3-3. SETUP MENU Screen

If you press MENU Button in LIVE Mode, following window appears and you can
change various product settings.
※ For moving the menu, use Up/Down Button. For changing the setting, use
Left/Right Button.
※ In order to save the change of setting, you have to move to upper menu by pressing
ENTER Button after setting all menus. If you close by pressing EXIT Button without
pressing ENTER, changed setting is not saved.
※ If you have 4 or 8 ch, you can see some buttons are disable. Thai is, on the case of
8 ch, the button 9 to 16 will be disable.

3-3-1. A/V(Audio/Video)

In this menu, you can change setting for Audio and Video.
1) Signal Type: You can change NTSC/PAL using the slide switch in rear panel. It
causes not to display the right images, so be careful to change the signal type.
2) Channel Name: You can set the camera name.
42
CH 3 How to Use
