  • Page 1 JetBox 8210 User Manual Hardware www.korenix.com 00.080.03...
  • Page 2: Copyright Notice

    Korenix assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. Korenix reserves the right to make changes in the product design without notice to its users. Acknowledgments Korenix is a registered trademark of Korenix Technology Co., Ltd.
  • Page 3: Table Of Contents

    Compact Flash Card ..............14 3-4-4 SDRAM ..................14 3-4-5 Battery Backup SRAM (NVRAM)—Optional ....... 14 3-4-6 I2C EEPROM................15 3-4-7 Security EEPROM ..............15 RS232/422/485 Serial Ports ..............15 3-5-1 Overview .................. 15 3-5-2 Configuration ................15 Korenix | Overview...
  • Page 4 Digital Input and Output ..............16 3-6-1 Digital Input ................16 3-6-2 Digital Output ................17 Hardware Unique Serial Number ............17 Chapter 4 Appendix ..................18 Chart Index ..................18 Customer Service ................19 Overview | Korenix...
  • Page 5: Chapter 1 Overview

    JetBox 8210 is a high performance, compact and rugged embedded computer. All-in-one device with small volume, fanless design and a capability to withstand a wide range of temperatures is suitable for industrial severe environment. It is equipped with Intel Xscale PXA270 RISC processor and 128MB SDRAM (256MB optional) and supports Linux and WinCE5.0 to meet requirements of...
  • Page 6: Chapter 3 Hardware Feature

    Net Weight 1.07kg Chart 1 JetBox 8210 HW spec Chapter 3 Hardware Feature Dimensions The following figures show the dimensions of JetBox 8210. The following sections give you detailed information about the function of each I/O Hardware Feature | Korenix...
  • Page 7: Front Panel Io Connectors

    Chart 2 JetBox 8210 appearance Chart 3 JetBox 8210 ME drawing Front Panel IO Connectors 3-2-1 Power ON/OFF Switch This switch is used to turn the system power on and off. Korenix | Hardware Feature...
  • Page 8: Com Connectors

    “SerCon” control applet of the control panel to change the settings. COM3 and COM4 Connectors The JetBox 8210 provides 2 D-sub 9-pin connectors (COM3 and COM4) for RS-232 communication. Note the settings are stored in the EEPROM, not registry. It’s necessary to configure each hardware target manually or programmatically.
  • Page 9: Power Led Indicator

    This LED indicator is used to indicate the CF card access status. 3-2-5 Ethernet Connector A standard RJ-45 jack socket with LED indicators shows its Active/Link status (Green LED) and Speed status (Orange LED). Chart 7 Ethernet connector 10/100 BaseT Signal Name Korenix | Hardware Feature...
  • Page 10: Audio Connector

    10/100 BaseT Signal Name Chart 8 Ethernet connector PIN assignment 3-2-6 Audio Connector JetBox 8210 provides an AC97 stereo audio output with a 2.1 W amplifier and a mono MIC input. Chart 9 Audio connector Audio Signal Name OUT_R+ OUT_R-...
  • Page 11: Rear Panel Io Connectors

    Note: Because the frequency of JetBox 8210 VGA output is around 62 Hertz, not the general VGA 60 or 75 Hertz. Therefore, the VGA output of the JetBox 8210 is NOT fully compliant with all the VGA monitors, especially for some monitors without “Auto Sync”...
  • Page 12: Ethernet Connector (The Same As 3-2-5)

    3-3-3 Ethernet Connector (the same as 3-2-5) 3-3-4 Reset Button This button is used to reset the CPU causing the system reboot. 3-3-5 USB1 ~ USB4 Connectors JetBox 8210 provides 4 USB type “A” female connectors for USB peripherals. Hardware Feature | Korenix...
  • Page 13: Power Connector

    DATA- DATA+ Chart 16 USB connector PIN assignment 3-3-6 Power Connector JetBox 8210 comes with a Phoenix connector that carries a 9 ~ 36 VDC external power input. Chart 17 Power connector Power Signal Name Chart 18 Power connector PIN assignment...
  • Page 14: Boot Memory

    3-4-4 SDRAM JetBox 8210 supports 128 MB of SDRAM. The Windows CE Image occupies 16 MB to 50 MB depending on the model. The remainder 112 MB to 78 MB is arranged for Windows CE Object Store and applications.
  • Page 15: I2C Eeprom

    “SerCon” located in the control panel could be used to change the settings and save to the system EEPROM. Replace the CF card “B” of JetBox 8210 “B” with from a well configured CF card “A” of JetBox 8210 “A” will not change the serial port configurations of JetBox 8210 “B”. It’s suggested to configure the serial ports programmatically if a great quantity of JetBox 8210 is applied.
  • Page 16: Digital Input And Output

    Digital Input and Output 3-6-1 Digital Input JetBox 8210 supports 16 digital input channels. Refer with 3-3-1 Digital IO Connector for connector pin assignments. Below figures show 2 ways to use digital input function. Chart 20 Dry connect for digital input...
  • Page 17: Digital Output

    3-6-2 Digital Output JetBox 8210 supports 16 digital output channels. Refer with 3-3-1 Digital IO Connector for connector pin assignments. Below figure show how to use digital output function. Chart 22 Wet connect for digital output Hardware Unique Serial Number JetBox 8210 provides a 6 bytes hardware unique serial number for identification.
  • Page 18: Chapter 4 Appendix

    Chapter 4 Appendix Chart Index Chart 1 JetBox 8210 HW spec ..............6 Chart 2 JetBox 8210 appearance ..............7 Chart 3 JetBox 8210 ME drawing ..............7 Chart 4 Power switch ................. 8 Chart 5 COM connector ................8 Chart 6 COM connector PIN assignment .............
  • Page 19: Customer Service

    Customer Service Korenix Technologies Co., Ltd. 9F, No. 100-1, Ming-Chuan Rd., Shing Tien City, Taipei, Taiwan Tel:+886-2-82193000 Fax:+886-2-82193300 Business service: sales@korenix.com Customer service: koreCARE@korenix.com Korenix | Appendix...
