8/16 Zone Control Panels with 4G Communicator
SIM
8
16
8 or 16
Various
Hardwired or
Keypad
Wireless zones
Options
Easy
Fast
Programming
Programming
via Keypad
via PC
Installation & Programming Manual
D8/D16 XCEL
Ness SIM supplied for your convenience.
Activate the SIM on a competitive Ness SIM
Plan or BYO SIM
4G Cellular
Operation by
Smartphone /
Internet
Free
Convenient
NessComms
Programming
Installer Software
via SMS
Operation and
Access
Monitoring by
Control
SMS or Central
onboard
Station
Adjustable
C-BUS
Vibration Inputs
Compatible
on all Zones
using Ness
MiniCentral
D8/D16 XCEL 4G
Navigator, Saturn+ or KPX+
keypad options
activate.ness.com.au
Powerful
Auto-Time
Wireless
Automation
Options
Multiple
Area
Arming
Partitioning
17VAC & 20VDC
Modes
Document 890-490
Rev 1.11
Up to 8 AUX
Outputs
Dual Voltage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D16 XCEL 4G and is the answer not in the manual?

Questions and answers

Related Manuals for Ness D16 XCEL 4G

Summary of Contents for Ness D16 XCEL 4G

  • Page 1 D8/D16 XCEL 8/16 Zone Control Panels with 4G Communicator Navigator, Saturn+ or KPX+ keypad options Ness SIM supplied for your convenience. Activate the SIM on a competitive Ness SIM Plan or BYO SIM activate.ness.com.au Operation and 8 or 16 Various...
  • Page 2 Ness Corporation. Ness recommends central station monitoring using an IP protocol as your primary monitoring path. 5. Ness recommends IP Protocol for most reliable back-to-base reporting. Contact ID (CID) is available as an option and should only be used if your central station does not offer IP protocols.

  • Page 3: Table Of Contents

    Report zone restorals ............. 49 Specifications ................. 93 Release Notes ................ 94 Report multiple zone alarms ..........49 Account No.2 zones ............... 49 Installation Record ..............95 Report Miscellaneous alarms ..........50 Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 4: Product Features

    • Central Station monitoring in Contact ID and ARMOR IP formats • Remote operation and programming via the free NessXCEL app • The panel is not network locked. Activate the supplied Ness SIM or BYO SIM NESS SIM • New PCB layout, AUX5~8 header added...

  • Page 5: Optional Products And Software

    • C-Bus events can control the D8x/D16x. Serial-to-USB adpater cables are required. • Multiple onboard SERIAL repeater ports means the D8x/ D16x panel can also connect to other serial devices while connected to MiniCENTRAL. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 6: Installation Procedures

    ESD 8. Insert the panel tamper bracket leads as shown below. damage may occur. 9. The NESS SIM is factory-fitted or insert your own SIM card as shown. The circuit board should not be 10. Power up as described below.

  • Page 7: Inputs And Outputs

    TAMP input. operation, until the panel is reset). poWEr inpUt tErminaLs A maximum of 2 x 1 Watt Strobes (Ness Part No. NOI300) can be These terminals are for the connection of the external power supply. connected to this output.
  • Page 8 If required, this control panel can alternatively be This power supply has positive and negative 20VDC powered by a 17VAC (1.4A) plug pack. output however the polarity is not important in this case. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 9: Connection Diagrams

    N.O. Tamper SWITCH nEss D8/D16 intErnaL (761-002) Colour: BLaCK ControL panEL TAMP HOrN RESET SpeaKer (NOI110) SIREN The terminal block should STrOBe LIGHT be mounted inside the (NOI300) siren cover. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 10: Keypad Operation - Saturn & Kpx

    * The onboard clock is automatically updated from your cellular network. You should only need to adjust clock settings if the panel is being used 'offline' without a SIM card. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 11 CELLULAR signal and real time clock display. Operational functions are unaffected, however it's recommended that at least one KPX+ keypad be installed to provide cellular signal indication. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 12: Keypad Operation - Navigator

    21, 22. This includes Zone Names, User Names and Installer Details for display on the Navigator keypad and for reporting by SMS messaging. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 13: Operation

    E11E (therefore Aux2 is 22, Aux3 is 33 etc.) More information next page. * If a user code is assigned to a radio key and has Extra Option 4E enabled, (Code Only arming), then pressing OFF toggles the arm/disarm state. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 14: Operation By Sms, Detail

    If the valid user code is not the master user code, but the command requires the master code then the reply is “wrong message” Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 15: How To Enter Program Mode

    This function displays the panel firmware version when in program mode. Displayed in decimal format by the zone LEDs. Example, version V6.1 is displayed by flashing 6 followed by 1. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 16: Quick Start Programming

    Enter the Account number followed 4 digits maximum. The account number is supplied by your by E central monitoring station. To exit program mode. PROG icon will turn off. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 17: Programming By Sms

    M29E ACK 3E ACK M41E ACK 2E ACK ME ACK To DELEtE a user code or phone number, enter V in place of the number. Example. P123EP000000EP180EVE deletes SMS phone number 1. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 18: Central Station Monitoring, Operation

    Arm/Disarm by AutoTimer 5 Arm/Disarm by AutoTimer 6 Arm/Disarm by AutoTimer 1 Arm/Disarm by AutoTimer 2 Arm/Disarm by AutoTimer 7 Arm/Disarm by AutoTimer 3 Arm/Disarm by AutoTimer 8 Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 19: Sms Messaging Sms Monitoring, Operation

    SMS MESSAGE EXPLAINER possible that sms monitoring reports may be delayed or fail NESS security report Identifies the message as a Ness alarm panel report. to be delivered. such failures MYPANEL are a function of the cellular identifies the premises.

  • Page 20: Sms Request Status

    Lists the panel’s model and firmware version Lists the status of Auxiliary outputs 1 to 8. Status of auxiliary outputs If the Aux outputs have been renamed they will be listed accordingly. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 21: Sms Text Output

    For example to delete the zone 1 description "Z1 FRONT DOOR" insert a space followed by a comma in place of the text. SMS SENT TO THE PANEL SMS REPLY t123E,Z1, , text report changes made ZONE 1, Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 22 AUTO ARM DELAY FAILURE SECURITY REPORT USER AUTO EXCLUDE WARNING REPORT *Shortcut names are provided for simplified programming by SMS. (Omit the brackets). See page 21 Changing Text Output Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 23 See more examples on page 17 Radio Keys programmed as an Arm Only can toggle the armed/disarmed state of the panel using the OFF button on the radio key. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 24: User Codes

    REX codes. See page 86. P240E 5E RADIO CODE. Enables selected user codes as Radio Codes P241E for operation by Ness Radio Key or Radio Keypad. (Page 79 - P242E how to program Radio Codes). P243E 6E READER CODE 1.

  • Page 25: Timers

    * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 26: Vibration Sensitivity

    (using a metal object such as a screwdriver blade) will cause an alarm. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 27: Zone Assignment

    When selecting zones, mEmory E selects all zones, 0 E deselects all zones * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 28 Area 1. (This is also the factory default). * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 29: Definitions. Day Zones, Temp Day Zones, Home

    Zones. The selected zones are indicated by entering program mode. default beep warning tone. See P126E 4E. the corresponding zone number. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 30 See page 29 for information about TEMPORARY DAY ZONES * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 31: Zone To Output Mapping

    When selecting zones, mEmory E selects all zones, 0 E deselects all zones * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 32 P[MasterCode]E P[InstallerCode]E P59E [Zone Number] E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 33: Various Options

    P129E N/C contacts in series. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 34 P144E 2E, AUX4 on when Area2 arms. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 35: Tamper/Keypad Panic Output Mapping

    P[MasterCode]E P[InstallerCode]E P61E 5E ~ 8E as required P126E1E). * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 36: System Operation Shortcuts

    P[MasterCode]E P[InstallerCode]E P62E 8E SMS* P28E Exit Time. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 37: Home Mode, Day Mode Output Mapping

    SMS* P[MasterCode]E P[InstallerCode]E P64E 1E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 38: Miscellaneous Options

    P120E 2E Siren Chirp on Home Arming by Radio * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 39: Zone Supervision Options

    The purpose of Radio Supervision is to verify the correct operation of Ness Radio PIRs. The Supervision signal from the Radio PIR tells the panel that the device has not been removed from radio range and is in working order.
  • Page 40 P65E Supervised Zones. SMS* P[MasterCode]E P[InstallerCode]E P66E 4E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 41 P66E 1E–4E Supervision Alerts. P66E 7E–8E Supervision Time Speed- * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 42: Misc. Options

    1E DoUbLE prEss raDio paniC program moDE LEVEL Setting this option ON enables Double Press Panic for Ness Radio Keys, if fitted. The panel Installer will look for two radio Panic signals in a row to sound the Panic alarm.
  • Page 43 P120E 3E Radio Key AUX / arms Home Monitor P162E Chirp Siren Volume * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 44 Arming/Disarming by keypad, keyswitch or by Radio Key. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 45 * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 46: Communicator Options Central Station Monitoring Account Numbers

    HOME Key # (Hash) EXCLUDE Key * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 47: Central Station Reporting Numbers

    P[MasterCode]E P[InstallerCode]E P172E [New Phone Number]E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 48: Sms Monitoring Phone Numbers

    Number 1 send the SMS message, P[MasterCode]E P[InstallerCode]E P180EVE * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 49: Report Zone Alarms

    When selecting zones, mEmory E selects all zones, 0 E deselects all zones * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 50: Report Miscellaneous Alarms

    = 1E, 2E, 3E or 4E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 51: Test Call Options

    4G providers to prevent excessive traffic. 1=10min, 2=20min, 3=30min, 4=1hr * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 52: Reporting Format Options

    ARMOR IP Message Format Table, Page 18 * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 53: Enable Sms Reporting

    P87E > enable/disable 4E SMS* P[MasterCode]E P[InstallerCode]E P87E 4E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 54: Area1, Area2 Open/Close Reports

    P88E 3E Siren Chirp on kiss-off. P[MasterCode]E P[InstallerCode]E P88E 4E SMS* * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 55: Other Reports

    P88E 7E Manual Exclude Reports. SMS* P[MasterCode]E P[InstallerCode]E P88E 8E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 56: Enable Test Calls

    P78E Report Multiple Zone Alarms. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 57: No Memory Warning Zones

    When selecting zones, mEmory E selects all zones, 0 E deselects all zones * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 58: Clear Radio Devices

    P99E > [New Installer Code] E [New Installer Code] E P[MasterCode]E P[InstallerCode]E P99E [New Installer Code] E SMS* For a complete list of factory default values, see the Programming Options Summary on pages 87–92. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 59: Output Expander Options

    Zone 16 Ext. Tamper Zone 16 * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 60 P[MasterCode]E P[InstallerCode]E P119E [Zone Number] E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 61 LEVEL This option enables the AUX button on a Ness RK4 Radio Key to arm Home Mode. Installer When this option is enabled, options P122E 3E & 4E will be disabled, (AUX button to Aux2 FaCtory DEFaULt options.
  • Page 62 P60E 2E, 3E. P120E 1E, 4E, 5E P[MasterCode]E P[InstallerCode]E P120E 8E SMS* * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 63: Aux Outputs Aux1~4 Output Options

    Set the reader using P318E, P328E or P338E. P339E. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 64 P[MasterCode]E P[InstallerCode]E P145E [NewTime] E SMS* * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 65 Set the reader using P318E, P328E or P338E. P339E. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 66 SMS* P[MasterCode]E P[InstallerCode]E P146E [NewTime] E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 67 Set the reader using P318E, P328E or P338E. P339E. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 68 SMS* P[MasterCode]E P[InstallerCode]E P147E [NewTime] E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 69 Set the reader using P318E, P328E or P338E. P339E. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 70 P148E > [New Time] E rELatED options P144E 8E SMS* P[MasterCode]E P[InstallerCode]E P148E [NewTime] E WIRING EXAMPLES Aux4 driving an extension sonalert. See P124E 2E. Use the optional 106-013 Relay Board Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 71: Aux5-8 Output Options

    P153E 8E Pulse AUX7 P154E 8E Pulse AUX8 * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 72: Alarm/Fire/Chirp Siren Volume

    0 E deselects all. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 73: End Of Line Resistor Options

    • The keyswitch input (if enabled) always uses a 2K2 resistor regardless of the global EOL resistor value set by P129E. Also see P60E 2E, 3E, page 33. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 74: Autotime Options Autotime Description And Examples

    SIM card the time is automatically set by the cellular network. If the panel is being used 'offline' without a SIM card then use options P340-P344E to set the clock, page 75. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 75: Realtime Clock Programming

    P[MasterCode]E P[InstallerCode]E P392E 1E as required * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 76 Note. AUX outputs must be enabled for control by AutoTimers at options P121E-P124E. * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 77: Signal Strength Test

    • Signal strength of Radio Keys can The Radio Signal Strength Test can be used to test the radio signal from any Ness radio be tested in USER PROGRAM Mode or device. The strength of the radio signal received is displayed on the zone lights 1 to 8 INSTALLER PROGRAM Mode.

  • Page 78: Radio Device / Radio Key Programming

    The optional 100–200 Ness Radio Interface is required for radio devices to operate. radio keys. In this case the zone can A radio device is any type of Ness transmitter including Radio PIR, Radio Reed not also be programmed to accept a Switches, Radio Smoke Detector.
  • Page 79 – p256E Each of the 56 User Codes, except for the Master Code, can be programmed to be Radio Codes. This allows up to 55 Ness Radio Keys to be used for Arming and program moDE LEVEL Disarming of the panel. The Ness RKP Radio Keypad can also be used with the D8/ Installer D16, (see the RKP installer manual).

  • Page 80: Serial Output Options

    7E ON: Send test ASCII string. Sends test data periodically, used for testing the serial port (D8x/D16x V6 and later.) * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 81: Access Control Options

    NORMALLY CLOSED Zone 8 Input Momentary pushbutton * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 82: Access Control Options

    OFF (Use one reader). data is then sent in an extended format that includes the reader address. (Use up to three Ness prox readers). The reader's address is determined the connection of the violet wire. notEs See the wiring diagram on page 86).
  • Page 83 P122E 7E DOTL Alarms to AUX1 P305E Misc DOTL options * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 84 P[MasterCode]E P[InstallerCode]E P304E [NewValue] E SMS* * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 85 P153E 7E, P154E 7E, P319E, P329E, P339E * SMS programming shows the full SMS string to send. KPX+ and NAVIGATOR programming assumes the panel is already in program mode. Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 86: Weigand Reader Wiring Diagram

    • Code 1555 activates door associated with AUX1 (READER 1). • Code 2555 activates door associated with AUX2 (READER 2). • Code 3555 activates door associated with AUX3 (READER 3). Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 87: Programming Options Summary

    P229E P230E P231E P232E P233E P234E P235E P236E P237E P238E P239E P240E P241E P242E P243E P244E P245E P246E P247E P248E P249E P250E P251E P252E P253E P254E P255E P256E Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 88 Disable Mains Fail Alarm All options can be programmed in Installer Program Mode Exit BEEPS - Full Arm Options relating to SMS reporting are marked Exit BEEPS - Home Mode Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 89 4 Dialling attempts Zone Supervision alarms to AUX1 Radio key Panic TOGGLE Radio key Panic PULSE door Open Too Long (dOTL) alarm to aUX1 Reader [x] output to AUX1 Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 90 Home Armed to AUX1 p156E AUX6 timer 20 sec Keypad toggle AUX1 p157E AUX7 timer 20 sec [not used] p158E AUX8 timer 20 sec [not used] [not used] Pulse AUX1 Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 91 DOTL time 20 sec p305E 1E DOTL output LATCHES DOTL outputs to Output Expander DOTL Timer in Minutes DOTL Timer in Hours DOTL zone flashes on keypad Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...
  • Page 92 Uses AUX5&6 not AUX1&2 AUX3 TOGGLE AUX1 TOGGLE See pages 74-76 for descriptions of AutoTimer AUX3 PULSE AUX1 PULSE related options. AUX4 TOGGLE AUX2 TOGGLE AUX4 PULSE AUX2 PULSE Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 93: Specifications

    Maximum 500mA. DIMENSIONS PLASTIC HOUSING 235w x 300h x 90d mm CARTON 330w x 310h x 105d mm CARTON WEIGHT (Plastic Housing) ~ 4kg including plug pack and battery Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 94: Release Notes

    DispLay thE FirmWarE VErsion By Keypad, in User or Installer program mode, press P 99999999 E (eight 9's) By SMS, send the command: i [Master Code] E MOD Ness D8xCeL / D16xCeL 4G CoNtroL PaNeL – INstaLLatIoN MaNuaL rev 1.11...

  • Page 95: Installation Record

    DATE PURCHASED: DATE INSTALLED: INSTALLATION RECORD INSTALLATION COMPANY: TELEPHONE: MONITORING COMPANY: NESS D8 ALARM CONTROL PANEL TELEPHONE: NESS D16 ALARM CONTROL PANEL P26E ENTRY DELAY TIME 1 Seconds ZONE ASSIGNMENT P27E ENTRY DELAY TIME 2 Seconds P28E EXIT DELAY TIME...

This manual is also suitable for:

D8 xcel 4gD16x4g
