Summary of Contents for Ness D-8
Page 1
To the best of our knowledge, the information in this manual is correct at the time of going to print. Ness Security Products reserve the right to make changes to the features and specifications at any time and without notice in the course of product development.
D - 8 CONTROL PA N E L I N S TA L L AT I O N M A N U A L NESS SECURITY PRODUCTS A$15.00...
Page 3
P A G E I N D E X I N T R O D U C T I O N Features Package Contents Installation Procedures I N S TA L L AT I O N Inputs Outputs Wiring Diagrams Sample Movement Detector Sample Reed Detector Sample Warning Detector...
Page 4
P A G E I N D E X Selecting Zones to Auxiliary 1 Output (P58E) Selecting Zones to Auxiliary 2 Output (P59E) Miscellaneous Options Entry warning Beeps (P60E 1E) Keyswitch Operation (P60E 2E 3E) Siren Tamper Lockout (P60E 4E) Duress Alarm to activate “Reset”...
The NESS D-8 is Australian Designed and Manufactured product by Ness Security Products Pty Ltd, Australia’s largest m a n u f a c t u rer of quality Electronic Security Products. Ness Security Products Pty Ltd is a Quality Accredited Company to ISO 9001.
I N S T A L L AT I O N U N PA C K I N G The D-8 package contains the following; C o n t e n t s Q u a n t i t y...
Page 7
AC Input Terminals: These terminals are for the connection of the Ness plug- The Ness D-8 has 9 separate monitored inputs. pack. The Ness D-8 requires an AC transformer rating of • 8 x Fully programmable Zone inputs 1.4 Amps @ 17 Vac minimum. (Ness Part No. Pow 215) •...
Page 8
A maximum of 3 x 12 Volt Piezo Sirens (Ness Part No. NOI 2: Battery Operation. 240, NOI 230) or 2 X Ness Piezo Sirens (Part No 100-172) A properly charged battery MUST be installed to ensure can be connected to this output.
Page 9
I N S T A L L AT I O N W I R I N G D I A G R A M Main Control Panel: TAMP +12V DIALLER SOCKET • • • RECEIVER • • AUX 1 • AUX 2 •...
Page 10
W I R I N G D I A G R A M Sample Wiring of Reed Detectors: Sample Wiring of Reed Switch and Nessensor Wiring to Ness Control Panel Other Two Wires are Looped and are for NC Tamper E.O.L.
Page 11
I N S T A L L AT I O N W I R I N G D I A G R A M Sample Wiring of Warning Detectors: W I R I N G D I A G R A M Wiring of D-8 Keypads:...
Page 12
Every time a button is pressed the panel responds with a Keypad Wiring very brief beep in acknowledgment. The D-8 Keypad connects to the D-8 Control Panel via a 4 wire connection. A Maximum of 3 keypads can be con- nected, each wired in parallel.
Page 13
I N S TA L L A T I O N V I S U A L I N D I C AT I O N S LIGHT FLASH ZONEs 1 - 8 Zone Alarm Zone Sealed Zone Unsealed ARMED Day / Disarm Monitor Mode Panel is Armed...
Page 14
Note : Replace the Link once the Ness D 8 is in Install Program mode otherwise an internal tamper alarm will occur when leaving program mode.
Page 15
P R O G R A M M I N G H O W T O P R O G R A M Programming the NESS D-8 Control Panel is done via the remote keypad. The PROGRAM, or P button, is used to begin any The ENTER, or E button, is used to signal the end of the programming sequence.
Page 16
U S E R C O D E S ( A C C E S S C O D E S ) A user code is a code the client uses to operate the panel. The Ness -D-8 has a total of 15 user / access codes, plus Example: To program a Master Code Pre s s ;...
Page 17
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P R O G R A M M I N G R A D I O K E Y C O D E S R A D I O K E Y A C C E S S C O D E p ro g r a m m i n g : First select the code numbers to have RADIO KEY...
P R O G R A M M I N G R A D I O D E V I C E C O D E S Program or Clear Zone Radio Device Code P01E-P08E NOTES: The D-8 can operate with Radio devices such as the A RADIO DEVICE operates in parallel with the Ness Radio PIR and both Radio Reed switch versions.
Page 19
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 2 6 E S E T T I N G E N T R Y T I M E 1 The 'Entry Delay Time 1' is the time the Control Panel To view the current Entry Time 1 enter : P 26 E gives you to disarm the Panel after an 'Entry 1 Delay...
Value displayed back P R O G R A M M O D E S The Ness D-8 Control Panel has 3 modes. 1) 'Installation' Program Mode 2) 'Client' Program Mode 3) 'Remote Programming via Remote Up and Down Loading or Direct Connect.
Page 21
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 3 0 E - P 3 8 E V I B R AT I O N S E N S I T I V I T Y Z O N E S When using vibration sensors, such as the Nessensor P 30 E is for n o rmal zones that do not use vibration sensors.
Page 22
Z O N E A S S I G N M E N T 24 Hour Zones work independently of Arm, Monitor, The Ness D-8 can operate in 3 different modes. Arm Mode (when the Panel is Armed), Monitor Mode, or Disarm mode and Disarm.
Page 23
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 4 1 E E N T R Y D E L AY 1 Z O N E S Example: To set , say, Zone 4 and Zone 7 to be Delay, After expiry of the Exit Time (as set by P 28 E) a 'Delay 1' Enter ;...
Page 24
A R E A O P E R AT I O N Area” Zones. If Zones are allocated to both Areas, then The NESS D-8 Control Panel allows the 8 Zones to be split both Areas must be Armed before those Zones are into two groups, known as Area 1 and Area 2.
Page 25
A S S I G N U S E R C O D E S T O A R E A 1 The Ness D-8 has 15 User codes, which can be selected to operate either or both of the 2 Areas.
Page 26
A S S I G N U S E R C O D E S T O A R E A 2 can Arm and Disarm Area 2. The Ness D-8 has 15 User codes of which any can be selected to operate either of the 2 Areas or both if Example : To set , say Users 1 , 3 , 10 ,12 to operate Area 2 enter ;...
Page 27
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 5 1 E S E L E C T I N G M O N I T O R Z O N E S Zones will turn on the outputs assigned to the zones as set Monitor Zones allow you to ARM selected zones while oth- ers are ignored.
Page 28
Outputs as well using Option P 63 E. Note: these are only active when programmed with Programming option P64 E (refer below). The NESS D-8 allows for each zone input to be selected as to what outputs they will activate. Tamper and Monitor outputs are displayed on Zones 1-4, while Panic and Day outputs are displayed on Zone LEDs 5-8.
Page 29
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 5 4 E S E L E C T I N G R E S E T O U T P U T Z O N E S Zones set to activate the Reset Output will be lit.
Page 30
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 5 7 E S E L E C T I N G S I R E N O U T P U T Z O N E S This option selects which Zones will activate the Zones set to activate the Siren Output will be lit.
Page 31
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S M I S C E L L A N E O U S O P T I O N S P 6 0 E 1 E E N T R Y W A R N I N G B E E P S With Zone 1 LED On , Entry Warning Beeps will be...
Page 32
If a Zone is unsealed at the end of Exit Time (as set by P 28 The Zone 6 LED will indicate if the option is selected. E) the Ness D-8 will provide a 2 Second Siren Burst and the Zone unsealed will be automatically excluded (not cause...
Page 33
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 6 1 E 1 E - 4 E S E L E C T I N G TA M P E R A L A R M S T O A C T I V AT E O U T P U T S The Zone 1-4 LED's will light to indicate which of the 4 This option selects which Outputs will be activated if a Tamper Alarm occurs.
Page 34
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 6 2 E S Y S T E M O P E R AT I N G S H O R T C U T S With the option selected (ie.
Page 35
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 6 2 E 8 E E X I T T I M E X 1 0 To View if the this option is selected Enter P 62 E 8 E If you require a longer than normal exit time you can select this option, which will multiply your Exit Time...
Page 36
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 6 3 E 5 - 8 E D AY M O D E O U T P U T S To View what Outputs will activate when in Monitor Mode This option selects which Outputs will be activated when the Panel is in Day Mode (ie Disarmed) and an Alarm...
Page 37
The Panel will provide 1 Chirp for Arming and 3 Chirps on Disarming. Disarm the Ness D-8 panel. The Factory Pre-Set = Off. ( Zone 4 LED Off) If this option is selected the Siren Output will “Chirp” when...
Page 38
D I A L L E R O P T I O N S The D-8 dialler uses standard Contact ID format and a The Ness D-8 has an onboard dialler which reports to the central station using Ademco Contact ID format and is also detailed breakup of these reports are listed below.
Page 39
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S REPORT NAME Account Number SUFFIX Zone 1 Manual Exclude AAAA Zone 2 Manual Exclude AAAA Zone 3 Manual Exclude AAAA...
Page 40
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 7 2 E - P 7 3 E C L I E N T A C C O U N T N U M B E R S To program Client Account Number 1, Press P72E (client Client Account Numbers are used by the Central Station to identify the location of the alarm premises.
Page 41
Client Account number 2. This function may be necessary if two premises are shar- ing a common D-8 system. eg. Two shops which are side by Factory Pre-set: No Zones set to report. (All zone lights off)
Page 42
T I M E B E T W E E N T E S T C A L L S Test calls from the D-8 are an important way in which the eg. If you required the D-8 to send a test call every 24 central station can determine if the dialler is operating.
Page 43
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 8 4 E T I M E B E F O R E N E X T T E S T C A L L The time before test call interval can be between 2 hours This option determines the time in hours before the next test call message is sent to the central station.
Page 44
Option 6: Contact ID + Pulse Audible. This option will send a Contact ID message to the central station then send the If Audible Dial Format is selected the D-8 will not send: Pulse Audible format to the “Follow Me” number.
Page 45
Telephone No.2 for the last half of the call attempts. the first attempt. If no responce, dial Telephone No. 2. If no The D-8 will also call telephone No 2 if Telephone No 1 was responce, dial Telephone number 1 etc. etc.
Page 46
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 8 8 E 1 E S E N D A R E A 1 O P E N / C L O S E R E P O R T S Zone LED 1 ON allows Area 1 Open/Close reports Factory Pre-set: Off (No Area 1 open/close)
Page 47
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 8 9 E 1 E E N A B L E T E S T C A L L S Zone LED 1 ON selects Automatic Test Calls Factory Pre-set: Off (No Test Calls)
Page 48
P R O G R A M M I N G O P T I O N D E S C R I P T I O N S P 9 6 E C L E A R I N G A L A R M M E M O R Y This Option will clear all events from memory To clear the event memory simply Press...
To ensure reliable operation of any system, correct testing procedures should be carried out prior to handing the completed installation over to the customer. Using a digital multimeter, the following procedures are recommended for testing a Ness L-8 control system. V O LTA G E S All zone inputs, and the tamper input should be terminated with a 2K2 ohm end of line resistor (supplied with the Panel).
S P E C I F I C AT I O N S M E C H A N I C A L . Construction 3 mm Polycarbonate (equivalent to 1.2 mm mild steel) Dimensions 233 wide x 300 high x 85 deep Weight 5 kg (inc battery) P O W E R .
G E T T I N G S TA R T E D W I T H A B A S I C P R O G R A M Option Factory Pre-Set Value Zone 1 Delayed Zone 2 Handover Zones 3-8 Instant Exit Delay...
Page 52
N E S S - D - 8 : P R O G R A M M I N G S U M M A R Y This summary is an outline of all options available in installation program mode. The Enter key is required to display the values in each option.
