Installing The Sd Unit - Dedicated Micros SD Unit Quick Start Manual

The following document will guide you through the installation, configuration and initial operation of the SD
Unit.
Use this guide in conjunction with the SD Installation & Operation manual. This document is located on the
Product cd supplied with the unit and can also be found on the dedicated micros website.

Installing the SD Unit

The SD supports a main monitor via BNC 'A' and a
spot monitor via BNC 'B'.
The sd supports a 10/100mbps auto-detecting
network port. Use a CAT5 cable to connect the unit to
the network.
By default the unit is configured for DHCP where the
unit is automatically allocated an IP address from the
network DHCP server.
dns (dynamic name servers) is supported and
therefore the unit can be assigned a name. This
removes the need for the unit to have a fixed IP
address and makes it easier for a remote user to
locate.
dedicated micros ©2007
The SD supports Video Inputs via the 75Ω BNC
connectors. connect cameras to the video inputs:
starting from input 1.
A 2
S A T
A 1
S A T
2 P
I A L
S E R
T
O U
1
I A L
S E R
I N
D I O
A U
T
N E
The sd supports bi-directional audio, accessible
through netVu obserVer. connect the audio
U S B
equipment to the phono sockets AUDIO IN and
AUDIO OUT. The audio channel defaults to recording
camera 1.
Note: The Audio ouptut can be configured as a
challenge output or as a replay output.
