Page 1: User Manual
Video Door Entry System user manual CALL UNLOCK TALK/MON IN-USE This manual covers IH692SD IH692 Monitor www.intelligenthomeonline.com... - Page 3 FFEATURES Touch Screen Operation UNLOCK INTERCOM MON/TALK IN-USE All the operations and settings can be done by touching the LCD screen. Full Screen Digital Clock The date and time will displayed when touch a n y w h e r e o f t h e s c r e e n , a n d i t w i l l c l o s e d automatically after 3 minutes.
- Page 4 PRECAUTIONS ● Read this manual through before using the product. ● Slots or openings in the back of the monitor, are provided for ventilation and to ensure reliable operation of the video monitor or equipment and to protect if from overheating. These openings must not be blocked or covered.
-
Page 5: Table Of Contents
CONTENT 1. Monitor Parts and Functions - - - - - - - - - - - - - - - - - - - - - - - -1 2. Monitor Mounting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1 3. -
Page 6: Monitor Parts And Functions
1. Monitor Parts and Functions LCD Touch Screen Microphone CALL CALL button UNLOCK UNLOCK button TALK/MON TALK/MON button IN-USE LED indicator Speaker Ventilation Vent connect slave monitor here Audio connect power here Slave Mon H-set connect audio phone here Power CAM 1 CAM 2 connect first... -
Page 7: System Connection
3. System Connection Terminals and descriptions: ● 1R Power positive. +12V present when Outdoor Station calling or being monitored. ● 2W Power negative (GND) ● 3Y Image signal (Video signal) ● 4B Talk and control signal (Audio signal) ● POWER TERMINAL: Black wire DC negative (-) ●... -
Page 8: Multi Monitors Connection
4. Multi Monitors Connection Audio Slave Mon H-set CN101 CAM 1 CAM 2 Audio Slave Mon H-set CN101 CAM 1 CAM 2 GX-3P Audio H-set Slave Mon Slave Mon Audio CN101 H-set CAM 1 CAM 2 CN101 CAM 1 CAM 2 - 3 -... -
Page 9: Multi Door Camera Connection
5. Multi Door Camera Connection Audio Slave Mon H-set CN101 CAM 1 CAM 2 Audio Slave Mon H-set CN101 CAM 1 CAM 2 Audio H-set Slave Mon CN101 CAM 1 CAM 2 - 4 -... -
Page 10: Talk/Unlock Operation
6. Talk/Unlock Operation When visitor presses the Call Button on the Outdoor Station, the monitor rings, at the same time, the screen displays the visitor image. CALL TALK UNLOCK EXIT TALK/MON UNLOCK IN-USE Talk icon Record icon. Exit icon Hide icon. Unlock icon Setting icon. -
Page 11: Ring Tone Setting
7. Ring Tone Setting 8. Monitor Time Setting 15 pieces ring tone can be selected. When Monitor Time is the maximum monitoring the Monitor is in standy, press anywhere time when the TALK/MON Button is pressed on the screen, a full screen calendar will be in standby, after which the screen will be showed. -
Page 12: Auto-Record
9. Auto-Record 10. Time Setting When the Auto-Record function is turned When the Monitor is in standby, press the on, a 10 seconds video will be recorded screen to open the time screen, press again automatically after the Call Button was to enter the main menu. -
Page 13: Restore To Default
11. Restore to Default 12. Screen Setting The restore to default function allows the When the Monitor is in monitoring or talking, user to recover the settings to factory setting. Press icon to open the screen setting Note that the restore to default operation will icons to increase or menu. -
Page 14: Built-In Memory And Sd Card
16. Built-in Memory and SD Card This Monitor has been equipped with a buit-in memory (about 118 MB, 50 ASF videos) together with a SD card reader. Maximum 2 GB SD card can be supported. When a new SD card was inserted to the Monitor, the SD card will be formated to FAT32 file system and 2 file folder(named DCIM and PHOTO) will be created. - Page 15 CALL UNLOCK play When the Monitor is in standby, press the screen TALK/MON monitor IN-USE to enter Main menu then enter PLAY menu. setup exit Press the icon to enter. Play back photo CALL UNLOCK Play back video TALK/MON IN-USE Copy videos from built-in memory to SD card (SD-->DCIM-->101MEDIA folder) Memory information...
-
Page 16: Camera Setting
14. 1/2 Camera Setting 15. Unlock Time Seeting When 2 Door Cameras are installed, the 1/2 The default unlock time is set to 1 second, Camera mode should be set to 2. Default is for a pulse activate lock. Unlock Time can be set to 1 for only one Camera. -
Page 17: Other Settings
16. Other Settings Press the screen to enter Advanced Set item. Then press enter Other Settings item. CALL 1/2 Camera -- 1 UNLOCK RLC Lock Set: for RLC lock control setting, when a Unlock Time -- 3 TALK/MON Date/Time Set... RLC is connected for lock contorl purpose, this item IN-USE Other Settings... -
Page 19: Warranty Card
WARRANTY CARD NB Please keep this document safe, as it is proof of your Warranty Your Video door system comes with a one year Manufacturers Warranty. When used normally, the following services are offered: 1. Replacement for malfunctioning parts in first three months 2. - Page 20 IH692-4wire-V2 2010-05-28 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved. www.intelligenthomeonline.com...
