Feed Shaft Mechanism

anita-b
Part No.
Ref.No.
GP/ 610280
D3-1
GP/ 119085
D3-2
GP/ 133283
D3-3
GP/ 215124
D3-4
GP/ 118600
D3-5
GP/ 119084
D3-10
GP/ 118601
D3-11
GP/ 119521
D3-12
GP/ 130224
D3-13
GP/ 335902-1
D3-14
GP/ 119521-1
D3-15
GP/ 700689
D3-16
GP/ 118603
D3-17
GP/ 118893
D3-18
D3
Name of Part
Retaining Ring
Washer
Washer
Needle Bearing
Bushing
Shaft
Bushing
Crank
Screw (M5x0,8x12)
Screw (M6x0,75x8)
Crank
Screw (M6x0,75x4,5)
Bushing
Collar
31
GP-510-446(7)
Q´ty
1
1
6
3
1
1
1
1
4
2
1
3
1
1
