each cone panel. Use 1-1/2" bolts, fender washers and flange nuts to mount guard. Tighten hardware evenly. Figure 9D PNEG-876 APP Series Fans... -
Page 23: Chapter 10 Warranty
GSI. Prior to installation, the end-user has the responsibility to comply with federal, state and local codes which apply to the location and installation of products manufactured or sold by GSI. 9101239_1_CR_rev7.DOC (revised July 2009) PNEG-876 APP Series Fans... - Page 24 Authorities having jurisdiction should be consulted before installations are made. 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com AP/Cumberland is a part of GSI, a worldwide brand of AGCO Corporation. Copyright © 2013 by Group Printed in the USA CN-307573...
