- Page 1 User´s Manual GS-842-141 ANITA B s.r.o. Průmyslová 2453/7 680 01 Boskovice Czech Republic tel: +420 516 454 774 +420 516 453 496 fax: +420 516 452 751 e-mail: info@anita.cz MP03500EN_180831...
- Page 2 CREATED ON APPROVED BY MP03500EN_180831 31. 08. 2018 Jakub Lžičař All rights reserved. Property of Anita B s.r.o. and protected by copyright. The use of this content without written permission is prohibited. Copyright © Anita B s r.o. (2018) MP03500EN_180831...
-
Page 3: Table Of Contents
© ANITA Content 1. Introduce the Stitcher´s Parts with Figure ................4 2. Machine´s Set up ........................5 2. Machine´s Lubrication ......................5 3. The Explanation of Thread Setting ..................6 4. Machine´s Operation ......................7 5. Pedal ............................8 6. -
Page 4: Introduce The Stitcher´s Parts With Figure
© ANITA 1. INTRODUCE THE STITCHER´S PARTS WITH FIGURE A) Head part B) Triangular base C) Swing arm set D) Sewing part E) Thread tension regulator assy. F) Table plate G) Foot stock H) Pedal Motor J) Motor switch K) Pulley... -
Page 5: Machine´s Set Up
© ANITA 2. MACHINE´S SET UP 1. Don´t make a mistake. Please according to indicatory power supply (VOLTAGE) when wiring. 2. The turning direction of pulley is clockwise. (Shown as the red arrow on label). If the turning direction is error after start. First, to turn off the motor switch, and wait about six-seven minutes to let the motor´s pulley stop really. -
Page 6: The Explanation Of Thread Setting
© ANITA 3. THE EXPLANATION OF THREAD SETTING ** Please, as the step on the left fig 1 to set the thread Fig. 1 Fig. 2 Fig. 3 ** Please pay attention the lower and upper rods must be aim, shown as fig 2 for feed thread... -
Page 7: Machine´s Operation
© ANITA 4. MACHINE´S OPERATION Motor switch Fig. 4 There is a protective equipment of automatic power off system. If the is power overloaded or thread is clamped on the rotating hook, it will automatically be cut off, and then the small red lamp on locator will twinkle. -
Page 8: Pedal
© ANITA 5. PEDAL Fig. 5 Adjusting the stitch speed and controlling the presser foot lifting. It will start when press the pedal forward down (A direction). Press lightly forward down for slow speed and to strongly for fast speed. Press the pedal backward down (B direction), for auto-lifting the presser foot. -
Page 9: Swing Arm
© ANITA 6. SWING ARM Fig. 6 The correction method of operation. Please turn the swing arm as shown on the fig, when you stitch near to the border of front shoe-top. MP03500EN_180831... -
Page 10: The Presser Foot´s Up-Down Bar
© ANITA 7. THE PRESSER FOOT´S UP-DOWN BAR Fig. 7 On sewing stop, you can use presser foot up-down bar (shown as arrow A), let the presser foot to hoist or lower. To pull up the bar for hoist presser foot or pull down for lower presser foot. -
Page 11: Machine´s Adjust (The Opposite Station Of Needle And Shuttle (Step 1)
© ANITA 8. MACHINE´S ADJUST (THE OPPOSITE STATION OF NEEDLE AND SHUTTLE (STEP 1) Fig. 8 1. First, push the bottom (A), and turn the wheel clockwise by hand, until you hear a “KA” voice. Second, to turn the wheel counterclockwise by hand to make the distance of inner presser foot stitch length to zero and loosen the (A). -
Page 12: The Opposite Station Of Needle And Shuttle (Step 2)
© ANITA 9. THE OPPOSITE STATION OF NEEDLE AND SHUTTLE (STEP 2) Fig. 9 Loose three fixed screws (#756) from the right-side leading hold on triangular base. The shuttle hook at needle´s hollow station, depend on the distance of stitch length. (The longer the distance, the lower the hook´s station will be, but must attention, don´t adjust the needle bar too high or too low,... -
Page 13: Adjusting The Distance Of Stitch Length
© ANITA 10. ADJUSTING THE DISTANCE OF STITCH LENGTH Fig. 10 To push the (A) button first and then scratch the pulley and press-disc at the same time. To turn backward until you hear a „KA“ voice, in case of turning it clockwise (shown as arrow D), it´s long stitch length, in case of reversing it (Shown as arrow E), it´s short stitch length. -
Page 14: Adjustment Of Tension Complete Set
© ANITA 11. ADJUSTMENT OF TENSION COMPLETE SET Fig. 11 (Basic tension complete set): Please turn the nut (B) clockwise for more tension or counterclockwise for Less tension. (Automatic laxation complete set): When the lifting lever rise, the tension disk can auto-open for pull thread out conveniently. -
Page 15: Adjusting The Elasticity Of Thread Controllor Disc
© ANITA 12. ADJUSTING THE ELASTICITY OF THREAD CONTROLLOR DISC Fig. 12 (ADJUSTING THE CONTROL SPRING): The arc-plate (A) under control spring is to decide the lowest station of spring. In adjusting, to loosen the fixed screw (B) first, and move plate to needful station, and then tighten the screw. -
Page 16: The Synchronizer´s Setting And Adjustment
© ANITA 13. THE SYNCHRONIZER´S SETTING AND ADJUSTMENT Fig. 13 The function of synchronizer is to make the needle bar auto-stay at established station, when sewing stop every time. (The established station is needle bar drop 2mm from uppermost station). -
Page 17: The Protective Device With Clutch
© ANITA 14. THE PROTECTIVE DEVICE WITH CLUTCH Fig. 14 Border stitcher had been especially designed for protecting parts. As long as over-load in the motion, the wheel will automatically break main-shaft to take no-loaded motion, and power also will be cut off after two seconds. -
Page 18: Adjusting The Moving Distance In Height Of Inner Presserfoot
© ANITA 15. ADJUSTING THE MOVING DISTANCE IN HEIGHT OF INNER PRESSERFOOT Fig. 15 First, to loosen the thumb nut, and push the screw forward to make inner presser foot moving long distance or short distance in height of inner presser foot than before, and then tighten the thumb nut. -
Page 19: Adjusting The Pressure And Station Of Outer Presserfoot
© ANITA 16. ADJUSTING THE PRESSURE AND STATION OF OUTER PRESSERFOOT Fig. 16 To turn screw (shown as A) clockwise by hand, for more pressure of outer presser foot than before. Conversely, counter clockwise for less pressure. First loose the fixed screws (B), and make outer presser foot station on needle-plate, pull up the presser foot up-down bar for having a space about 0,5 –... -
Page 20: Adjust The Height Of Inner Presser Foot & Needle Bar
© ANITA 17. ADJUST THE HEIGHT OF INNER PRESSER FOOT & NEEDLE BAR Fig. 17 1. ADJUSTING THE HEIGHT OF INNER PRESSER FOOT: First loose the screw (shown as A) and push the rocking arm forward (shown as B) for lifting more height of inner presser foot and then tighten screws back. -
Page 21: Adjusting Set Of The Sewing Speed / Selection Of Presser Foot Lifting
© ANITA 18. ADJUSTING SET OF THE SEWING SPEED / SELECTION OF PRESSER FOOT LIFTING Fig. 18 When you need to adjust the sewing speed, in addition to press the pedal strongly also can set up the screen of motor control box. Please refer to the motor´s operational manual for operation details. -
Page 22: Other Attentive Items And Solution Of Breakdown
© ANITA 19. OTHER ATTENTIVE ITEMS AND SOLUTION OF BREAKDOWN Fig. 19 The elastic sheet (628-2) in shuttle and the adjusting screw (MB030003) in bobbin case, must adjust properly for ensuring feed thread smoothly. When the elastic sheet´s sides was worn seriously, please change it. -
Page 23: Adjusting The Pressure Of Bobbin Thread
© ANITA 20. ADJUSTING THE PRESSURE OF BOBBIN THREAD Fig. 20 Fig. 21 There are two adjusting methods Method1: Adjusting the elastic sheet in shuttle, to pull open sheet (showed as Fig.). To pull the sheet more open, the bobbin-threads more pressure, conversely push close for less. Please attention, don´t let the elastic sheet too lever to touch bobbin. -
Page 24: The Setting Method Of Bobbin Thread Into Bobbin Case
© ANITA 21. THE SETTING METHOD OF BOBBIN THREAD INTO BOBBIN CASE Fig. 22 Please as the above Fig. 22 to do, when you what to set the bobbin-thread again. MP03500EN_180831... -
Page 25: How To Access (Parameter Mode A): (Available Parametr Codes: 1 ~ 46)
© ANITA 21. HOW TO ACCESS (PARAMETER MODE A): (AVAILABLE PARAMETER CODES: 1 ~ 46) 22. HOW TO ACCESS (PARAMETER MODE B): (AVAILABLE PARAMETER CODES: 1 ~ 122) MP03500EN_180831... -
Page 26: Overview Of Parameters
© ANITA 23. OVERVIEW OF PARAMETERS NO. Code Parameter Range/Unit Factory settings Description Setting the maximum Maximum speed 50-9999 rpm 4500 speed MP03500EN_180831...
