PICO121 AMD G-Series Embedded SoC Pico-ITX Board
For thermal dissipation, a heatspreader enables the PICO121's components to dissipate heat
efficiently. Images below illustrate how to install the heatspreader.
Installing Heatspreader
The PICO121 has four assembly holes for installing heatspreader plate. Align and firmly
secure heatspreader plate to PICO121. Be careful not to over-tighten the screws.
x4
x4
x4 (8mm)
