5.13 Use of the headrest (optional item)

Removing and placing the headrest
You can remove the headrest by turning the black buttons, near the push handles (figure 46), on both sides
-
fully loosen. When these buttons are completely independently, you can remove the bolt and the headrest of
the wheelchair;
To place the headrest back onto the wheelchair you should repeat the above in reverse order;
-
Make sure the headrest is secure before use.
-
Adjusting the height of the headrest
At the back of the headrest, in the middle of the tube, there is a black button;
-
Turn this button, see figure 47;
-
You can now move the headrest up and down;
-
When the headrest is at the desired height you should fix it there;
-
Make sure the headrest is in place before use.
-
Figure 46
Adjusting the headrest
On the headrest there are three levers (figure 48) that allows you to adjust the headrest into the desired position.
These levers work in the following way:
Turn the levers separately, never simultaneously;
-
Move the headrest to the desired position;
-
Turn the lever back until they are tight and possibly do the same with the other levers (if an adjustment is
-
required);
Make sure the head is secure in place and that the three levers are not obstacles. Please note that you can
-
move the levers without loosening of fastening them;
You can also adjust the headrest by pulling the sides of the headrest in or outwards with your hands, see
-
figure 49.
Figure 47
Figure 49
