- Page 1 ENGLISH V I DEO DOOR PH ONE SY ST EM USER M AN UAL Manual covers IH-692 Master and IH-692 Slave Monitors...
- Page 3 PRECAUTIONS BEFORE INSTALLATION Connect this unit ONLY to other compatible units. Do not connect it to any other type of alarm or auxiliary device. Connecting anything else to this unit may damage it or prevent it from operating properly, and will invalidate the warranty. Do not place cables from the AC/DC adapters, camera or monitor where they can be damaged or stepped on.
-
Page 4: Table Of Contents
CONTENT 1. Parts and Functions ------------------------------1 2. Mounting and Installation------------------------1 3. Standard System Wiring-------------------------2 4. Connecting Multi Monitors/Audio phone----3 5. Connecting 2 Doorbell cameras----------------4 6. Operating Instructions----------------------------5 7. Precautions-----------------------------------------11 8. Specifications--------------------------------------11 The model you purchased may not have all the functions ... - Page 5 Touch Screen Operation All the operations and settings can be done by touching the LCD screen. Full Screen Digital Clock The date and time will displayed when touch anywhere of the screen, and it will closed automatically after 3 minutes. Press-To-Talk Function A special ‘listening’...
-
Page 6: Parts And Functions
1. Parts and Functions 2. Mounting and Installation Use the screws to fix the Mounting Bracket on the wall. Screws and brackets are included with the product for this purpose. -
Page 7: Standard System Wiring
3. Standard System Connection Terminals and descriptions • Power positive. +12V present when Outdoor Station calling or being monitored. • Power negative (GND) • Image signal (Video signal) • Talk and control signal (Audio signal) • POWER TERMINAL: Black wire DC negative (-) •... -
Page 8: Connecting Multi Monitors/Audio Phone
4. Connecting multiple Monitors and/or Audio Phones... -
Page 9: Connecting 2 Doorbell Cameras
5. Connecting 2 Doorbell cameras (CCTV camera) -
Page 10: Operating Instructions
6. Operating Instructions 6.1 Basic Functions When a visitor presses the Call button on the doorbell/camera unit, the monitor will ring and display the visitor’s image; also the IN-USE LED will turn red. ‘’ To answer the doorbell, press the TALK/MON button (or touch icon on the screen). - Page 11 will display the view from the doorbell (Outdoor Station). During monitoring ‘ ’ state, press TALK/MON button (or touch icon) to talk to someone outside. Press again to exit. The monitoring state is limited to 30 seconds and will shut off automatically. When you wish to open the door lock, press UNLOCK button (or touch ...
- Page 12 6.3 Intercom function (available when Multiple Monitors are installed) Intercom can be initiated by either Monitor. Press the INTERCOM button, the other Monitor will ring. Press TALK/MON button on the other Monitor to answer. To end the intercom conversation, press TALK/MON. If no one answers, it will exit automatically after 30 seconds.
-
Page 13: Basic Setup Instructions
selected in sequence: Normal, User, Soft and Bright. Whenever you modify Brightness or Colour, Scene item will be set to User mode automatically. Screen Ratio can be shifted from 16:9 to 4:3. The Brightness and Color item is for image quality setting. Adjust the value to get the best image. - Page 14 ‘Outdoor Tone’ and ‘Intercom Tone’ are for choosing the doorbell melody and the intercom melody. ‘Monitor Time’: To change the amount of time the monitor will remain active if no buttons are pressed, use the plus and minus buttons to set between 30 seconds and 10 minutes. ‘Advanced Set’: To access the Advanced Settings, a password will be required before entering.
- Page 15 ‘Other Device Set’ submenu: RLC and Remote settings. ‘Information’ submenu: shows the hardware/software version and voltage info. Press ‘Restore to Default’ if you wish to restore all the settings to factory defaults. 6.6 Image Recorder Operation (master only) Pictures can be recorded both manually and automatically.
-
Page 16: Precautions
7. Precautions All parts should be protected from violent vibration, forceful impacts and being dropped onto hard surfaces. Do NOT clean the Lens or Screen using your hands or a wet cloth. Do not use organic or chemical cleaners. Clean using a soft cotton cloth. If necessary, lightly dampen the cloth to remove stubborn dirt. - Page 17 WARRANTY CARD NB Please keep this document safe, as it is proof of your Warranty Your Video door system comes with a one year Manufacturers Warranty. When used normally, the following services are offered: 1. Replacement for malfunctioning parts in first three months 2.
- Page 20 T he design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
