Anita GARUDAN GF-2207-147 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GF-2207-147, GF-2210-447
GF-2210-147, GF-2210-447
ANITA B s.r.o.
Průmyslová 2453/7
680 01 Boskovice
Czech Republic
tel: +420 516 454 774
+420 516 453 496
fax: +420 516 452 751
e-mail:
info@anita.cz
User´s Manual
MP03700EN_181101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GARUDAN GF-2207-147 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anita GARUDAN GF-2207-147

Summary of Contents for Anita GARUDAN GF-2207-147

  • Page 1 User´s Manual GF-2207-147, GF-2210-447 GF-2210-147, GF-2210-447 ANITA B s.r.o. Průmyslová 2453/7 680 01 Boskovice Czech Republic tel: +420 516 454 774 +420 516 453 496 fax: +420 516 452 751 e-mail: info@anita.cz MP03700EN_181101...
  • Page 2 CREATED ON APPROVED BY MP03700EN_181101 01. 11. 2018 Jakub Lžičař All rights reserved. Property of Anita B s.r.o. and protected by copyright. The use of this content without written permission is prohibited. Copyright © Anita B s r.o. (2018) MP03700EN_181101...

  • Page 3: Table Of Contents

    © ANITA Content Safety Instrictions ........................4 1. Names of Major Parts ......................7 2. Machine Specifications ......................8 3. Optional Parts ......................... 9 4. Installation ..........................10 5. Preparation Before Sewing ....................17 6. Sewing ..........................23 7. Thread Tension ........................24 8.

  • Page 4: Safety Instrictions

    © ANITA SAFETY INSTRICTIONS Safety indications end their meanings: Safety indications end their meanings: This instruction man ual and the indications and symbols that are used on the machine itself are ual and the indications and symbols that are used on the machine itself are...
  • Page 5 © ANITA CAUTION SEWING This sewing machine should only be This sewing machine should only be Attach all safety devices before using Attach all safety devices before using used by operators who have received by operators who have received the sewing machine. If the machine is sewing machine.
  • Page 6 © ANITA MAINTENANCE AND INSPECTION MAINTENANCE AND INSPECTION Maintenance and inspection machine Maintenance and inspection machine If the power switch need to be If the power switch need to be left on should only be carried out by a should only be carried out by a...

  • Page 7: Names Of Major Parts

    © ANITA 1. NAMES OF MAJOR PARTS Face plate Bobbin winder Machine pulley Belt cover ① ② ④ ⑤ Reverse Stitching lever Stitch length dial Needle plate ⑥ ⑦ ⑧ Thread pillar ⑪ Safety device Finger guard Thread take-up cover ⑨...

  • Page 8: Machine Specifications

    © ANITA 2. MACHINE SPECIFICATIONS GF-2207-147 – Twin needle needle feed lock stitcher GF-2210-147 – Twin needle needle feed split needle bar lock stitcher GF-2207-147 GF-2210-147 Medium- Medium- VERY Thin Thick Thick Application thick thick thick material material material material...

  • Page 9: Optional Parts

    © ANITA 3. OPTIONAL PARTS Upper thread tension assembly: The following types of upper thread tension assembly are available for use with different thread take-up spring types and different thread tension spring strengths. Part code Thread tension spring type Thread take-up spring strength...

  • Page 10: Installation

    © ANITA 4. INSTALLATION CAUTION Do not connect the power cord until Do not connect the power cord until Machine ins tallation should only be tallation should only be installation is complete. The machine installation is complete. The machine carried out by a qualified technician.
  • Page 11 © ANITA Returning the machine head to the upright position: Returning the machine head to the upright position: 1. Clear away any tools, etc. Which may be near the table etc. Which may be near the table holes. 2. While holding the face plate with your 2.
  • Page 12 © ANITA Installing the machine head: 1. Insert the knee lifter complying bar ① 2. Insert the two hinges into the holes in ② the machine bed. 3. Clamp the hinges onto the rubber ② Cushions in the work table, and then place the ③...
  • Page 13 © ANITA 6) Turn the screw until the distance between the ⑩ end of the screw and the knee lifter ⑩ ⑦ approximately 8mm. 7) Turn the screw to adjust so that the presser foot ⑩ is at the desired position within a distance of 13mm ⑤...
  • Page 14 © ANITA DANGER Touch ing areas where high voltages are present can result in severe injury. ing areas where high voltages are present can result in severe injury. ing areas where high voltages are present can result in severe injury.
  • Page 15 © ANITA Installing the cotton stand: Assemble the cotton stand while referring to the ① cotton stand instruction manual, and then install the cotton stand to the far right comer of the work ① table. Lubrication:  The sewing machine should always be lubricated and the oil supply replenished before it is used for the first time, and also after long periods of no-use.
  • Page 16 © ANITA If the lubricating oil level drops below the bottom reference line (2) of the oil gauge window (1) be sure to add more oil. Checking the machine pulley rotating direction: Insert the power cord plug into the wall outlet, and then turn on the power switch.

  • Page 17: Preparation Before Sewing

    © ANITA 5. PREPARATION BEFORE SEWING Installing the needle: GF-2207-147, GF-2207-447 GF-2210-147, GF-2210-447 1. Turn the machine pulley to move the needle bar to its highest position. Loosen the screws, hold the needles with their long groove fasting inward, insert them all the way into the needle bars, and re-tighten the screws.
  • Page 18 © ANITA Winding the lower thread: 1. Turn on the power switch. 2. Place the bobbin into the bobbin winder ① shaft ② 3. Wind the thread several times around the bobbin in the direction indicated by the arrow. ①...
  • Page 19 © ANITA Installing the bobbin or cap: Installing the bobbin (GF-2207-147, GF-2207-447) 1. Turn the machine pulley to raise the needle to its highest position. ① 2. Insert the bobbin into the rotate hook ② so that the winding direction is as shown in ③...
  • Page 20 © ANITA Thread the Upper thread:  Turn the machine pulley and raise the thread take-up laver before threading the upper thread. This will make threading easier and it will prevent the thread from coming out at the sewing start.
  • Page 21 © ANITA Adjusting the stitch length: GF-2207-147, GF-2207-447 GF-2210-147, GF-2210-447 Turn the stitch length dial clockwise or counter clockwise that the desired stitch length is at the uppermost position on the dial.  The larger the number, the longer the stitch longer will be.
  • Page 22 © ANITA To stop operation of the right needle bar: Move the stop lever to the R position. ① To resume twin-needle sewing: Press the push lever The stop lever will ⑦. ① then return to its original position automatically.

  • Page 23: Sewing

    © ANITA 6. SEWING Sewing: 1. While holding the two upper threads with your fingers, turn the machine pulley by hand toward you until the lower threads come out onto the feed dog. 2. Pull the lower thread toward you and check that they pull out smoothly.

  • Page 24: Thread Tension

    © ANITA 7. THREAD TENSION Adjusting the thread tension: Good even stitches Upper thread tension too weak or lower thread tension too strong. Upper thread tension too strong or lower thread tension too weak. Lower thread tension The tension of the lower thread varies with...
  • Page 25 © ANITA Upper thread tension After the lower thread tension has adjusted, adjust the upper thread tension so that a good, even stitch is obtained. 1. Lower the presser foot. 2. Adjust by turning the thread tension nut ② Adjusting the presser foot pressure:...

  • Page 26: Cleaning

    © ANITA 8. CLEANING The following cleaning operations should be carried out each day in order to maintain the performance of this machine and to ensure a long service life. Furthermore, if the sewing machine has not been used for along period of time, carry out the following clearing procedures before using it again.

  • Page 27: Standard Adjustments

    © ANITA 9. STANDARD ADJUSTMENTS Adjusting of the feed dog height: 1. Turn the pulley until the feed dog rises to the highest position. ① 2. Tilt back the machine head. 3. Loosen Screw and raise or ② lower the feed dog holder so that ③...
  • Page 28 © ANITA Adjusting the thread tension spring: Thread take-up spring tension The standard tension for thread take-up spring L and thread take-up spring R ① ② is 0.147-0.343N(15 - 35g)for both spring.(Thread take-up spring L ① 1. Open the face plate.
  • Page 29 © ANITA Operating range of thread take-up spring The standard operating range for thread take-up spring L and thread take-up ① spring R is 5-10mm for both springs. ② 1. Loosen the left and right screws ③ then turn the left and right thread take-up...
  • Page 30 © ANITA Adjusting the needle and rotary hook timing: Needle rotary hook point gap 1. Tilt back the machine head. 2. Loosen screws Ⓐ Ⓑ Ⓒ 3. Move the rotary hook base to the ① left or right so that the clearance between the needle and the rotary hook is 1-3mm.
  • Page 31 © ANITA Clearance between rotary hook and opener 1. Loosen the setscrew ⑪ move the opener to the left or ① right to adjust so that the clearance between the rotary hook and the opener ⑦ ⑩ 0.2mm when the opener ⑩...
  • Page 32 © ANITA [GF-2207-147, GF-2207-447] Needle bar lift amount GF-2207-147 GF-2210-447 Stitch Length 2 mm 2 mm 3 mm 3 mm Needle bar height (H) 2.4 mm 2.4 mm 2.4 mm 7. Remove the needle plate. 8. Remove the feed dog.
  • Page 33 © ANITA GF-2210-147 GF-2210-447 Stitch length 2 mm 2 mm Needle bar height (H) 2.4 mm 2.4 mm 1. Remove the needle plate. 2. Remove the feed dog. 3. Set the stitch length to eighter 2(approx. 2mm) on 3(approx. 3mm) or the scale, depending on the model and specifications of the machine (refer to the table).
  • Page 34 © ANITA Adjusting the rotary hook lubrication Adjusting the rotary hook lubrication amount: CAUTION Be careful not to touch your fingers or the lubrication amount check sheet against moving Be careful not to touch your fingers or the lubrication amount check sheet against moving...
  • Page 35 © ANITA Adjusting of the needle and feed timing: 1. Remove the needle. 2. Remove the belt cover. 3. Tilt the machine head back and remove the timing belt ① 4. Turn the machine pulley until the A mark is aligned with the red dot.
  • Page 36 © ANITA Checking the lubrication amount: After turning the lubrication adjustment screw to adjust the lubrication amount operate the machine for 5-10 minutes before checking the lubrication amount. 1. Remove the needle. 2. Remove the bobbin or the cap. 3. Turn on the power.
  • Page 37 © ANITA Thread Wiper Adjustment: 1. Stop the machine while needle bar is at its highest position. 2. Turn off the power switch. 3. Set the stitch length to 2 on the scale.  Adjusting the forward and back position 4.
  • Page 38 © ANITA 8. Loosen the screws and raise or lower ⑥ the Stopper until the clearance between ⑦ the tip of thread wiper and the presser bar ① is about 3mm when the thread wiper ⑤ ① returns to is original position.
  • Page 39 © ANITA Movable and Fixed Knife Adjustment: Removing to movable and fixed knives 1. Remove the needles and raise the presser foot. 2. Loosen the screws , and then ① ② remove the needle plate ③ 3. Remove the holed screws ④...
  • Page 40 © ANITA Installing the movable and fixed knives 1. Turn the machine pulley by hand until the ooedres are pulled the way in the arrow direction. 2. Lightly secure the movable knife with screw. Install the movable knife on the top of the bobbin thread clamp spring.
  • Page 41 © ANITA Tension Release: If the thread slips out of the needle hole after thread cutting, or if the tension disc remain open, adjust as follows. A. If the thread slips out of the needle hole (The tension release lever is not working properly during thread cutting) 1.
  • Page 42 © ANITA Synchronizer Adjustment: Needle up position stop adjustment 1. Turn on the power. 2. Stop the machine while the needle bar is at its highest position. 3. The pulley reference line should be visible in the windows of the belt cover when the machine is ①...
  • Page 43 © ANITA Thread trimmer timing adjustment: Thread Trimmer Timing Adjustment 1. Remove the needles. 2. Hold the thread trimming solenoid ① depressed and turn the sewing machine pulley in its normal direction of rotation until the pulley become hard to turn(the movable knife will begin to move).

  • Page 44: Replacing Gauge Parts (Changing The Needle Width)

    © ANITA 10. REPLACING GAUGE PARTS (CHANGING THE NEEDLE WIDTH) How to change gauges 1. Turn the machine pulley to move the needle bar to its highest position. 2. Remove the needle ① 3. Remove the slide plate ② 4. Remove the needle clamp ③...
  • Page 45 © ANITA Adjust the rotary hook base Make the following adjustment when replacing the current gauge with one wider, the feed dog cannot be installed if this adjustment is not made. Loosen screw Ⓐ Ⓑ Ⓒ shift the rotary hook base right or left.
  • Page 46 © ANITA 4. Check the needle bar height. Turn the machine pulley to move the needle bar the its lowest position and adjust so that reference line is aligned as shown in the machine head. 5. Tilt back the machine head.
  • Page 47 © ANITA 7. Adjust the needle bar lift amount. 1) Set the stitch length to eight 2 (approx. 2 mm) or 3 (approx3ram) on the scale, depending on the model and specifications of the machine. (Refer to the table on page 17.)

  • Page 48: Installing Optional Parts

    © ANITA 11. INSTALLING OPTIONAL PARTS Replacing the rotary hook: Removal 1. Turn the machine pulley to move the needle bar to its highest position. 2. Remove the needle ① 3. Remove the slide plates ② 4. Raise the presser foot with the presser foot ④...
  • Page 49 © ANITA Installation 1. Insert the new rotary hook into the mounting hole ⑪ 2. Install the needles ① 3. While referring to pages 34, adjust so that the rotary hook tip ⑭ aligned with the center of the needle when the needle bar is raised ①...
  • Page 50 © ANITA 4. Return the machine head to its original 4. Return the machine head to its original position. 5. Install the opener ⑦ 6. Install the feed dog ⑥ ⑥ 7. Install the needle plate 7. Install the needle plate ⑤...
  • Page 51 © ANITA Replacing the upper thread tension assembly: Removal 1. Open the faceplate. 2. Loosen the screw ① 3. Loosen the screw and then remove ② the upper thread tension assembly ③ Installation 1. Install the new upper thread tension...

  • Page 52: Troubleshooting Guide

    © ANITA 12. TROUBLESHOOTING GUIDE Be sure the check the following before calling an authorized service station. Problem Where to check Page 1. Sewing machine pulley doesn’t turn.  Is a breaker or fuse blown?  Is the power cord disconnected? 2.
  • Page 53 © ANITA Problem Where to check Page 4. Skipped stitches.  Is the needle tip bent? Is the needle tip blunt? If the needle tip is bent or broken, replace the needle.  Is the needle properly installed? If it is incorrect, install the needle correctly.
