Ness D8x / D16x AlARm CoNtRol pANel
InstallatIon & programmIng manUal
5.5
Revision
A$15.00
Covering D8x/D16x
firmware versions up to v5.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D8x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ness D8x

Summary of Contents for Ness D8x

  • Page 1 Ness D8x / D16x AlARm CoNtRol pANel InstallatIon & programmIng manUal Revision A$15.00 Covering D8x/D16x firmware versions up to v5.5...
  • Page 2 Ness. Ness reserves the right to make changes to features and specifications at any time without prior notification in the interest of ongoing product development and improvement.

  • Page 3: Table Of Contents

    Zone supervision options ........31–33 Zone split (D16 only) ..........34 RADIo optIoNs misc. options ............35–37 signal strength test ............. 60 Ness Radio Interface ........... 61 DIAlleR optIoNs Radio Devices, described ........... 61 telephoNe NumBeRs ........38–39 RADIo DeVICe pRogRAmmINg ......62 Account Numbers ............

  • Page 4: Product Features

    • New "enable hardwire Zones" option allows zone inputs to be disabled if unused. • Automatic reset fuses. • the Ness output expander is now also an option for the D8 control panel. (previously D16 only). • programmable siren/reset lockout.

  • Page 5: Specifications And Approvals

    RADIo header ....... multi-pin connector for the Ness Radio Interface (100-200). seRIAl header ...... serial data port for direct connect programming using NessComms™ software. ReADeR header ....multi-pin port for connecting up to 3 Ness proximity access card readers. outputs siren ........

  • Page 6: Installation

    3. securely mount the rear panel housing to a secure location. 4. Run all cabling needed for the installation. (electrostatic Discharge). once properly installed, Ness control panels are 5. Before removing the circuit board from its protective wrapping. well protected from esD. however, take note of 6.

  • Page 7: Inputs And Outputs

    2K2 end of line strobe operation, until the panel is reset). resistor. this input is always a 24hr input. A maximum of 2 x 1 watt strobes (Ness part No. NoI300) can be connected to this output. AC input terMinAls these terminals are for the connection of the Ness plugpack.

  • Page 8: Connection Diagram

    12V DC Power for detectors, etc +12V D8 MAIN BOARD Zone 8 END OF LINE RESISTORS Ness control panels are supplied with 2200 Ohm 1% tolerance Metal Zone 7 Film end of line resistors. Colour code: Red, Red, Black, Brown, Brown LISTEN PINS Zone 6 Diagnostics.

  • Page 9: Connection Diagram

    N.C. Contacts 3 keypads +12V +12V (WHITE) READER Connection for Up to 2 x Ness 12V Siren (100-172) RESET up to 3 Ness OR 3 x 12V Screamer (100-238, 100-004) Weigand readers Up to 2 x Strobe Light (NOI-300) “HEARTBEAT” LED...

  • Page 10: Keypad

    KEypaD NeSS LeD KeyPaD (100-192) NeSS D816 LCD KeyPaD (100-667) D8 PaNeL oNLy D8 or D16 PaNeL D8 & D16 KeypADs the Ness leD or lCD keypad provides 105mm 90mm important visual and audible indication LED KEYPAD LCD KEYPAD of the system status and is the main...

  • Page 11: Operation Summary

    opEratIon sUmmary opeRAtIoN by KEYPAD by RADIO KEY by ACCESS CARD or FOB to ARM present a Card or Fob press twice. (if p301e 2e is the panel must initially be (If the a is enabled, p62e 5e) rMINg hortCut on).

  • Page 12: Quick Start Programming

    I n g QUICK start programmIng use one of these programming summaries for fast setup of your Ness D8 or D16 control panel as a local, Audible monitored or Central station monitored system.

  • Page 13: How To Enter Program Mode

    p r o g r a m m I n g Power up with Program Link OFF FACTORY DEFAULTS (Usually on first time installation) master Code: 123 Installer Code: 000000 light PROGRAM INSTALLER PROGRAM Mode is FLASHING PROGRAM LIGHT IS FLASHING PROGRAM INSTALLER PROgRAM MODE Installer program mode allows...

  • Page 14: User Codes

    P101E – P116E UsEr CoDEs P201E – P256E D8x and D16x version 5 and later have 56 user Codes which are used to operate the panel by a variety of methods. PROGRAM MODE LEVEL user, Installer, Remote by pC (except each user Code can be assigned to either a KeypAD CoDe or a RADIo Key or an radio keys and access cards).

  • Page 15: User Codes

    Rex codes. see page 69. p239e 5E RADIo CoDe. enables selected user codes as Radio Codes p240e for operation by Ness Radio Key or Radio Keypad. (page 63 p241e - how to program Radio Codes). p242e 6E ReADeR CoDe 1.

  • Page 16: Timers

    p r o g r a m m I n g option No. Description Default Note p26e eNtRy DelAy tIme 1 seconds p27e eNtRy DelAy tIme 2 x10 = 60seconds p28e exIt DelAy tIme seconds p29e sIReN Reset tIme minutes Entry DElay tImE1 P26E the entry Delay time 1 is the time given to Disarm the panel after a entry Delay 1 zone...

  • Page 17: Vibration Sensitivity

    1 second ZoNes previous versions of D8/D16. p38e 3 second ZoNes * extreme sensitivity (p31e) should not be used. It is provided as a guide only Ness NesseNsoR Vibration sensor ™ part No. VIB100 ADJustINg NesseNsoRs In addition to zone sensitivity adjustment, the overall sensitivity of the Nesssensor can be Nessensors are sensitive to high adjusted by rotating the body of the Nesssensor within its bracket.

  • Page 18: Zone Assignment

    p r o g r a m m I n g ZoNes 1–8 (D8 & D16) ZoNes 9–16 (D16) option No. Description 9 10 11 12 13 14 15 16 p39e DouBle tRIggeR zones p40e INstANt zones oN oN oN oN oN oN oN oN oN oN oN oN oN oN ZoNe DelAy types p41e eNtRy DelAy 1 zones...

  • Page 19: Area Partitioning

    p r o g r a m m I n g HanDovEr ZonEs P42E handover zones are delayed only if entry is made through an entry Delay zone first. PROGRAM MODE LEVEL If a handover zone is triggered first, the zone behaves as an instant zone. Normally, Installer, Remote by pC.

  • Page 20: Definitions. Day Zones, Temp Day Zones, Monitor

    p r o g r a m m I n g arEa partItIonIng arEa partItIonIng monItor moDE & monItor moDE monitor mode, (or home mode), allows DEFINITION selected zones to be armed whilst the system the panel can be armed in moNItoR Area partitioning allows the control panel is disarmed.
  • Page 21 p r o g r a m m I n g assIgnIng UsEr CoDEs to arEas P47E, P48E, P49E, P50E options p201e–p256e are now used for assigning user codes to areas. see page 14, 15 programming user (experienced users can still use options p47e–p50e for this function, but only up to Codes.

  • Page 22: Zone To Output Mapping

    p r o g r a m m I n g ZonE to oUtpUt mappIng When a zone alarms, it can turn on any or all of the following 6 outputs: Sonalert, Strobe, Siren, Reset, AUx1, AUx2. The programming is selected with options P54E – P59E. Simply set the zone number to the output to select it.
  • Page 23 p r o g r a m m I n g sIrEn oUtpUt ZonEs P57E selects the zones to trigger the siren output. PROGRAM MODE LEVEL Installer, Remote by pC. PROgRAMMINg SEQUENCE: p57e [Zone no]e toggles the options ON and OFF FACTORY DEFAULT All oN: All zones trigger siren output.

  • Page 24: Various Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p60e VARIous optIoNs P60E 1E Entry bEEps the sonalert will beep during entry Delay. PROGRAM MODE LEVEL Installer, Remote by pC. PROgRAMMINg SEQUENCE: FACTORY DEFAULT p60e 1e toggles the option ON and OFF...
  • Page 25 p r o g r a m m I n g tampEr sIrEn loCKoUt P60E 4E this option programs the tamper input to lockout, i.e. cause the siren & Reset outputs PROGRAM MODE LEVEL to sound only once whilst the panel is armed. Installer, Remote by pC.

  • Page 26: Tamper/Keypad Panic Output Mapping

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p61e oN oN oN oN oN oN oN oN tAmpeR & pANIC AlARm mAppINg tampEr alarm / oUtpUt mappIng P61E 1E–4E this option selects which outputs will trigger when a tamper Alarm occurs.

  • Page 27: System Operation Shortcuts

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p62e oN oN oN opeRAtIoN shoRtCuts etC P62E 1E–6E systEm opEratIon sHortCUts some keypad operations can be programmed to operate with or without a user Code. PROGRAM MODE LEVEL Installer, Remote by pC.

  • Page 28: Monitor Mode Output Mapping

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p63e oN oN oN oN moNItoR & DAy moDe mAppINg monItor moDE oUtpUt mappIng P63E 1E–4E this option selects which outputs are triggered by alarms in monitor mode. PROGRAM MODE LEVEL Installer, Remote by pC.

  • Page 29: Miscellaneous Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p64e oN oN mIsC. optIoNs P64E 1E brIEF monItor moDE alarm Alarms in monitor mode can either activate the programmed outputs for siren time PROGRAM MODE LEVEL duration (p29e) or they can activate the outputs for 2 seconds only.

  • Page 30: Keypad Fire Alarm

    FACTORY DEFAULT oN: Double key Keypad panic enabled. PROgRAMMINg SEQUENCE: NOTES p64e 6e toggles the option ON and OFF the Ness lCD keypad has two buttons oFF: No double key Keypad Panic labelled oN: Double key Keypad Panic enabled RELATED OPTIONS...

  • Page 31: Zone Supervision Options

    Radio supervision is to verify the correct operation of Ness Radio pIRs. the supervision signal from the Radio pIR tells the panel that the device has not been removed from radio range and is in working order.
  • Page 32 p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p66e ZoNe supeRVIsIoN AleRts ZonE sUpErvIsIon alErts – rEsEt oUtpUt P66E 1E setting this option turns the Reset output oN when a supeRVIseD ZoNe alert occurs. PROGRAM MODE LEVEL the Reset output will remain oN for the duration of the AlARm tIme (set by option Installer, Remote by pC.
  • Page 33 5e wired Zone supervision. p67e Zone supervision time. p92e 4e (D8) Report supervision. p75e 12e (D16) Report supervision. THIS OPTION IS AVAILABLE IN D8x/D16x V5.2 AND LATER P66E 7E sUpErvIsIon tImE spEEDUp X6 setting this option speeds up the supervision time by 6. For instance if p67e is set to PROGRAM MODE LEVEL 1 hour (60 minutes), then this option will reduce it to 10 minutes.

  • Page 34: Zone Split (D16 Only)

    1e toggles the option ON and OFF END OF LINE RESISTOR NOTES: oFF: No Zone Split • Ness supplies 1% tolerance metal film oN: Zone split enabled resistors for the end of line termination. these are accurate value resistors and they stay accurate long term.

  • Page 35: Misc. Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p68e mIsC. optIoNs 3K3 ZonE rEsIstors P68E 2E setting this option oN changes the Zones 1 – 8 monitoring resistor from 2K2 to 3K3. PROGRAM MODE LEVEL (external tamper input always uses a 2K2 resistor).

  • Page 36: Misc. Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p69e mIsC. optIoNs 2 P69E 1E aUX3 (arm1) pUlsE oUtpUt this option selects the Aux3 output to pulse on for 2 seconds whenever arming or PROGRAM MODE LEVEL disarming of Area1.
  • Page 37 p r o g r a m m I n g 6 bEEps on armIng P69E 4E Normally the keypad/s onboard soNAleRt gives 3 beeps when the panel is armed. PROGRAM MODE LEVEL turning this option oN will give 6 keypad beeps when Arming. Installer, Remote by pC.

  • Page 38: Telephone Numbers

    p r o g r a m m I n g option No. Description Default p70e telephoNe NumBeR 1 - pRImARy p71e telephoNe NumBeR 2 - seCoNDARy p80e telephoNe NumBeR 3 - test CAlls p81e telephoNe NumBeR 4 - CAllBACK FoR uploAD p00e Follow-me telephoNe NumBeR - For audible dialling p72e...
  • Page 39 HEx CLIENT CODE NOTES Dialler client codes can now be entered in hexadecimal. use the following keys Note 1: If using the Ness leD keypad to enter the hex digits B, C, D, e or F. for programming, the hex digits will not be displayed but are still programmed.

  • Page 40: Report Zone Alarms

    p r o g r a m m I n g ZoNes 1–8 (D8 & D16) ZoNes 9–16 (D16) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 option No. Description p74e RepoRt ZoNe AlARms oN oN oN oN oN oN oN oN oN oN oN oN oN oN oN oN p76e RepoRt ZoNe RestoRAls...

  • Page 41: Report Miscellaneous Alarms

    p r o g r a m m I n g ALARM RESTORAL DEFAULT DEFAULT AlARm RestoRAl AlARm RestoRAl P75E, P92E Duress p75e 1e p77e 1e p75e 1e p77e 1e medical p75e 2e p77e 2e p75e 2e p77e 2e REPORT MISCELLANEOUS ALARMS Kp panic &...

  • Page 42: Test Call Options

    p r o g r a m m I n g option No. Description Default Note p83e test CAll INteRVAl x2 = 168hrs p84e tIme BeFoRe FIRst test CAll x2 = 12hrs P83E tEst Call IntErval test calls to the Central station can be sent at intervals between 2 and 198 hours in 2 PROGRAM MODE LEVEL hour increments.

  • Page 43: Dialler Format Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p86e RepoRtINg FoRmAts P86E 1E DIsablE DIallEr this option disables the dialler even if telephone numbers and other dialler options are PROGRAM MODE LEVEL programmed.

  • Page 44: Contact Id Reporting Codes

    p r o g r a m m I n g ContaCt ID + aUDIblE DtmF Format P86E 5E For simultaneous Central station and Audible monitoring. PROGRAM MODE LEVEL the alarm message will be sent to the Central station on the primary telephone Installer, Remote by pC.

  • Page 45: Dialling Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p87e mIsC. DIAllINg optIoNs P87E 1E splIt DIal prImary/sEConDary pHonE nUmbErs this option selects the order in which telephone numbers 1 & 2 are dialled. PROGRAM MODE LEVEL Installer, Remote by pC.

  • Page 46: Area1, Area2 Open/Close Reports

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p88e oN oN opeN/Close RepoRtINg optIoNs arEa1 opEn/ClosE rEports P88E 1E enables or disables sending of AReA1 open/Close reports. PROGRAM MODE LEVEL the user ID of the code used is included in the report.

  • Page 47: Other Reports

    p r o g r a m m I n g ForCED opEnIng rEport P88E 5E If Forced opening Report is selected oN – when an alarm has been reset by a valid PROGRAM MODE LEVEL user Code (or Radio Key), the dialler will send an opening report along with a restoral Installer, Remote by pC.

  • Page 48: Enable Test Calls

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p89e oN oN mIsC. RepoRtINg optIoNs EnablE tEst Calls P89E 1E this option enables the reporting of dialler test calls to the Central station. PROGRAM MODE LEVEL Installer, Remote by pC.

  • Page 49: Swinger Shutdown

    p r o g r a m m I n g swIngEr sHUtDown P89E 4E limits the number of calls made by a zone alarm when multiple Zone Alarms are PROGRAM MODE LEVEL enabled for that zone. Installer, Remote by pC. If enabled, multiple reports are limited to three per zone.

  • Page 50: Remote Access Options

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p90e uploAD/DowNloAD optIoNs rEmotE aCCEss P90E 1E when selected on, this option allows the panel to be remotely upload/downloaded by PROGRAM MODE LEVEL a remote computer or controlled by a remote telephone.

  • Page 51: Remote Disarming

    p r o g r a m m I n g P90E 4E rEmotE DIsarmIng Allows the remote Disarming of the control panel using a standard DtmF telephone (or PROGRAM MODE LEVEL mobile phone) from anywhere in the world. Installer, Remote by pC. FACTORY DEFAULT PROgRAMMINg SEQUENCE: oFF: No Remote Disarming.

  • Page 52: Required Rings

    p r o g r a m m I n g option No. Description Default Note p91e ReQuIReD RINgs to ANsweR 1 to 24 rings P91E rEQUIrED rIngs sets the number of rings before an incoming call is answered. this is used for remote PROGRAM MODE LEVEL access of the panel either by NessComms software or user operation by telephone.

  • Page 53: Clear Radio Devices

    p r o g r a m m I n g option No. Description these options allow selective restoring p95e CleAR RADIo DeVICes of various factory defaults. For example, you can default (clear) all the user p96e CleAR memoRy Codes, without affecting any other p97e CleAR pANel optIoNs (RestoRe FACtoRy DeFAults) programmed options.

  • Page 54: Output Expander

    p r o g r a m m I n g 1E 2E 3E 4E 5E 6E 7E 8E option No. Description p117e output expANDeR optIoNs P117E 1E EnablE oUtpUt EXpanDEr selecting this option enables the optional 106-011 output expander. PROGRAM MODE LEVEL Installer, Remote by pC.
  • Page 55 p r o g r a m m I n g Day ZonE FollowEr P117E 3E this option allows Day zones to appear on the Zone outputs. PROGRAM MODE LEVEL In Day mode the Zone output will follow the state of any active Day zone. this Installer, Remote by pC.
  • Page 56 P120E 3E RADIO AUx BUTTON ARMS MONITOR MODE this option enables the Aux button on a Ness RK4 Radio Key to arm monitor mode. NOTE when this option is enabled, options p122e 3e & 4e will be disabled, (Aux button to this option enables Radio Key monitor Aux2 options.

  • Page 57: Aux1 Output Options

    p r o g r a m m I n g Connects to AUx1 output optIoNs AUX header sets the behaviour of the Aux1 output. only one option can be selected. Separate Power Supply * Diode is required to prevent spikes. (not supplied) option No.

  • Page 58: Aux2 Output Options

    p r o g r a m m I n g AUx2 output optIoNs Connects to sets the behaviour of the Aux2 output. AUX header only one option can be selected. Separate Power Supply * Diode is required to prevent spikes. (not supplied) option No.

  • Page 59: Aux3 Output Options

    (Adding an additional keypad would the extension beeper can either be a standard 12V sonalert or wire directly to the Ness achieve the same effect). Quantum sonic as shown. Keypad beeps will 2e oFF: extension sonalert disabled.

  • Page 60: Enable/Disable Hardwire Zones

    NOTES • signal strength of Radio Keys can the signal strength test can be used to test the radio signal from any Ness radio be tested in useR pRogRAm mode or device. the strength of the radio signal received is displayed on the zone lights 1~8 INstAlleR pRogRAm mode.

  • Page 61: Ness Radio Interface

    Armed state of the control panel. If the Ness Radio Interface is correctly installed, the keypad will flash the RADIo light oN when any radio signal is detected (from both programmed and non-programmed RADIO TAMPER: causes the keypad to con- radio devices).

  • Page 62: Radio Device Programming

    (Remove the battery or open the RADIo link). the Ness R12 and R15 Radio pIRs have a test link which disables the re-transmit Remember to enable all the timer, allowing the detector to be walk tested without waiting for the 4 minute re- transmit timer to expire.

  • Page 63: Radio Key Programming

    56 user Codes, except for the master Code, can be programmed to p203e be Radio Codes. this allows up to 55 Ness Radio Keys to be used for Arming and p204e Disarming of the panel. the Ness RKp Radio Keypad can also be used with the p205e D8/D16, (see the RKp installer manual).

  • Page 64: Real Time Clock Options

    p r o g r a m m I n g option No. Description Default Note p130e ReAl tIme CloCK set MINUTES 00–59 minutes p131e 00–23 hours ReAl tIme CloCK set HOURS (00=midnight) p132e ReAl tIme CloCK set DAY 01–31 days p133e ReAl tIme CloCK set MONTH 01–12 months...

  • Page 65: Access Control Options

    aCCEss Control option No. Description P300E p300e DeFAult All ACCess CoNtRol optIoNs PROGRAM MODE LEVEL DEFaUlt all aCCEss Control optIons Installer. enter p300e in Installer program mode to return all access control programs to factory default values. PROgRAMMINg ACCESS CARDS If the panel has 1, 2 or 3 weigand proximity readers connected up to 55 of the panel's user codes can be programmed as Reader Codes.
  • Page 66 P301E 1E UsE rEaDEr aDDrEssEs If oN then all readers connected to the D8x/D16x must have set addresses of 1, 2 or 3. the PROGRAM MODE LEVEL data is then sent in an extended format that includes the reader address. (use up to three Installer, Remote by pC.
  • Page 67 Control strobE FlasH on arm/DIsarm by rEaDEr P301E 8E this option enables strobe flash when arming and disarming by Reader. (D8x/D16x PROGRAM MODE LEVEL versions prior to V5.4 had strobe flash permanently enabled). Installer, Remote by pC. PROgRAMMINg SEQUENCE:...
  • Page 68 aCCEss Control option No. Description option No. Description p318e p328e ReADeR 1 to Aux outputs ReADeR 2 to Aux outputs option No. Description Default Note p319e ReADeR 1 output tIme 01–24 sec option No. Description p329e ReADeR 2 output tIme 01–24 sec p338e ReADeR 3 to Aux outputs...

  • Page 69: Weigand Reader Wiring Diagram

    In this mode the panel is compatible with the 101-091 Ness IDteck Fingerprint Reader or the 101-014 Ness ultraprox the 101-014 Ness ultraprox weigand Readers can be weigand Reader.

  • Page 70: Remote Operation Monitoring Operation

    CEntral statIon monItorIng the Ness D8 and D16 control panels have an on-board digital dialler which can send CENTRAL STATION MONITORING detailed alarm messages to a central monitoring station. the digital messages can include information about the zone/s which caused the alarm, tamper alarms, low battery or mains failure reports, and it can also (by user number) identify the users who arm and disarm the system.

  • Page 71: Remote Operation By Telephone

    opEratIng tHE panEl by tElEpHonE AudiBle feedBACk the D8/D16 will allow a user to call in sequenCe of operAtion. to the panel, using a standard DtmF 1. phone the panel telephone number • the user Code is valid telephone, and remotely Arm or Disarm and listen for the required number of •...

  • Page 72: Programming Options Summary

    D8/D16 v5 optIons sUmmary page 1 of 3 USER CODE exCluDe+e toggles extra options mode. OPTION DesCRIptIoN DEFAULT PAGE OPTIONS TABLE (Installer program mode only) P00E Follow me telephone Number. none PaGe 14, 15 Pge 63 Page 65 P26E eNtRy DelAy time 1 20 sec area area...
  • Page 73 D8/D16 v5 optIons sUmmary page 2 of 3 OPTION DesCRIptIoN OPTION DesCRIptIoN DEFAULT PAGE DEFAULT PAGE P62E shortcut memory display P70E telephoNe No.1 primary NoNe shortcut Zone exclude P71E telephone No.2 secondary NoNe shortcut monitor mode P72E ACCouNt No. 1 0000 shortcut Keypad panic Account No.
  • Page 74 D8/D16 v5 optIons sUmmary page 3 of 3 OPTION DesCRIptIoN OPTION DesCRIptIoN DEFAULT PAGE DEFAULT PAGE P89E 48, 49 P123E 1e eNABle test CAlls Area 1 armed output to Aux3 mains Report Delay (1 hour) enable telephone remote control of Aux3 listen-In to Dialler swinger shutdown Reader [x] output pulses Aux3...

  • Page 75: Operation Summary

    opEratIon sUmmary opeRAtIoN by KEYPAD by RADIO KEY by ACCESS CARD or FOB to ARM present a Card or Fob press twice. (if p301e 2e is the panel must initially be (If the a is enabled, p62e 5e) rMINg hortCut on).

  • Page 76: Installation Record

    DATE PURCHASED: DATE INSTALLED: INSTALLATION RECORD INSTALLATION COMPANY: TELEPHONE: MONITORING COMPANY: NESS D8 ALARM CONTROL PANEL TELEPHONE: NESS D16 ALARM CONTROL PANEL P26E ENTRY DELAY TIME 1 Seconds ZONE ASSIGNMENT P27E ENTRY DELAY TIME 2 Seconds P28E EXIT DELAY TIME...
