Page 1: Quick Installation Guide
JetBox 9300 / 9310 Series Industrial Networking Computer Quick Installation Guide www.korenix.com V1.0... -
Page 2: Packing List
� 4-pin power terminal block � 10-pin DIO terminal block � Quick Installation Guide � Documentation and Software CD-ROM Overview 133.50 120.50 9.00 Korenix LAN 1 LAN 2 LAN 3 LAN 4 LAN1 LAN2 LAN3 Reset LAN4 JetBox 9310 4.00 66.00... -
Page 3: Power Consumption
Power Consumption: Single input: 5.4Watt at 12Volt, 6.72Watt at 48Volt P1 P2 SD Dual inputs: 5.28Watt at 12Volt, 7.2Watt at 48Volt Notice: Improper power input will damage the device. Power Signal Name Power Connector: Connect the DC power line to the DC terminal block at the bottom of JetBox 9300/9310 and turn on the power switch. - Page 4 Software Specifications (Linux2.6.21) The entire JetBox 9300/9310 system can be controlled by SNMP Routing: IP routed, static routing, per VLAN routing, NAT/DMZ, ICMP, ARP, Block/Allow IP or port address Managed Switch: Port configuration, MIB, NTP, VLAN, QoS, IP access control, E-mail warning, SMTP, System event log Device Drivers: SD Card, USB, Watchdog Timer, UART Linux Tool Chain: Gcc, uClibc...
-
Page 5: System Upgrade
JetView v1.1 (or above version) for device discovery and basic system LAN IP address modification. With future versions, more features will be supported. You can find the latest information on the Korenix website or by contacting Korenix Customer Support.
