UG-059

BILL OF MATERIALS

Table 3. AD5504
Qty Name
4 C1 to C4
2 C5, C11
17 C6, C7, C9, C12, C13, C16 to C19,
C21, C22, C26, C27, C29 to C32
3 C10, C23, C24
2 C15, C28
1 C25
4 D1 to D4
1 J1
2 J2, J5
2 J3, J4
1 J6
3 LK1 to LK3
2 LK9, LK10
4 R1 to R4
4 R5, R7, R11, R19
1 R6
4 R8, R12, R16, R17
2 R9, R13
1 R10
1 R15
20 T1 to T11, T14 to T19, T22 to T24
4 T12, T13, T20, T21
1 U1
1 U2
1 U3
1 U4
1 U5
4 V1 to V4
1 Y1
1
FEC refers to Farnell In One; Digi-Key refers to the Digi-Key Corporation.
Part Description
Socket pins × 2
Capacitor, 10 μF, 100 V
Capacitor, 0603, 100 nF, 50 V
Capacitor, Case A, 10 μF, 10 V
Capacitor, 0603, 22 pF, 50 V
Capacitor, Case A, 2.2 μF, 10 V
LED, SMD 0805 green
Socket, USB MINI-AB SMT
Black 4 mm banana socket
Red 4 mm banana socket
10-pin (2 × 5) 0.1" pitch 90° header
2-pin 0.1" pitch header and shorting shunt
6-pin (3 × 2) 0.1" header and shorting shunt
Socket pins × 2
Resistor, 0603, 100 kΩ
Resistor, 0603, 10 kΩ
Resistor, 0603, 2.2 kΩ
Resistor, 0603, 1 kΩ
Not populated
Resistor, 0603, 0 Ω
Terminal, PCB red
Terminal, PCB black
High voltage, quad-channel DAC
USB microcontroller
Precision low dropout voltage regulator
IC serial EEPROM 64K 2.5 V 8-SOIC
Bus transceiver
50 Ω SMB 90° PCB jack
CM309S SMD crystal
Rev. 0 | Page 8 of 12
Evaluation Board User Guide
1
Stock Code
FEC 329563 (two required)
FEC 9693130
FEC 431989
FEC 9751041
FEC 9406107
FEC 9753796
FEC 8529906
FEC 9786490
FEC 1101128
FEC 1101127
FEC 102-2233
FEC 102-2247 and FEC 150-411
FEC 102-2231 and FEC 150-411
FEC 329563 (two required)
FEC 9330402
FEC 9330399
FEC 9330810
FEC 9330380
N/A
FEC 9331662
FEC 8731144
FEC 8731128
AD5504BRUZ
Digi-Key 428-1669-ND
ADP3303ARZ-3.3
FEC 9758070
Digi-Key 296-8279-1-ND
FEC 121-2895
FEC 9509658
