Tyre table
Type Designation Type
wheelchair
EXCEL G3 'Eco' Self propel
Using the anti-tip wheels
- Go to the back of the wheelchair;
- At the bottom of the rear side of the side frame you can find the anti-tip wheels, picture 24;
- By pulling the silver round you can adjust the height of the anti-tip wheels;
- When you pull the silver round towards you, the anti-tip wheel will automatically slide downwards. Adjust the
anti-tip wheel to the desired height and let go of the silver round;
- The anti-tip wheels are adjusted in the best manner if you, if you are at the side of the wheelchair, can see
the anti-tip wheel stick out of the outside the rear wheel;
- Check if the anti-tip wheels are fastened correctly and aren´t moving anymore;
- When you do not want to use the anti-tip wheels you can adjust the anti-tip wheels in to the highest position.
Retract the silver round with one hand, while pushing up the anti-tip wheel, by sliding it up the holder.

5.10 Using accessories and other options on your wheelchair

The seat cushion (option)
Your wheelchair can be equipped with a 5 cm thick, nylon seat cushion. This seat cushion is equipped with an anti-
slip layer, see picture 25. You need to place the seat cushion with the anti-slip side down on your wheelchair.
When you are going to sit in the wheelchair the seat cushion will not move.
Tyre size Maximum pressure
front front tyres
7"X 1¼" 2,5 bar / 36 psi
8" X 1 ¼" 2,5 bar / 36 psi
Picture 25
~ 17 ~
Picture 23
Tyre size Maximum pressure rear
rear tyres
24" x 1 3/8" 4,5 bar / 65 psi
Picture 24
