Tower Hobbies UPROAR User Manual

Uproar arf
Hide thumbs Also See for UPROAR:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Wingspan: 48 in [1,220mm]
Wing Area: 618 sq in [39.9 dm
Weight: 4 lbs [1,810 g] Length: 44 in [1,120mm]
Wing Loading: 15 oz/sq ft [46 g/dm
Engine: .32 – .46 cu in [5.0 – 7.5 cc] two-stroke,
.40 – .52 cu in [6.5 – 8.5 cc] four-stroke
Radio: 4-channel, 5 standard servos
Tower Hobbies
guarantees this kit to be free from defects in both material and workmanship at the date of purchase. This warranty
®
does not cover any component parts damaged by use or modification. In no case shall Tower Hobbies' liability exceed the original
cost of the purchased kit. Further, Tower Hobbies reserves the right to change or modify this warranty without notice.
In that Tower Hobbies has no control over the final assembly or material used for final assembly, no liability shall be assumed nor
accepted for any damage resulting from the use by the user of the final user-assembled product. By the act of using the user-assembled
product, the user accepts all resulting liability.
If the buyer is not prepared to accept the liability associated with the use of this product, the buyer is advised to return this
kit immediately in new and unused condition to the place of purchase.
To make a warranty claim send the defective part or item to Hobby Services at the address below:
Include a letter stating your name, return shipping address, as much contact information as possible (daytime telephone number, fax
number, e-mail address), a detailed description of the problem and a photocopy of the purchase receipt. Upon receipt of the package
the problem will be evaluated as quickly as possible.
READ THROUGH THIS MANUAL COMPLETELY BEFORE STARTING CONSTRUCTION. IT CONTAINS
IMPORTANT INSTRUCTIONS AND WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.
®
© Copyright 2004 V 1.0
2
]
2
]
WARRANTY
Hobby Services
3002 N. Apollo Dr. Suite 1
Champaign IL 61822
®
USA
Champaign, IL 61826
(800) 637-6050
www.towerhobbies.com
Tower Hobbies
P.O. Box 9078
TOWZ1157 for TOWA2054
