Optional Parts - THE WORLD MODELS Outregeous Instruction Manual

9
Outrunner Motor / Cowling
PWA2.3x8mm Screw
4
Silicon Grommet
d1.5xD6.5mm
4
Make sure rotating
motor casing is not
in contact with
wirings or anything.
Don't over-tighten the
M3 screws, too much
stress on the screws
could split the firewall.
Fuselage
Cowling
PWA2.3x8mm
d1.5x6.5mm
Silicon Grommet
E337XMPO28991306
Outrunner Motor 37/ 49 - 750kv
KM37490750
11x8E Propeller PL6211108
1
KM3x6 mm
ESC
Solder
Solder
Double-sided Tape 30x35mm
Cable Tie 4x200mm
Brushless ESC
1.8mm
TWM HW3112400
PROPELLER ADAPTOR WRENCH
11x8E Propeller
PL6211108
Propeller Adaptor
HW2340300
Aluminum Pole
TWM
Motor
KP0011310
4
P.8

Optional Parts

TWM HW3112400
PROPELLER ADAPTOR WRENCH
X- Mount Plate/Pole
2
M3x30 mm
Adaptor
3
Cowling
5
PA2.3x8mm
Ø38mm Spinner
Completed
