- Page 1 JetBox 8100 User Manual Modbus Gateway Copyright@2007 Korenix Technology Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Customer Service: KoreCARE@korenix.com V1.0...
-
Page 2: Copyright Notice
Korenix assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. Korenix reserves the right to make changes in the product design without notice to its users. Acknowledgments Korenix is a registered trademark of Korenix Technology Co., Ltd. -
Page 3: Table Of Contents
Table of Contents JetBox 8100 User Manual ................i Modbus Gateway .................... i Copyright Notice ................ii Acknowledgments ................ ii Chapter 1 Modbus TCP to RTU/ASCII Gateway Application ...... 1 1.1 Overview ..................1 1.2 Arguments ..................2 1.3 Scenarios ..................2 1.4 Limitations .................. -
Page 5: Chapter 1 Modbus Tcp To Rtu/Ascii Gateway Application
Figure 1-1 shows the block diagrams of Modbus TCP to RTU/ASCII gateway application. Modbus JetBox 8100/8210/8220 Modbus RTU/ ModbusT2R.exe Master ASCII (HMI or Slave Modbus Modbus PLC) (PLC, RTU/ DCS) Slave ASCII Master Figure 1-1 Block Diagrams of Modbus TCP to RTU/ASCII Gateway Application JetBox 8100 User Manual_Modbus_1.0-r1.doc... -
Page 6: Arguments
Execute the “ModbusT2R.exe” with arguments “-f demo.ini” to start the gateway application with script file. Figure 1-4 shows this demo scenario. Script File Name: demo.ini Contents Description -p 5501 –s COM1: -b 9600 –m One Modbus TCP master on TCP port 5501 JetBox 8100 User Manual_Modbus_1.0-r1.doc... -
Page 7: Limitations
Modbus RTU/ASCII slave device with the same station ID is not allowed to join the gateway network. No TCP request buffering Modbus TCP master is not allowed to JetBox 8100 User Manual_Modbus_1.0-r1.doc... - Page 8 Multiple instances of gateway application are allowed. Executable without UI A standalone executable and no UI available. Not a service It’s not a service, no start and stop behaviors are supported. Table 1-5 Limitations While Running “ModbusT2R.exe” Application JetBox 8100 User Manual_Modbus_1.0-r1.doc...
-
Page 9: Chapter 2 Appendix
Table 1-3 Contents of the Script File “demo.ini”……………………………………………..2 Table 1-4 Scenario of Running “ModbusT2R.exe” with “demo.ini” Script File……………..3 Table 1-5 Limitations While Running “ModbusT2R.exe” Application……………………….3 2.2 Customer Service Korenix Technologies Co., Ltd. Business service : sales@korenix.com Customer service: koreCARE@korenix.com Web Site: http://www.korenix.com JetBox 8100 User Manual_Modbus_1.0-r1.doc...
