GROVE GR7 MADNESS
Needle valve.
Machine screw M3x10mm.
3) Install the muffler and muffler extension
onto the engine and make the cutout in the
cowl for muffler clearance. Connect the fuel
and pressure lines to the carburetor, muffler
and fuel filler valve. Secure the cowl to fuse-
lage using the M3x10mm screws.
ELECTRIC POWER CONVERSION.
1) Locate the items neccessary to install the
electric power conversion included with your
model.
10
Instruction Manual.
Recommendation EP parts as shown (not
included with your model)
- Model size: .45-.52 size models
- Motor: 35mm 830 rev per volt
- Propeller: 12x6-13x6
- ESC: 50A
- Lipo Batteries: 4 cell 3200mA
2) Attach the electric motor box to the firewall
suitable with the cross lines drawn on the electric
motor box and firewall. Using epoxy and balsa
stick to secure the motor box to the firewall.
Please see pictures below.
3) Attach the motor to the front of the electric
motor box using four 3mm blind nut, four
M3x15mm hex head bolts to secure the motor.
Please see picture shown.
M4x20mm.
