Tire table
Type Designation Type
wheelchair
EXCEL® 'G6 Active' Self propel
EXCEL® 'G6 Active' Transit
Using the anti-tip wheels
Go to the back of the wheelchair;
-
When you get down to your knees you will see the operating system of the anti-tip wheels, see figure 39;
-
Retracting the silver round (figure 40) will cause the anti-tip wheel to slide;
-
Let go of the silver round when the anti-tip wheel touches the ground;
-
Make sure the anti-tip wheel is fastened correctly and does not move anymore;
-
When you do not want to use the anti-tip, retract the silver round with one hand, while pushing up the
-
anti-tip wheel, by sliding it up the holder.

5.12 Using accessories and other options on your wheelchair

The seat cushion
Your wheelchair is equipped with a 5 cm thick, nylon seat cushion. This seat cushion is equipped with an anti-skid
layer, see figure 41. You need to place the seat cushion with the anti-slip side down on your wheelchair. When you
are going to sit in the wheelchair the seat cushion will not move.
Tire size Maximum pressure
front front tires
5"X 1 ¼" 2,5 bar / 36 psi
6" X 1 ¼" 2,5 bar / 36 psi
8" X 1 ¼" 2,5 bar / 36 psi
5"X 1 ¼" 2,5 bar / 36 psi
6" X 1 ¼" 2,5 bar / 36 psi
8" X 1 ¼" 2,5 bar / 36 psi
Figure 39
~ 22 ~
Tire size Maximum pressure rear
rear tires
24" x 1" 7,5 bar / 110 psi
22" x 1 3/8" 4,5 bar / 65 psi
12" x 2 1/4" 2,8 bar / 40 psi
Figure 40
Figure 41
