2.5

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table showing connectors on the hardware.
Connector
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
LAN1
SATA1
BAT1
SCN1
SCN2
SCN3
SDIMM1
Board and Pin Assignments
PICO121 AMD G-Series Embedded SoC Pico-ITX Board
Description
Power LED Header
High Speed Board to Board Connector
Low Speed Board to Board Connector
SMBus Connector
Fan Power Connector
LVDS Connector
Serial ATA Power Connector
Inverter Connector
SWIM Connector
DC Power In Connector
VGA Connector
Ethernet Connector
Serial ATA Connector
CMOS Battery Connector
Full-size PCI-Express Mini Card and mSATA Connector
SIM Card Slot
Half-size PCI-Express Mini Card Connector
DDR3/3L SO-DIMM Connector
