- Page 1 JetBox 8100 User Manual Hardware Copyright@2007 Korenix Technology Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Customer Service: KoreCARE@korenix.com V1.0...
-
Page 2: Copyright Notice
Korenix assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. Korenix reserves the right to make changes in the product design without notice to its users. Acknowledgments Korenix is a registered trademark of Korenix Technology Co., Ltd. -
Page 3: Table Of Contents
1.2 Hardware Specifications ............3 1.3 Dimension ..................4 1.4 Packing List ................4 Chapter 2: Hardware Functionality...............5 2.1 Introduction of JetBox 8100 external I/O Connectors ....5 2.2 VGA Connector ................5 2.3 PS2 Keyboard /Mouse Connector ..........6 2.4 COM 1 Connector ..............6 2.5 COM2 Connector ...............7 2.6 Ethernet Connector (LAN) ............7... - Page 4 4.8 PnP/PCI Configurations ............23 4.8.1 PNP OS Installed ..............24 4.8.2 Reset Configuration Data............24 4.8.3 Resources controlled by............24 4.8.4 PCI/VGA Palette Snoop ............24 4.9 PC Health Status..............24 4.10 Load Fail-Safe Default ............25 4.11 Load Optimized Default............25 4.12 Password Setup..............25 JetBox 8100 User Manual_HW_1.00...
- Page 5 4.13 Save & Exit Setup ..............26 4.14 Exit Without Saving ...............26 Chapter 5: Appendix ..................27 5.1 Revision History ..............27 5.2 Table/Figure Index ..............27...
-
Page 7: Chapter 1: Overview
Further, Korenix provides application development toolkits for users to build up their own applications easily. JetBox 8100 is a high performance, compact and rugged embedded computer. All-in-one device with small volume, fanless design and a capability to withstand a wide range of temperatures is suitable for industrial severe environment. -
Page 8: Highly Robust Coating Construction
1.1.2 Highly Compact Size With its maximum mounting wide of 44mm,the Jetbox 8100 can be used in limited space critical conditions 1.1.3 Highly Scalable Performance with low power consumption Scalable Low Voltage AMD Geode LX800 processor system to bring high computing performance with low power consumption 1.1.4 Optimized Integration... -
Page 9: Hardware Specifications
Construction Sheet metal case Dimensions 120.0mm(D)* 44.2mm(W)*123.0mm(H) 5℉~158℉(-15℃ ~ 70℃), 5 to 95% RH(w/o Operating Temperature Storage -4℉~176℉(-20℃ ~ 80℃), 5 to 95% RH(w/o Temperature Net Weight 0.7 kg CE/FCC class A Table 1-1 Hardware specifications JetBox 8100 User Manual_HW_1.00... -
Page 10: Dimension
Figure 1-2 Dimension 1.4 Packing List JetBox 8100 PS/2 Keyboard/Mouse adapter cable 2 pin power terminal block 44-pin flat cable w/4 screws for fix 2.5”HD Din-Rail mounting kit w/3 screws Quick Installation Guide Documentation and Software CD-ROM JetBox 8100 User Manual_HW_1.00... -
Page 11: Chapter 2: Hardware Functionality
Chapter 2: Hardware Functionality 2.1 Introduction of JetBox 8100 external I/O Connectors Figure 2-1 External I/O Connectors 2.2 VGA Connector VGA connector is provided for CRT display Signal Signal DDC Data Green DDC Clock Blue 5&10 Digital Ground Hsync 6,7,8... -
Page 12: Ps2 Keyboard /Mouse Connector
Keybaord Clock KB/MS Table 2-3 KB/MS Connector Pin Assignment 2.4 COM 1 Connector The DB9 (COM1) is standard serial port connector. The following tables show the pin assignment of connector. RS232 Table 2-4 COM1 Connector Pin Assignment JetBox 8100 User Manual_HW_1.00... -
Page 13: Com2 Connector
2.6 Ethernet Connector (LAN) The RJ45 connector with 2 LED’s for LAN. The right side LED(Orange) indicates data is being accessed and the left side LED(Green)indicates on-line status. Signal Signal Table 2-6 Ethernet Connector Pin Assignment JetBox 8100 User Manual_HW_1.00... -
Page 14: Usb Connector
2.7 USB Connector The JetBox 8100 supports a two port USB connector. Any USB device can be attached to USB ports with plug-and-play supported. Signal USBV USBD- USBD+ USBG Table 2-7 USB Connector Pin Assignment 2.8 Audio MIC/ Earphone Connector... -
Page 15: Power On/Off Button
ON: Power On Figure 2-9 Power ON/OFF Button 2.11 Reset Button The JetBox 8100 has a push button switcher for system reset. Push and release the button will cause hardware reset of JetBox 8100 and restart system booting. 2.12 LED Indicators The Power and HDD LED’s has two distinctive statuses: Off for inactive... -
Page 16: Chapter 3: Hardware Installation And Upgrade
3.2 Setting Jumpers You can configure your JetBox 8100 to match the need of your application by setting jumpers. A jumpers is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover)that slides over the pins to connect them. -
Page 17: Com2 Rs232/422/485 Jumper Setting (Jp2)
3.3 COM2 RS232/422/485 Jumper Setting (JP2) The COM 2 port located on front metal face plate of Jetbox 8100 unit which can be configured to operation in RS232, RS422 or RS485 mode by use BIOS setting or setting up the Jumper Pins of JP2 located on internal board of Jetbox 8100 unit. -
Page 18: Install The Ddr Sdram Memory Module
Memory Module) socket and supports 2.5V DDR SDRAM. You can install from 128MB to 512MB of DDR SDRAM memory. The procedure of installing a DDR SDRAM SODIMM into the JetBox 8100 is detailed below, please follow these steps carefully. 1. Remove the power cord. -
Page 19: Inserting A Compact Flash Card
The procedure of installing a Compact Flash card into the JebBox 8100 is detailed below, please follow these steps carefully. 1. Remove the power cord. 2. Unscrew the four screws from the bottom cover of the JetBox 8100. 3. Remove the bottom cover. 4. Plug a Compact Flash card into JetBox 8100. -
Page 20: Installing The 2.5" Hard Driver Disk (Hdd)
3.6 Installing the 2.5” Hard Driver Disk (HDD) You can attach one enhanced Integrated Device Electronics(IDE)hard disk driver to the JetBox 8100’s internal controller which uses a IDE slot. The advanced IDE controller supports faster data transfer. The following are instructions of installation: 1. - Page 21 Be careful with pin orientation when installing connectors and the cables. A wrong connection can easily destroy your hard disk.CN3 is used to connect a 2.5” HDD with included 44-pin flat cable. 3.7 Installing DIN Rail Kits Figure 3-5 DIN Rail Kits Installation JetBox 8100 User Manual_HW_1.00...
-
Page 22: Chapter 4: Award Bios Setup
“CMOS checksum error…” display screen message appearing. Then enter the “Setup” screen to modify the data. If the “CMOS checksum error…”message appears again and again, please check to see if you need to replace the battery in your system. JetBox 8100 User Manual_HW_1.00... -
Page 23: Entering Setup
Choose the “Standard CMOS Feature” option from the “Initial Setup Screen” menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. JetBox 8100 User Manual_HW_1.00... -
Page 24: Advanced Bios Features
Enabling this feature speeds up memory access. The commands are “Enabled” or “Disabled”. 4.4.3 Quick Power On Self Test This option speeds up the Power-On-Self-Test(POST) conducted as soon as the computer is turned on. When enabled, BIOS shortens or JetBox 8100 User Manual_HW_1.00... -
Page 25: First/Second/Third/Boot Other Device
This field allows you to limit access to the System and Setup. The default value is Setup. When you select System, the system prompts for the User Password every time you boot up. When you select JetBox 8100 User Manual_HW_1.00... -
Page 26: Advanced Chipset Features
You can configure CAS Latency time as Auto, 1.5, 2.0, 2.5, 3.0, 3.5. The system board designer should set the values in this field, depending on the DRAM installed. Do not change the values in this JetBox 8100 User Manual_HW_1.00... -
Page 27: Video Memory Size
The commands are “Enabled” or “Disabled”. It allows you to use onboard Audio function. 4.6 Integrated Peripherals 4.6.1 On-Chip IDE Channel 1 The commands are “Enabled” or “Disabled”. It allows you to use on-chip IDE channel 1. JetBox 8100 User Manual_HW_1.00... -
Page 28: Master/Slave Drive Pio/Udma Mode
This commands to setting Serial Port 2 mode. You can configure Serial Port 2 as RS232, RS422, RS485. The default setting for Serial Port 2 mode is RS232. 4.6.9 Lan 1 Controller This commands to enable onboard Lan1 controller. JetBox 8100 User Manual_HW_1.00... -
Page 29: Onboard Lan Boot Rom
This item allows you to boot up the system via LAN from remote host. The choices: Enabled, Disabled. 4.7 Power Management Setup The Power Management setup controls the CPU card’s “green” features to save power. 4.8 PnP/PCI Configurations JetBox 8100 User Manual_HW_1.00... -
Page 30: Pnp Os Installed
“Auto” automatically configures all of boot and Plug and Play devices but you must be using Windows95 or above. 4.8.4 PCI/VGA Palette Snoop This is left at “Disabled”. 4.9 PC Health Status JetBox 8100 User Manual_HW_1.00... -
Page 31: Load Fail-Safe Default
3. Then you can go on to set a user password(up to 8 character length) if required. Note that you cannot configure the password until the Supervisor password is set up. 4. Point to Save Settings and Exit and press Enter. JetBox 8100 User Manual_HW_1.00... -
Page 32: Exit Without Saving
This record is required for the system to operate. 4.14 Exit Without Saving Selecting this option and pressing<Enter> lets you exit the setup program without recording any new values or changing old ones. JetBox 8100 User Manual_HW_1.00... -
Page 33: Chapter 5: Appendix
Figure 2-8 Power Input Connector ………………………………………………….8 Figure 2-9 Power ON/OFF Button…………………………………………………...9 Figure 2-10 LED Indicators…………………………………………………………..9 Figure 3-1 Jumper 2 Setting…………………………………………………………12 Figure 3-2 SDRAM Installation……………………………………………………..13 Figure 3-3 Compact Flash Card Installation……………………………………….13 Figure 3-4 2.5” HDD Installation…………………………………………………...14 Figure 3-5 DIN Rail Kits Installation……………………………………………….15 JetBox 8100 User Manual_HW_1.00...
