Cobra Vehicle Alarm Series 3100 Fitting Instructions

SPECIFIC VEHICLE ALARM FITTING INSTRUCTIONS
www.cobra.it
DAEWOO
MAKE
ALARM/SIREN
POSITION
POWER SUPPLY
DIRECTION INDICATORS
ELECTRIC WINDOWS
CENTRAL DOORS LOCKING
IMMOBILISATION POINT
BONNET SWITCH
DOORS SWITCH
BOOT SWITCH
Note: This information is not binding, therefore it must be considered only an example for installation purposes that must be executed
as per the instructions given on the product installation manual.
NUBIRA
MOD.
Position the compact alarms and the sirens in the engine compartment near the
left lateral headlamp. Position the modular systems and the modules under the
dashboard, drivers side.
+ 30: connect to the 2,5mm
drivers side.
- 31: connect with an eyelet cable terminal to one of the fastening bolt of the
dashboard.
2
Connect to the 1 mm
harness and coming out of the 22 way yellow connector located on the support of
the connector holder, above the fuse box behind the left lateral frame, drivers
side.
Positive control signal
Front window, driver's side:
cut the BLUE wire directly outgoing from the switch of the window to the inner
drivers side door.
Front window, passenger's side:
2
cut the 1,5 mm LIGHT BLUE wire.
Rear window, driver's side:
2
cut the 1,5 mm BROWN wire.
Rear window, passenger's side:
2
cut the 1,5 mm GREEN wire located in the wiring harness coming out of the
drivers side door.
Negative control signal
Connect to the LIGHT BLUE wires with WHITE reference located at the position
nr. 7 (lock) and the YELLOW at the position nr. 1 (unlock), in the 9 way white
connector of the central door locking unit located at the rear of the left lateral
frame, drivers side.
Note: for the vehicles without original key less entry, please refer to
diagram nr. 42 for the serie Bridge antithefts or refer to diagram nr.42A for
serie 3100 antithefts.
The vehicle has an original equipment immobiliser that may be enabled
immediately when the switchboard is switched off.
Install an additional switch on the front headlamp support plate.
2
Connect to the 0,5 mm
the 16 way white connector, on the support of the connector holder, above the
fuse box behind the left lateral frame, drivers side.
Connect to the 0,5 mm
harness and coming out of the 16 way white connector located on the support
mentioned above.
YEAR
2
RED wire located at the rear of the left lateral frame,
BLUE and LIGHT BLUE wires located
WHITE wire located in the wiring harness coming out of
2
PINK wire with BLACK reference located in the wiring
REV. 00
PETROL
98
DIESEL
in the wiring
danub98gbb.doc
X
