Main Wing
2
Aileron Servos
PB2x14mm
Screw
4
PA1.7x8mm
Screw
8
TWM PL8210010
CLEVIS WRENCH
PB2x14mm
Clevis
Horn
E337XMPO28991306
Apply instant type CA glue to both sides of each hinge.
Bottom View
Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole
marks at under side of control surfaces.
Pushrod
Ø1.8x76mm
Fuel Tube
D6x5mm
Bottom View
Aileron Servo Lead
PA1.7x8mm
P.3
Straper
Fuel Tube
D6x5mm
Completed
