- Page 1 Video Intercom System 692SD user manual CALL UNLOCK TALK/MON IN-USE ST-ENG-692SDTC7-V1 091S208...
- Page 2 PRECAUTIONS ● ● Read●this●manual●through●before●using●the●product. ● ● Slots●or●openings●in●the●back●of●the●monitor,●are●provided●for●ventilation● and●to●ensure●reliable●operation●of●the●video●monitor●or●equipment●and● to●protect●if●from●overheating.●These●openings●must●not●be●blocked●or● covered.●The●monitor●●should●never●be●placed●near●or●over●a●radiator●or● heat●register●and●should●not●be●placed●in●a●built-in●installation●such●as●a● bookcase●unless●proper●ventilation●is●provided. ● ● All●parts●should●be●protected●from●violence●vibration.●And●not●allow●be● impacting,●knocking●and●dropping. ● ● For●clean●the●LCD●screen,●using●hands●or●wet●cloth●is●forbidden. ● ● Please● do● the● cleanness● with● soft● cotton● cloth,● please● do● not● use● the● organic● or● chemical● clean● impregnate.● If● necessary,● please● use● pure● water●or●dilute●soap●water●to●clean●the●dust.
-
Page 3: Table Of Contents
CONTENT 1.●Parts●and●Functions ●- - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1 2.●Mounting●and● ●- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1 3.●System●Connection-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-2 4.●Multi●Monitors●Connection●- - - - - - - - - - - - - - - - - - - - - - - - - -3 5.●Multi●Door●Camera●Connection ●- - - - - - - - - - - - - - - - - - - - - -4... -
Page 4: Parts And Functions
1. Parts and Functions LCD Touch Screen Microphone CALL CALL button UNLOCK UNLOCK button TALK/MON TALK/MON button IN-USE LED indicator Speaker Ventilation Vent Power Input Slave Monitor Audio Handset CAM 1 CAM 2 Second Camera First Camera 2. Mounting and 1. Use the screws to fix the Mounting Bracket on the wall.(fitting accesories includes a Bracket (Two 4X25 screws are needed for fastening the Mounting Bracket), Special 4 core cables to connect with Monitor) -
Page 5: System●Connection-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-2
3. System Connection Terminals and descriptions: ● 1R Power positive. +12V present when Outdoor Station calling or being monitored. ● 2W Power negative (GND) ● 3Y Image signal (Video signal) ● 4B Talk and control signal (Audio signal) ● POWER TERMINAL: Black wire DC negative (-) ● POWER TERMINAL: White wire DC positive (+) It’s recommended you use shielded alarm cable 4x0.3mm2 for distances up to 30m. For distances over 30m, we suggest you add coaxial cable (RG-59) to connect the 3Y and 2W pin in addition to the alarm cable. -
Page 6: Multi Monitors Connection
4. Multi Monitors Connection Audio Slave Mon H-set CN101 CAM 1 CAM 2 GX-3P Audio Slave Mon H-set Slave Mon Audio H-set CN101 CAM 1 CAM 2 CN101 CAM 1 CAM 2 Audio H-set Slave Mon CN101 CAM 1 CAM 2 - 3 -... -
Page 7: Multi Door Camera Connection
5. Multi Door Camera Connection Audio Slave Mon H-set CN101 CAM 1 CAM 2 Audio Slave Mon H-set CN101 CAM 1 CAM 2 Audio H-set Slave Mon CN101 CAM 1 CAM 2 - 4 -... -
Page 8: Talk/Unlock Operation
6. Talk/Unlock Operation 1. When visitor presses the Call Button on the Outdoor Station, the monitor rings, at the same time, the screen displays the visitor image. CALL TALK UNLOCK EXIT TALK/MON UNLOCK IN-USE 1. Talk icon 4. Record icon. 2. Exit icon 5. Hide icon. 3. Unlock icon 6. Setting icon. 2. Press TALK/MON Button or icon, you can talk with the visitor for 90 seconds. During TALK talking state, press the TALK/MON Button again or press icon to end the conversation. EXIT If nobody answers the phone, the screen will be turned off automatically after 30 seconds. If the system connects two or more Monitors, when any Monitor starts to talk, the other Monitors will be automatically shut off. CALL TALK UNLOCK 3. During the conversation, press UNLOCK EXIT TALK/MON Button or... -
Page 9: Ring Tone Setting
7. Ring Tone Setting 8. Monitor Time Setting 15●pieces●ring●tone●can●be●selected.●When● Monitor● Time● is● the● maximum● monitoring● the● Monitor● is● in● standy,● press● anywhere● time●when●the●TALK/MON●Button●is●pressed● on●the●screen,●a●full●screen●calendar●will●be● in● standby,● after● which● the● screen● will● be● showed. closed●automatically. Presspress●anywhere●on●the●screen. CALL UNLOCK TALK/MON IN-USE CALL UNLOCK TALK/MON IN-USE... -
Page 10: Auto-Record
9. Auto-Record 10. Time Setting When● the●Auto-Record● function● is● turned● When● the● Monitor● is● in● standby,● press● the● on,● a● 10● seconds● video● will● be● recorded● screen●to●open●the●time●screen,●press●again● automatically● after● the● Call● Button● was● to● enter● the● main● menu.● select● ● to● setup pressed●... -
Page 11: Restore To Default
11. Restore to Default 12. Screen Setting The● restore● to● default● function● allows● the● When●the●Monitor●is●in●monitoring●or●talking,● user●to●recover●the●settings●to●factory●setting.● Press● ● icon● to● open● the● screen● setting● Note●that●the●restore●to●default●operation●will● — / icons to increase or menu.● Press not●change●the●time●setting●and●the●files●on● decrease current value; touch the icon to the●buit-in●momery●or●SD●card. switch to next setting, press ●icon●to●exit. When● the● Monitor● is● in● standby,● press● the● screen●to●open●the●time●screen,●press●again●... -
Page 12: Built-In Memory And Sd Card
13. Built-in Memory and SD Card This●Monitor●has●been●equipped●with●a●buit-in●memory●(about●118●MB,●50●ASF●videos)●together●with● a●CD●card●reader.●Maximum●2●GB●SD●card●can●be●supported.●When●a●new●SD●card●was●inserted● to●the●Monitor,●the●SD●card●will●be●formated●to●FAT32●file●system●and●2●file●folder(named●DCMI●and● PHOTO)●will●be●created. CALL UNLOCK TALK/MON IN-USE SD card ● ● This● Monitor● can● play● back● JPEG● photos● and●ASF● videos.●The● recorded● videos● will● be● saved●in●the●SD-->●DCIM-->100MEDIA●file●folder. ● ● Photo●frame●function,●each●photo●playing●will●last●5●seconds,●it●will●be●stopped●in●one●hour. More●pictures●in●the●SD●card,●longer●time●for●triggering●the●fuction,●less●than●1000pcs●is● recommend.●Note●that●the●Monitor●can●only●play●back●the●photos●in●the●SD-->PHOTO●file● folder. ● ● Only●the●JPEG●photos●took●by●a●digital●camera●can●be●played●back●in●this●monitor,●JPEG● picture●processed●by●other●software●might●not●be●supported. - Page 13 CALL UNLOCK play When●the●Monitor●is●in●standby,●press●the●screen● TALK/MON monitor IN-USE to●enter●Main●menu●then●enter●PLAY menu. setup exit Press●the●icon●to●enter. 1. Play back photo CALL UNLOCK 2. Play back video TALK/MON IN-USE 3. Copy videos from built-in memory to SD card (SD-->DCIM-->101MEDIA folder) 4. Memory information 5. Exit Press● the● icon● to● play● the● video/photo.● When● playing●videos,●there●is●no●sound●at●first,●press●the●...
-
Page 14: 1/2●Camera●Setting
14. 1/2 Camera Setting 15. Unlock Time Seeting When●2●Door●Cameras●are●installed,●the●1/2 The●default●unlock●time●is●set● to●1●second,● Camera●mode●should●be●set●to●2.●Default●is● for●a●pulse●activate●lock.●Unlock●Time●can●be● set●to●1●for●only●one●Camera. set●when●needed.● When● the● Monitor● is● in● standby,● press● the● When● the● Monitor● is● in● standby,● press● the● screen●to●open●the●time●screen,●press●again● screen●to●open●the●time●screen,●press●again● to●enter●the●main●menu.●●then●press● ● to●enter●the●main●menu.●●then●press● ● setup setup to●enter●Setup●menu. to●enter●Setup●menu. -
Page 15: Other Settings
16. Other Settings Press●the●screen●to●enter●Advanced Set●item.●Then● press●enter●Other Settings●item. CALL 1/2 Camera -- 1 UNLOCK RLC Lock Set:●for●RLC●lock●control●setting,●when●a● Unlock Time -- 3 TALK/MON Date/Time Set... RLC●is●connected●for●lock●contorl●purpose,●this●item● IN-USE Other Settings... Information... must●be●turned●on●to●enable●the●lock●control●function. Exit RLC Lamp Set:●when●using●a●RLC●unit●to●control●a● additional●lock,●this●time●must●be●turned●on●to●enable● the●function. RLC Lamp Call Control:● If● set● to● on(always),● the● lamp●... - Page 16 The●design●and●specifications●can●be●changed●without●notice●to●the●user.● Right●to●interpret●and●copyright●of●this●manual●are●preserved. ST-ENG-692SDTC7-V1 091S208...
